- Page 1 KAMVAS 22 Plus GS2202 User Manual...
-
Page 2: Table Of Contents
GS2202 Contents 1 / Precautions ...........................3 2 / Product Overview ........................4 2.1 Display Introduction ..........................4 2.2 Product and Accessories ........................4 2.3 Setting Up Display ............................8 2.4 Install Driver ..............................8 3 / Pen Basic Operation ........................9 3.1 Hold the Pen ..............................9 3.2 Position the Cursor ............................9 3.3 Click ................................ -
Page 3: Precautions
GS2202 / Precautions 【 Please read this manual carefully before using, and keep it well for future reference. 】 --Before cleaning the display, please unplug the USB cable and wipe with a soft damp cloth, do not use any kind of detergents. --Please don't place the display near water sources such as bathtub, washbasin, sinks, washing machine, damp basement, swimming pool, etc. -
Page 4: Product Overview
/ Product Overview 2.1 Display Introduction ® ® Thanks for choosing HUION KAMVAS 22 Plus creative display. This is a new generation of desktop-level professional drawing display, which can greatly improve your work efficiency of painting and creation, and full of fun. You can freely paint and write, depicting different lines and colors, just as the pen writes on the paper, which brings you a real shock experience. - Page 5 GS2202 2.2.1 Accessories Battery-free pen Replacement Nibs Pen Holder Cleaning Cloth (inside the pen holder) 3-in-1 Cable Power Adapter Power Cable USB-C Cable Warranty Card Quick Start Guide Pen Nib Clip (inside the pen holder) 2.2.2 Adjustable Stand We designed this ergonomic adjustable stand specially for your KAMVAS display, you can adjust the angle of the display according to your usage habit, and make you feel more comfortable when painting and creating.
-
Page 6: Setting Up Display
GS2202 2.3 Setting Up Display [1] Take out the pen display and stand from the package, then assemble the stand to the back of the display with attached screwdriver according to the following instruction. Adjust the stand angle by dragging this switch [2] Connect the pen display to your computer with 3-in-1 Cable or USB-C to USB-C Cable. - Page 7 GS2202 2) Connect the display to your computer with USB-C to USB-C cable; Connect the power adapter to the power cable.
-
Page 8: Install Driver
Windows 7 or later, macOS 10.12 or later. 2.4.2 Install Driver Please download the driver from our website: www.huion.com/download After finishing installation, you can find the driver icon " " in the system tray area, which means the driver was installed successfully; when you connect the display to computer, the icon will change to color "... -
Page 9: Pen Basic Operation
GS2202 / Pen Basic Operation 3.1 Hold the pen Hold the pen as you hold a normal pen or pencil. Adjust your grip so that you can toggle the side switch easily with your thumb or forefinger. Be careful not to accidentally press the switch while drawing or positioning with the pen. -
Page 10: Click
GS2202 3.3 Click Use the pen tip to tap once on the screen to register a click. Tap to highlight or select an item on the screen and double-click to open it. 3.4 Move Select the object, then slide the pen tip across the screen to move it. 3.5 Use the side buttons The buttons on the pen can be set to two different customizable functions. -
Page 11: Pen Nib Replacement
GS2202 3.6 Pen Nib Replacement The nib will be worn off after using for a long time, then you need to replace a new nib. [1] Anticlockwise rotate the pen holder to open the cover, take a new nib out. [2] Insert the pen nib into the pen nib clip and tilt the pen to pull out the old nib. -
Page 12: Function Setting
GS2202 / Function Setting 5.1 Working Area Setting 5.1.1 Using Multiple Monitors Select the Working Area tab to define the relationship between pen movement on the display and cursor movement on the monitor screen. By default the entire active area of display maps to the entire monitor. If more than one monitor is in use and you are in extended mode, you need to choose the related monitor on the driver interface which you are going to map to. - Page 13 GS2202 ① ② ③ 5.1.3 Rotate Working Area By changing the direction of the display to adapt to the left and right hand operation. You can rotate the display by 0°, 90°, 180° or 270°.
-
Page 14: Display Setting
GS2202 5.2 Display Setting Click the " " in the upper right corner of the driver to set the Display, including General settings, Hotkeys and Updates. 5.2.1 General settings Add App: Shortcut key function can be set by adding different programs. When opening different programs, the driver will automatically recognize that the shortcut function is the corresponding function set. - Page 15 GS2202 5.2.2 Hotkeys settings Set the shortcut key to quickly open the driver interface. The default value is Ctrl+Alt+H, which can be set according to usage habits. 5.2.3 Updates You can view the driver version number, click "Check for Update", view the latest driver version, and update according to the system prompt.
-
Page 16: Pen Buttons Function Setting
GS2202 5.3 Pen Buttons Function Setting Select the function to be achieved on the pop-up dialog box, then click "Apply" or "OK" to take effect. 5.4 Enable the Windows Ink Feature Microsoft Windows provides extensive support for pen input. Pen features are supported in such as Microsoft Office, Windows Journal, Adobe Photoshop CC, SketchBook 6 and so... -
Page 17: Pressure Sensitivity Setting
GS2202 5.5 Pressure Sensitivity Setting The pressure sensitivity will be changed by dragging the slider up and down, the smaller the value, the more pressure sensitive. Drag upward (left): the pressure change is more obvious, small pressure produces a great pressure. -
Page 18: Pen Pressure Testing
GS2202 5.6 Pen Pressure Testing You can gradually apply pressure to the stylus on the screen to test the pressure level. Click " " button to clear all the ink. 5.7 Pen Nib Activity Setting The pen nibs can be set to be Active/Inactive as needed.Click the drop-down option to select, and click OK again to save the Settings. -
Page 19: Data Export And Import
GS2202 5.8 Data Export and Import The driver supports exporting and importing your custom configuration data of the product, which is convenient for you to use different software and avoid the trouble of repeated settings. -
Page 20: Specifications
GS2202 / Specifications Model GS2202 Panel Size 21.5 inches Resolution 1920 x 1080 (16:9) LCD Type Active Area 476.64 x 268.11mm Contrast Ratio 1200:1 Screen Brightness 220cd/m2 Response Time 14ms 89°/89° (H) /89°/89° (V) (Typ.) (CR ＞ 10) View Angle Gamut 140% sRGB Display Color... -
Page 21: Trouble Shooting
GS2202 / Trouble Shooting 7.1 Possible Breakdowns Related to DISPLAY Abnormal Phenomena Possible Solutions 1. Make sure power is on. Power indicator does not flash 2. Check the socket and power cable. 1. Make sure power is on. 2. Correctly connect the cables. 3. - Page 22 GS2202 Abnormal Phenomena Possible Solutions 1. It is because you are under extended mode right now. It is a normal situation. 2. If you are not familiar with extended mode, we recommend you to use in Duplicate/Mirror mode. Windows OS: Press keyboard Displays wallpaper &...
- Page 23 There is no pressure in the software when installing the driver. Please uninstall all drivers and graphics software but the close the drawing software, then reinstall the Huion driver. It's better cursor moves to restart your computer after finishing the installation.
