- Page 1 INSTRUCTION MANUAL Flexible Arm & Clamps for FAE Fume Extractor Ref. FAE070...
- Page 2 Packing List The following items are included: Flexible Arm ..........1 unit Clamps ............2 units Ref. FAE070 Ref. 0018940 Screws* ............2 units Washers* ............ 2 units Ref. 0018681 Ref. 0018877 Manual ............1 unit Ref. 0019184...
- Page 3 w w w.jbctools.com Assembly * You can also fix the flexible arm on your workbench with the supplied screws Lenght: 1 m (39.37 in) Clamp to fix flexible arm in place Connect the Flexible Hose to Flexible Arm Flexible Hose Ø50 Ref.
- Page 4 Arm assembly - When the flexible arm loses firmness, it must be re-compressed. - For a greater compression, turn it slightly clockwise. - Once the arm is compressed, adapt its position again. Nozzles You can replace the supplied nozzle and choose the one that best suits your needs. 70 cm / 27.6 in max.
- Page 5 w w w.jbctools.com Nozzle Replacement Turn the nozzle and pull out to A bayonet fitting system The nozzles are designed to remove it. allows a proper connection work with the arm suspended between the flexible arm and and also supported on the the nozzle.
- Page 6 Notes...
- Page 7 w w w.jbctools.com Notes...
- Page 8 41.34 x 6.7 x 4.72 in / 6.2 lb Complies with CE standards. ESD protected. Warranty JBC’s 2 year warranty covers this equipment against all manufacturing defects, including the replacement of defective parts and labour. Warranty does not cover product wear or misuse.
