Denon AVR-887 Specifications

A/V Surround Receiver
AVR-887
7.1 A/V Surround Receiver features HDMI repeater, conversion,
XM-HD Surround and iPod command and control capability.

Audio section

Fully discrete 7-channel high power amplifiers
Front 100 W + 100 W
Center 100 W
Surround 100 W + 100 W
Surround Back 100 W + 100 W
High-quality sound reproduction
• New high resolution 32bit floating point DSP
• 96 kHz processing circuit
• 24 bit, 192 kHz capability high resolution D/A conversion
Denon's basic design for high-quality sound reproduction
• Power transformer for high power driven
• Twin drive rectifier
• Large aluminum extruded heatsink
Wide-Range Play Capability for DVD-Audio and Super Audio CD
The power amp circuits of the AVR-887 have been meticulously designed to repro-
duce the exceptionally high sound quality with wide frequency response from 10
Hz to 100 kHz.
Dual-Channel surround back power amp for 7.1 surround
The AVR-887 is equipped with a total of 7 power amps including 2 for the Surround
Back channel speaker to give you more clearly defined sound localization at the rear
for 6.1-channel surround sources such as DTS-ES Discrete 6.1, DTS-ES Matrix 6.1,
Dolby Digital EX, and DTS-ES NEO:6.
Supports the most advanced surround playback formats
• DTS 96/24 Decoding for DVD-Video • DTS-ES Discrete 6.1 and Matrix 6.1
• DTS NEO:6 • DTS • Dolby DIgital • Dolby Digital EX • Dolby Pro Logic
• Neural Surround
Cinema Equalizer
The sound from movie sources recorded in Dolby Digital, DTS or other formats
emphasises high-frequency range due to a theater's front speakers being placed
behind the movie screen. If this sound is reproduced in the home theater without
correction, the high-frequency range is too strong. The AVR-887 features a Cinema
Equalizer to correct these high-frequency components so that the sound is clearer
and easier to listen to. (For Dolby Digital, Dolby Pro Logic I I x, Dolby Digital EX and
DTS surround modes)
Pure Direct mode, for the pure enjoyment of music in high-quality sound
(8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
(8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
(8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
(8 ohms, 20 Hz - 20 kHz, 0.08 % THD)

Video section

HDMI In/Out terminals and repeater function ( Supports 1080p signal)
The AVR- 887 is equipped with 2 HDMI inputs, as well as 1 output, allowing the
selection of multiple digital video signals. The HDMI terminals also accepts multi-channel
digital audio input and the input signals can be output via amps.
Video Up/Down conversion capable of output to HDMI
The AVR-887 includes a video up/down conversion function that allows the unit to
be connected to the video monitor via a single cable regardless of the video input
signal's format as follows:
1) Composite video signals are converted to HDMI, component video, & S-video;
2) S-video signals are converted to HDMI, component video, & composite video;
3) Component video signals are converted to HDMI
Component video circuits which maintain flat response up to 100MHz,
ensuring sharp image quality
3 sets of component video inputs

Connectivity/ Expandability

ASD-1R Control Dock for iPod
when connected to the AVR-887
iPod (*1) playback can be enjoyed through the AVR-887
when the ASD-1R, Denon's original Control Dock for iPod
(sold separately), is connected to the dedicated control ter-
minal of the AVR-887. The iPod can also be controlled via
the remote controller supplied with the AVR-887.
*1) Supports 3rd-generation and later iPods equipped with a Dock connec-
tor. Some functions may not work depending on the generation of the iPod
I I x
and the version of the software.
XM Mini-Tuner Ready*
(Supports XM 5.1ch surround powered by Neural Audio)
*Optional XM Mini-Tuner and subscribes are required.

Auto Setup and RoomEQ with Microphone

The AVR-887 includes an Auto Set-up function that performs basic settings for
the speakers based on frequency response data for the speakers and the lis-
tening room that was measured by a supplied high-performance microphone,
and a Room EQ (equalizer) function that optimizes frequency response character-
istics for the listening room.
®
(option): Supports iPod playback
Black version is also available.
