Qi Wireless Charging
IMPORTANT NOTE: Only attempt to wirelessly charge devices
which are listed as Qi Certified.
ChargePort Duo has two Qi compliant wireless charging pads,
each capable of charging compatible devices up to 10 watts.
Place device to be charged on one of the Qi charging pads and
adjust position until the charging indicator (6) pulses yellow.
If the indicator does not pulse yellow then adjust the position of the
device being charged until it does.
You can charge two devices simultaneously, one on each wireless
charging pad.
Do NOT place metallic objects on the wireless charging pads.
In case of accidental placement of metal objects on one of the
wireless charging pads, ChargePort Duo is equipped with Foreign
Object detection (FOD). If metallic foreign objects are detected by
ChargePort Duo then charging will be disabled and the indicator for
the affected charging pad will flash white. Remove the foreign
object.
ChargePort Duo also monitors temperature to check for signs of
over heating. If the temperature is too high then charging will be
disabled and the indicator for the affected charging pad will flash
white until the temperature returns to the normal range.
USB Charging
ChargePort Duo includes three USB ports, 1 x USB-C and 2 x USB-
A. The USB ports support powering and charging most devices
including iPhone, iPad, iPod, Android devices, e-readers, digital
cameras and more (USB cables sold separately).
The USB-C port can supply 5V/3A, and the USB-A ports can supply
5V/2.4A each.
6
6
Specifications
Input
Voltage/Current:
12V/4A
Wireless Charging
Output Power:
5W/7.5W/10W. Total:20W (Max.)
Over voltage protection:
Yes
Under voltage protection:
Yes
Short circuit protection :
Yes
Over current protection:
Yes
Over temperature protection:
Yes
Foreign Object Detection (FOD): Yes
Working Frequency:
110-205KHz
Wired Charging
Single output (USB-A or USB-C): 5V3A,9V2A,12V1.5A
Dual output (USB-A and USB-C): 5V3A. Total 15W (Max.)
Short circuit protection:
Yes
Over current protection:
Yes
Environmental
Operating temperature range:
0~25°C
Storage temperature range:
-20 ~ 70°C
Operating humidity:
10% ~ 80% RH
Storage humidity:
5% ~ 95% RH
7
7
