1. LEDS LD1, LD2, AND LD3 ARE TO BE HAND INSERTED.
2. INSTALL YS#8937 TIE AROUND C104. SEE PIC.
3. RTV ALL ELECTROLYTIC CAPACITORS.
4. PCBSA: DO NOT STUFF J3, J5. J7, P2, P3, OR S1
5. PCBSA: TACK ON 3 RESISTORS 8K25 #4792 SEE ATTACHED PHOTO.
SEE LAYOUT DIAGRAM
NS21P
PRODUCTION NOTES
