- Page 1 ShuttleOne 2.5-inch M.2 to U.2 NVMe SSD Carrier Shuttle Full Metal Housing Swappable Easy Assembly & Installation Up to 8,000MB/s...
- Page 2 TABLE OF CONTENTS INTRODUCTION 1.1 System Requirements ..................3 1.2 Packaging Contents ..................3 1.3 Installation and Usage ..................3 1.4 About This Manual ................... 3 INSTALLATION 2.1 Installation of M.2 Drive .................. 4 SUPPORT RESOURCES 3.1 Contacting Technical Support ................ 7 TABLE OF CONTENTS...
- Page 3 OWC U2 ShuttleOne Quick start guide 1.3 INSTALLATION AND USAGE The OWC U.2 ShuttleOne installation steps and digital guide, as well as other manuals and guides are available at: www.owcdigital.com/support/manuals 1.4 ABOUT THIS MANUAL The images and descriptions may vary slightly between this manual and the unit shipped. Functions and features may change depending on the fi rmware version.
- Page 4 INSTALLATION 2.1 INSTALLATION OF M.2 DRIVE For reference, the steps below show how to install an NVMe M.2 drive with a 2280, 2260, 2242, or 2230 form factor. Note that each supported form factor has a post location silkscreened on the inside of the ShuttleOne, which you can see once the bottom plate is removed.
- Page 5 3. Remove the cover and set it aside. If you are going to install a 2280 form factor M.2 drive, all you need to do is remove the drive post screw (3B). By default, the screw and drive post should be installed on the 2280 form factor. 4.
- Page 6 8. Once completed, the OWC U.2 ShuttleOne is now ready for installation in the host. Please consult the manuals for the following OWC products that are compatible with the ShuttleOne: ThunderBay Flex 8, Helios 3S with U.2 Interchange system, or Mercury Pro U.2 Dual enclosure.
- Page 7 OWC. © 2021 Other World Computing, Inc. All rights reserved. OWC, the OWC logo, and U.2 ShuttleOne are trademarks of New Concepts Development Corporation, registered in the U.S. and/or other countries.
