Summary of Contents for audiomotion electronics JUST ULTRA BIKES EXOS
- Page 1 E X O S Owner’s User Manual Division of www.justultrabikes.com...
- Page 2 EXOS FOR THE EVERYDAY COMMUTER Product Description: 14inch Compact folding E-Bike Frame Material: 6061 bicycle frame Fork: 14 inches Alloy Aluminium Fork Headset: Waterproof Bearing Handset Headbar: Aluminium anodized handlebar Grip: Ergonomical design grip; Stem: Black Aluminium Alloy stem Saddle: Ergonomical high quality saddle Seat Post: Aluminium black seat-post Kick-Stand: Two hole top class kick-stand Paddle: All alloy aluminium paddle...
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION SAFETY INSTRUCTIONS BEFORE YOU RIDE READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT. Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all safety warnings and instructions for future reference and This manual provides important information on proper operation &... - Page 4 IMPORTANT SAFETY INFORMATION IMPORTANT SAFETY INFORMATION The Exos is designed for the ultra style commuter with intended use for paved roads, gravel or dirt roads Keep your E-bike in safe condition! that are in good condition and on bike paths. The Exos is not suitable for extreme mountain biking. Follow the inspection and maintenance guidelines.
-
Page 5: Battery Warning
EXOS FOLDING E-BIKE DIAGRAM SETUP: BATTERY & CHARGING BATTERY WARNING • Do not immerse the battery in water • Store in cool, dry environment • Only use the supplied official charger • Do not tamper with the battery case or internal cells for any reason instead consult the supplier •... - Page 6 EXOS SETUP: FOLDING METHOD EXOS SETUP: PEDALS PEDAL INSTALLATION ENSURE THE XOS IS TURNED OFF BEFORE PROCEEDING Pedals come in pairs with “R” and “L” labels (Right and Left). Correctly tighten the pedals to avoid thread • Fold the pedal (Spring clip release is located damage and personal injury.
- Page 7 EXOS : BATTERY CHARGING EXOS : PEDAL ASSIST SYSTEM To maximize the useable life of the battery, charge immediately after riding or when battery is running Your Exos has a pedal assisted drive system. low. The drive assisted system consists of a driving unit, a battery, a controller, and various electronic Attach the charger connector charge slot located on the battery, and the AC connector to a 230V power components (harness wires, sensors and switches).
- Page 8 EXOS : SERVICE & MAINTENANCE EXOS : SERVICE & MAINTENANCE Some service and maintenance can and should be performed by the owner, and requires no special tools or Tyres information psi pressure indicated on the tyre knowledge beyond what is presented in this manual. Please check tyre pressure regularly.
- Page 9 EXOS : TYRE MAINTENANCE EXOS GETTING STARTED : MAINTENANCE CHECKLIST Component or Condition Inspect Inspect Clean Adjust or Repair or Flat Tyre before periodically and/or Tighten replace if every ride lubricate necessary If you get a flat tyre, remove the wheel. Depress the tyre valve to let all the air out of the tube. Remove one bead of the tyre from the rim by grasping the tyre at a point opposite the valve stem with both hands Tyre pressure √...
- Page 10 EXOS SETUP: TROUBLE SHOOTING EXOS SETUP: TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION PROBLEM POSSIBLE CAUSE SOLUTION Gear shifts not working • Derailleur cables sticking, • Lubricate, tighten or replace Brakes not working effectively • Brake blocks worn down • Replace brake blocks properly stretched or damaged cables...
- Page 11 EXOS SETUP: TROUBLE SHOOTING EXOS SETUP: TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION PROBLEM POSSIBLE CAUSE SOLUTION Bicycle has reduced range • Low batteries • Charge batteries for Bicycle has intermittent power • Loose connectors • Check all connectors and/or speed recommended time •...
