YORKVILLE VTC PRO Audio NS21P Service Manual
  1. Manuals
  2. Brands
  3. YORKVILLE Manuals
  4. Speakers
  5. VTC PRO Audio NS21P
  6. Service manual
YORKVILLE VTC PRO Audio NS21P Service Manual

YORKVILLE VTC PRO Audio NS21P Service Manual

Rev1+rev2
Hide thumbs

Advertisement

Quick Links

Download this manual
CANADA
Yorkville Sound
550 Granite Court
Pickering, Ontario
L1W-3Y8 CANADA
Voice: (905) 837-8481
Fax: (905) 837-8746
www.vtcproaudio.com
U.S.A.
Yorkville Sound Inc.
4625 Witmer Industrial Estate
Niagara Falls, New York
14305 USA
Voice: (716) 297-2920
Fax: (716) 297-3689
NS21P
REV1+REV2
SMT Disclaimer
Due to the complex nature of the use of SMT installed components
in Yorkville equipment, we highly caution all service technicians in
attempting to repair or replace SMT factory installed components.
Many of these components may be glued prior to initial soldering.
Replacing SMT components requires expensive
specialized de-soldering equipment and training.
Yorkville Sound will repair and replace defective SMT components
to ensure proper quality assurance and installation is maintained.
Service Manual
Manual-Service-VTC-NS21P-00-1v7 • September 14, 2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the VTC PRO Audio NS21P and is the answer not in the manual?

Questions and answers

Related Manuals for YORKVILLE VTC PRO Audio NS21P

Summary of Contents for YORKVILLE VTC PRO Audio NS21P

  • Page 1 Due to the complex nature of the use of SMT installed components Pickering, Ontario Niagara Falls, New York in Yorkville equipment, we highly caution all service technicians in L1W-3Y8 CANADA 14305 USA attempting to repair or replace SMT factory installed components.
