Delta Electronics GPS-230GB-1 Specifications

DPS-230GB-1

FEATURES

• Application: Desktop PC
• 60mm fan
• Remote On/Off
• Low acoustics noise
• High reliability
• Fan speed control
• Short circuit protection
• Over voltage protection
• Over temperature protection
• Passive PFC to meet EN61000-3-2
CB

Output

Voltage Regulation
V1 +3.3V ±5%
V2 +5V ±5%
V3 +12V ±5%
V4 -12V ±10%
V5 +5Vsb ±5%
1. Total continue power output: 230W
2. The combined power on +3.3V & +5V: 106.2W max
3. The combined power on +3.3V, +5V & +12V: 220W max
All specifications are subject to change without prior notice.
DELTA ELECTRONICS, INC.
3, TUNG YUAN ROAD, CHUNGLI
INDUSTRIAL ZONE
TAOYUAN SHIEH, TAIWAN, R.O.C.
TEL: 886-3-4526107
FAX: 886-3-4527314
mail: powersales@delta.com.tw
Series
125 (W) x 63.5 (H) x 110 (L) mm

ENVIRONMENTAL

• Operating ambient temperature: 10~50 ºC
• Operating relative humidity: 20~85%
• Storage ambient temperature: -20~60ºC
• Storage relative humidity: 5~90%
• Altitude: 10,000~50,000 feet
• MTBF: > 100K hours @ max. load & 25ºC
ambient conditions.
Minimum Maximum
Peak Load
Load Load
0.3A 14.0A -
1.0A 12.0A -
0.5A 13.0A 15.0A
0.05A 0.5A -
0.1A 2.0A 2.5A
DELTA PRODUCTS CORPORATION
4405 CUSHING PARKWAY
FREMONT, CA 94538, U.S.A.
TEL: 1-510-668-5100
FAX: 1-510-668-0680

ELECTRICAL SPECIFICATIONS

INPUT

• Input Range
• Frequency
• Input Current
• Efficiency
• EMI/RFI
OUTPUT
• Maximum Power
• Holdup Time
• Rise Time
• Leakage Current
• Overvoltage Protection: +3.3V, +5V, +12V
• Short-Circuit Protection: Latch off
• Power Good Signal: TTL compatible on delay 100mS
to 500mS, off delay 1mS.
Ripple & Noise
100mV
100mV
200mV
240mV
150mV
DELTA ELECTRONICS(JAPAN) INC.
DELTA SHIBADAIMON BLDG.
2-1-14 SHIBADAIMON, MINATO-KU,
TOKYO, 105-0012, JAPAN
TEL: 81-3-5733-1111
FAX: 81-3-5733-1211
90~264Vac, single phase
47~63Hz
<6A @ 115Vac, <3A @ 230Vac
>65% @ 115Vac
CISPR 22 Class B, FCC, VCCI
230 Watts
>17mS for outputs @ 115Vac
0.1~20mS
<0.75mA @ 220Vac
