- Page 1 S707 SL-100 SLOTTING MACHINE INSTRUCTION & PARTS MANUAL 14-11-11...
-
Page 8: Speed Change
OPERATION MANUAL FOR SLOTTING HEAD 1. USAGE The slotting head can be widely used for slotting internal and external keyways, spline cutting and machining odd shapes etc. 2. ITS CONSTRUCTION AND OPERATION INSTRUCTION. A. The slotting head is driven by 0.25kw motor. The reciprocal movement is realized by a pair of 6 step triangle pulley, worm and worm gear through an eccentric block. -
Page 9: Stroke Adjustment
4. STROKE ADJUSTMENT Ensure machine is unplugged from Power Supply Open Vee belt cover and turn pulleys manually to get ram stroke in Center of the stroke. Undo the nut on front dial as needed, The Dial will come with it and disengage the fixed pin in the dial from the hub. - Page 12 SLOTTING HEAD...
- Page 13 SLOTTING HEAD PARTS No. Qty. Code Name No. Qty. Code Name X6325-3011 slotting head 80-105-12 seal ring X6325-3304 housing cover 2306 bearing X6325-3022 adjust plate X6325-3013 Cover motor 7204AC bearing motor pulley X6325-3116 washer slotting connector X6325-3117 washer X6325-3014 eccentric block lock washer X6325-3019 joint rod...
- Page 14 No. Qty. Code Name No. Qty. Code Name X6325-3017 travel adjuster X6325-3120 travel dial M6X12 Screw 5X12 M8*100 Screw Ventilation 4X16 plate M4*8 Screw X6325-3303 housing cover X6325-3205 plate handle knob 4X20 oil cup oil pointer choke plug adjust screw X6325-3104 Spring M8X20...
- Page 15 Certificate of Inspection VERTICAL SLOTTER Dispatch No.：...
- Page 16 The machine has been qualified and may be permitted to dispatch Head of inspection depart Date Director Date...
- Page 17 Total 2 ACCURACY TEST FOR VERTICAL SLOTTER Checking items T o le rance Error tested 0.025 for The flatness of worktable surface any tested length 200 Max 0.08 Squareness of worktable longitudinal movement to cross 0.04/300 movement Parallelism of worktable longitudinal movement to the 0.05 base T-slot Parallelism of worktable...
- Page 18 Total 2 ACCURACY TEST FOR VERTICAL SLOTTER Checking items T o l e r a n c e Error tested Squareness of slotting head a 0.05/100 vertical movement to worktable surface b 0.05/100...
- Page 19 General Machinery Safety Instructions Machinery House requires you to read this entire Manual before using this machine. 1. Read the entire Manual before starting 14. Use correct amperage extension cords. machinery. Machinery may cause serious injury if Undersized extension cords overheat and lose not correctly used.
- Page 20 Slotting Machine Machine Safety Instructions Machinery House requires you to read this entire Manual before using this machine. 1. Maintenance. 9. Work area hazards. Make sure the Slotting Machine is Keep the area around the turned off and disconnect from the main power Slotting Machine clean from oil, tools, objects &...
