Diablotek DHCV0302 Specifications

Model NO.: DHCV0302
UPC NO.: 843636002143
XBOX TO HDMI CONVERTER
Description:
(HDMI/DVI+SPDIF/YPBPR TO HDMI/SPDIR)
SPEC.:
• Output signal format: HDMI1.3 protocol compliant.
Feature:
• Up support capture 1080p Analog YPbPr Input, bandwidth 330M
• HDCP1.2 protocol compliant.
• Deep color 36bit support.
• SPDIF HIFI audio output from HDMI1.3 signal:
• Support interfuse SPDIF, convert DVI to HDMI.
• Support interfuse RL or SPDIF, convert YPbPr/YCbCr to HDMI.
• Manual or Remote, Switch input source signal from HDMI to DVI to
• LED indication: input source signal selection. When some source is

Box Content:

• Xbox to HDMI Converter
• Remote control
• Power Adapter.
• User's Manual
HDMI
Inputs
Outputs
Display Selection
Vertical Frequency
Dimension
Power Adapter
Remote control
LPCM/Dolby-AC3/DTS7.1/DSD.
YPbPr.
selected, LED relative to the source is red. When output is working,
LED relative to the sink is red.
DVIx1, HDMIx2, SPDIFx1
SPDIFx1, RCAx5
Push Button or Remote Control
50/60/75HZ.
10.3x4.5x1 in
Input :100-240V, Output : 5V
Infrared, discrete code
