VTC Pro Audio Inception NS21P Service Manual page 18

LEADS & PINS REFERENCE
2N5401 (YS#5108)
2N5551 (YS#5107)
MPSA06 (YS#5103)
MPSA13 (YS#5105)
TO-92
E B C
IRS21844PBF (YS#6586) 74HC14N (YS#6603)
MC78L05ACP (YS#6728)
TO-92
O G I
LM318 (YS#6542)
BC550C (YS#5101)
TO-92
NJM7815FA (YS#6856)
C B E
TO-220
FOD816 (YS#2306)
I G
LM311 (YS#6640)
NJM7915FA (YS#6857)
TO-220
O G I O
IRGP35B60PDPBF (YS#2307)
LM13600N (YS#6745)
MODEL(S):-
#
LM6172IN (YS#2318)
1
MC33078P (YS#6840)
2
3
NE5532N (YS#6884)
4
TL072CP (YS#6882)
5
6
7
8
9
10
11
12
TO-247
13
1
2
3
4
5
6
G C E
7
8
9
10
11
12
13
POTENTIOMETERS AND KNOBS
M1375
MODEL(S):- LS2100P
REF FUNCTION PART# KNOB STYLE
P1 LEVEL 2339 8653 P34
P2 SHAPE 2340 8653 P34
P3 ROLLOFF 2339 8653 P34
M1375
LS2100P/NS21P
DATE VER# DESCRIPTION OF CHANGE
28-APR-2009 1.00 RELEASED FOR PRODUCTION
28-OCT-2009 2.00 ADDED D41 IN SERIES WITH PIN 1 OF Q9
. . REMOVED PCB FROM X8010, CHANGED TO M1375
06-MAY-2010 3.00 Increased Hole sizes: T0220 packages and 156 spacing Molex
24-JUN-10 4.00 PC#
. . .
02-FEB-11 . PC8198: DNS 245V CONN, ADD FUSE VALUES
04-JUL-2013 V05 PC8545: Moved vias from under resistors. - ML
11-DEC-2013 V06 PC8441 - Changed footprint for J1 to YS#4100. - ML
15-JULY-2014 V06 PC#8674 GROUNDING HOLE PATTERN MODIFIED.
T0126 AND T0220 TRANSISTOR PADS UPDATED.
17-DEC-2014 PC8734 - Add 2 diodes (YS#6438) in location
. . shown on bottom of board.
14-JAN-2015 V07 PC#8734:D12 and D14 added to U30,U31 regulators.
16-JUN-2015 . PC8811: Add NS21P product used on. GG
17-JAN-2017 . PC8988: Change C81, C82, C85, and C86 to 1N YS#5220
19-JAN-2017 V08 PC8988: Implemented on board
D V N
D V N
D V N
D V N
D V N
D V N
D V N
D V N
D V N
"STYLE_P34"
