LBON320AC Series 1.2 GHz Customer Premise RFoG ONU
Installation & Operation Manual

PRODUCT OVERVIEW

• Model: LBON320AC
• Bandwidth: 5-42 MHz/54-1218 MHz; 5-65 MHz/85-1218 MHz; 5-85 MHz/102-1218 MHz; 5-204 MHz/256-1218 MHz
• Powering: 12-15 VDC
Lindsay's RFoG product family includes several optical network units (ONUs). The LBON320AC device is a 1218 MHz, DOCSIS
node that provides the ideal platform for delivering upstream and downstream DOCSIS
LBON320AC ONU includes Automatic Gain Control (AGC), burst-mode return lasers, and optional bandwidth splits.

FEATURES

• Input Optical Wavelength: 1550 nm
• Optical AGC: -6 to +2 dBm
• Thermally stable DFB burst-mode laser
• Transmit Wavelengths: 1310 nm, 1610 nm or CWDM
• Downstream Bandwidth: 54/85/102/256 MHz to 1218 MHz
• Upstream Bandwidth: 5 MHz to 42/65/85/204 MHz
CAUTION
Risk of electric shock. Do not open.
No serviceable parts inside. Refer servicing to qualified service personnel.

FUNCTIONAL SCHEMATIC

SPECIFICATIONS

Parameter
Forward Receiver
Optical Receive Wavelength
Monitor Voltage
Optical Input Power
Frequency Range
(1)
Flatness of Frequency Response
Output Return Loss
Reference Output Level
Slope
Optical Input Return Loss
C/N
(2)
CTB
(2)
CSO
(2)
Invisible laser radiation! Avoid eye injury. Never look into the optical cable or connector.
Specifications
Min
1540-1565 nm
1 V/mW
-6 to +2 dBm
54-1218 MHz
f = fmin-1218 MHz
f = fmin-1218 MHz 16 dB
@ 1000 MHz (± 2 dB)
± 1 dB
45 dB
50 dB
, voice, video and high-speed data services over FTTx applications. The
®
• Output RF Level: 20 dBmV/CH (typ.)
• Total RF Input Level: 20-40 dBmV
• RF Bi-directional Test Point: -20 dB
• Supply Voltage: 12-15 VDC
• Pwr-On, Opt I/P, Opt TX LED indicators
• Optional UPS available
Typ Max
± 1 dB
20 dBmV
6 dB
51 dB
-65 dB
-60 dB
3.1, compact, bi-directional optical
®
