- Page 1 OPERATOR’S HANDBOOK w w w . t t i . c o m . a u PantherPatrol ™ Equipped to Defend Manufacturer of The Safest Tanks in Motion...
-
Page 2: Table Of Contents
TTi’s PantherPatrol HandBook ™ Table of Contents Introduction Risk Assesment Operating Instructions Start Up Procedure Quick Fill Unit Using Pump Maintenance Warranty Warranty Limitations Warranty Registration Card www.tti.com.au Call 1800 816 277... -
Page 3: Introduction
Please carefully read your operators handbook before mounting or using your Fire Attack Unit. Keep your handbook in a safe place. Congratulations on your purchase of a PantherPatrol Fire Fighting Unit which is complete and ready to mount onto a suitable ute or truck. -
Page 4: Risk Assesment
TTi’s PantherPatrol HandBook ™ Risk Assesment Product Information Risk Assessment Sheet TTi - PantherPatrol Unit TASK HAZARDS RISK CONTROL MEASURES • Concentrate on task; • follow safe manual handling techniq ues: • don’t lif t on your own if > 20kg, bend Manual handling;... -
Page 5: Operating Instructions
TTi’s PantherPatrol HandBook ™ Operating Instructions Before First Use 1. Check all hoses, connections and hose clamps to ensure that the unit has been delivered to you without transportation loss or damage. 2. Before attempting any spraying with your new unit, operate it with water only to familiarize yourself with its features and capabilities and to ensure that your sprayer has arrived in a safe working condition. -
Page 6: Start Up Procedure
TTi’s PantherPatrol HandBook ™ Start Up Procedure Prepare the engine for start up as per the engine manual and pump manual. Add the spray solution to the tank (See “Mixing and Filling”). Ensure that the pressure regulator lever is in the ‘open’ position and the pressure adjusting knob is screwed out (anti-clockwise). -
Page 7: Quick Fill Unit
TTi’s PantherPatrol HandBook ™ Quick Fill Unit Aussie pumps are designed for sucking water directly out of dams. The quick fill unit is a quick, environmentally safe way of sucking up water to fill the water tank. When using the quick full unit, 1. - Page 8 TTi’s PantherPatrol HandBook ™ Part No. Description 33-103231 Tank, 15/55(g/L) 33-103230 Tank, 25/95 (g/L) 33-103245 Tank, 40/150 (g/L) 33-103246 Tank, 60/225 (g/L) TL-6B Lid, Tank 33-103234 Harness, Wire, SS, EF1000 Pump, Everflo, 1 GPM EF2200 Pump, Everflo, 2.2 GPM 33-103126...
-
Page 9: Using Pump
6. Open ball valve at tank 7. Start engine and operate until tank is full. Nb. TTi recommend removing tank lid while filling 8. When tank is full turn engine off, close valve at bottom of tank and reverse steps 4 to 2 and unit is ready to use www.tti.com.au... -
Page 10: Maintenance
TTi’s PantherPatrol HandBook ™ Maintenance Maintenance • Service motor & pump in accordance with instructions in the manufacturers manuals as supplied with this Fire Fighting unit • Periodically [at least annually] check all hoses, nozzles and fittings for any sign of wear. -
Page 11: Warranty
Warranty Warranty Policy TTI will, at its option, repair or replace, without charge, any part covered by this warranty which is found to be defective in material and/or workmanship within one (1) year* after date of sale to the original retail purchaser unless the product is used for rental purposes, in which case this warranty is limited to ninety (90) days. -
Page 12: Warranty Limitations
Any and all implied warranties are excluded. b] TTI will not be liable for any incidental, consequential or special damages and/ or expenses in connection with the purchase or use of this equipment, to the extent permitted by law. -
Page 13: Warranty Registration Card
Alternatively if you are unable to register on-line fill in all the details below, copy and email to warranty@tti.com.au or post to the address on the back cover. I have read and understood the instructions in this booklet. Date Purchased:... - Page 14 w w w. t t i . c o m . a u 1800 816 277 sal es@t ti.co m .au PO Box 137, N a t ha l i a , V I C , 3 6 3 8 M ur ra y Valley Hw y, N a t h a l i a , VI C 3 63 8...
