Delphi Touch Screen Navigation Radio - TNR800
Purchaser/Installer assumes all responsibility for damages and/or injuries incurred while and after
installing this product. Delphi is not responsible for damages resulting from kits installed incor-
rectly or individuals not following these instructions correctly.
READ ALL INSTRUCTIONS THROUGHLY BEFORE BEGINNING THE INSTALLATION
Do not attempt to install this radio in any application other than those specified. If you do,
there may be radio and vehicle functions that will not work properly.
Items included in the Kit:
•
Navigation Radio
•
GPS Antenna
•
Navigation DVD
•
Miscellaneous Installation Hardware
•
Owner's Manual
DISCLAIMER – WARNINGS
BEFORE YOU BEGIN
•
Eject all CD's from the factory radio. If you
don't, the customer's CDs may be trapped
in the old unit with no way to remove them.
•
Set the Parking Brake! If you don't, the
vehicle could move during this procedure,
causing personal injury or damage to the
vehicle.
•
Turn the ignition key to the Off Locked:
position.
