Remove the door cover ⁠ .
6.
Remove the rail ⁠ .
7.
Remove the inner pane
8.
on a flat surface.
Loosen the screw on the left- and right-hand
9.
spacers ⁠ and remove both spacers
Pull out the upper intermediate pane
10.
down carefully on a flat surface.
Pull out the next intermediate pane
11.
down carefully on a flat surface.
and set it down carefully
⁠ .
and set it
and set it
12.
WARNING ‒ Risk of injury!
Scratched glass in the appliance door may develop
into a crack.
Do not use glass scrapers, sharp or abrasive
▶
cleaning aids, or harsh cleaning products.
Clean the removed door panes on both sides with
glass cleaner and a soft cloth.
Clean the appliance door.
13.
→ "Suitable cleaning agents", Page 16
Dry the door panes and refit them.
14.
→ "Installing the door panes for the upper the appli-
ance door ", Page 25
16.8 Installing the door panes for the upper
the appliance door
WARNING ‒ Risk of injury!
The hinges on the appliance door move when the door
is opened and closed, which could trap your fingers.
Keep your hands away from the hinges.
▶
Components inside the appliance door may have sharp
edges.
Wear protective gloves.
▶
Slide in an intermediate pane. When doing so, en-
1.
sure that the number on the intermediate pane is at
the bottom right ⁠ .
Slide the intermediate pane until it is in the left- and
2.
right-hand retainers ⁠ ⁠ .
Push the intermediate pane upwards until it is in the
3.
retainer ⁠ .
Slide in a second intermediate pane. When doing
4.
so, ensure that the number on the intermediate
pane is at the bottom right ⁠ .
