- Page 1 Become part of the M E S O E-Bike Revolution with Owner’s User Manual Division of www.justultrabikes.com...
-
Page 2: Detailed Specifications
MESO FOR THE ULTRA STYLISH COMMUTER DETAILED SPECIFICATIONS Size: 26 Inch Foldable E-bike Frame Material: High-impact alloy aluminium Frame Fork: Aluminium alloy integrated front fork with shock absorber Headset: Integrated sealed headset Head bar: Black Aluminium Alloy head bar Grip: Ergonomical design grip Stem: Black Aluminium Alloy stem Saddle: Ergonomical design E-bike saddle Seat Post: Aluminium matt black seat-post... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION SAFETY INSTRUCTIONS BEFORE YOU RIDE READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT. Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all safety warnings and instructions for future reference and This manual provides important information on proper operation &... - Page 4 IMPORTANT SAFETY INFORMATION IMPORTANT SAFETY INFORMATION The Meso is designed for the ultra style commuter with intended use for paved roads, gravel or dirt roads Keep your E-bike in safe condition! that are in good condition and on bike paths. The Meso is not suitable for extreme mountain biking. Follow the inspection and maintenance guidelines.
-
Page 5: Battery Warning
MESO FOLDING E-BIKE DIAGRAM SETUP: BATTERY & CHARGING BATTERY WARNING • Do not immerse the battery in water • Store in cool, dry environment • Only use the supplied official charger • Do not tamper with the battery case or internal cells for any reason instead consult the supplier •... -
Page 6: Pedal Installation
MESO SETUP: FOLDING METHOD MESO SETUP: PEDALS PEDAL INSTALLATION ENSURE THE MESO IS TURNED OFF BEFORE PROCEEDING • Fold the pedal (Spring clip release is located inside the pedal Pedals come in pairs with “R” and “L” labels (Right and Left). Correctly body). - Page 7 MESO : BATTERY CHARGING MESO : PEDAL ASSIST SYSTEM To maximize the useable life of the battery, charge immediately after riding or when battery is running Your MESO has a pedal assisted drive system. low. The drive assisted system consists of a driving unit, a battery, a controller, and various electronic Attach the charger connector charge slot located on the battery, and the AC connector to a 230V power components (harness wires, sensors and switches).
- Page 8 MESO : SERVICE & MAINTENANCE MESO : SERVICE & MAINTENANCE Some service and maintenance can and should be performed by the owner, and requires no special tools or Tyres information psi pressure indicated on the tyre knowledge beyond what is presented in this manual. Please check tyre pressure regularly.
- Page 9 MESO : TYRE MAINTENANCE MESO GETTING STARTED : MAINTENANCE CHECKLIST Component or Condition Inspect Inspect Clean Adjust or Repair or Flat Tyre before periodically and/or Tighten replace if every ride lubricate necessary If you get a flat tyre, remove the wheel. Depress the tyre valve to let all the air out of the tube. Remove one bead of the tyre from the rim by grasping the tyre at a point opposite the valve stem with both hands Tyre pressure √...
- Page 10 MESO SETUP: TROUBLE SHOOTING MESO SETUP: TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION PROBLEM POSSIBLE CAUSE SOLUTION • Derailleur cables sticking, • Lubricate, tighten or replace Gear shifts not working • Brake blocks worn down • Replace brake blocks Brakes not working effectively properly stretched or damaged cables...
- Page 11 MESO SETUP: TROUBLE SHOOTING MESO SETUP: TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION PROBLEM POSSIBLE CAUSE SOLUTION • Low batteries • Charge batteries for • Loose connectors • Check all connectors Bicycle has reduced range Bicycle has intermittent power • Damaged wires •...
