Delta Electronics HCB1060 Specifications

SMT Power Inductor
HCB1060 Type
Features
RoHS compliant.
Low profile, SMD type.
High current.
Magnetic shielded.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
Mechanical Dimension :
B
A
Electrical Characteristics :
HCB1060-271
HCB1060-161
HCB1060-181
HCB1060-211
1. Tolerance of inductance is
2. Isat is the DC current which cause the inductance drop not lower than Li.
3. Irms is the DC current which cause the surface temperature of the part increase less than 45
4. Operating temperature : -20
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
C
E
F
o
At 25 : 100KHz, 1V C
1
L Li
(nH) (nH)
270 216
160 128
180 140
210 160
20%.
O to 105 O ( including self-temperature rise ).
C C
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
D
2.7
10.5 4.0
DCR
(m ) MAX
0.60
0.60
0.60
0.60
116
UNIT : mm/inch
A = 10.00 / 0.394 Max.
B = 8.20 / 0.323 Max.
C = 6.00 / 0.236 Max.
D = 2.20 / 0.087
E = 2.00 / 0.079
F = 4.60 / 0.181
2 3
I
I rms
sat
(Adc) (Adc)
30 40
60 40
52 40
45 40
O
C.
