Summary of Contents for Delphi TNR800

  • Page 2: Table Of Contents

    Digital Signal Processing (DSP) ... 3-5 XM™ Satellite Radio Service ... 3-6 Playing a CD ... 3-10 CD Messages ... 3-12 Playing a CD with the CD Changer ... 3-12 Rear Seat Entertainment System ... 3-15 © 2006 Delphi Corp. Table of Contents...

  • Page 3: Navigation System Overview

    Overview Navigation System Overview...
  • Page 4 Power/Volume Knob. See “Hard Keys” on page 2-1. B. NAV (Navigation) Key. See “Hard Keys” on page 2-1. C. NAV RPT (Navigation Repeat) Key. See “Hard Keys” on page 2-1. D. BAND Key. See “Playing the Radio” on page 3-2. SEEK Key.

  • Page 5: Getting Started

    Overview Getting Started Before you begin to operate the navigation system, read this manual thoroughly to become familiar with it and to understand how the system works. The navigation system allows you to do the following: • Plan a route with provided turn-by-turn route and map guidance with voice prompts. •...

  • Page 6: Setting Radio Station Presets

    Setting Radio Station Presets Press the power/volume knob to turn the audio and navigation system on. Press the BAND hard key to access the band menu and select the desired band. You may choose between AM, FM1, FM2, and XM1, and XM2 (if equipped). Use the tuning knob or the SEEK hard key arrows to select a station.

  • Page 7: Entering An Address, Point Of Interest, Home And Preset Destinations

    Overview Entering an Address, Point of Interest, Home and Preset Destinations Before you enter an Address, Point of Interest, Home or any Preset Destination, you must select the appropri- ate search area that contains the final destination you wish to enter. Your vehicle must be stopped to perform this operation.

  • Page 8: Entering An Address

    Entering an Address 1. Press the power/volume knob to turn the audio and navigation system on. 2. Insert the DVD map disc into the radio CD slot. 3. A notice may appear. Touch the NEXT screen button to proceed. If the radio is already on with a map disc inserted, push the NAV hard key.
  • Page 9 Overview Entering a Point of Interest (POI) 1. Press the power/volume knob to turn the audio and navigation system on. 2. Insert the DVD map disc into the radio CD slot. 3. A notice may appear. Touch the NEXT screen button to proceed. If the radio is already on with a map disc inserted, push the NAV hard key.
  • Page 10 Setting Home Destination 1. Press the power/volume knob to turn the audio and navigation system on. 2. Insert the DVD map disc into the radio CD slot. A notice may appear. Touch the NEXT screen button to proceed. If the radio is already on with a map disc inserted, push the NAV hard key. 3.

  • Page 11: Using Your Home Or Preset Destinations

    Overview Using Your Home or Preset Destinations These destinations are available for selection while driving: 1. Press the power/volume knob to turn the audio and navigation system on. 2. Insert the DVD map disc into the radio CD slot. 3. Touch the DEST screen button. 4.

  • Page 12: Features And Controls

    Features and Controls Using the Navigation System This section includes the basic information you will need to know to operate the navigation system. The main navigation menu displays a number of options which offer information on a variety of topics. See Nav- igation Menu on page 2-8 for more information.
  • Page 13 Hard Keys (continued) NAV (Navigation): If you are in a menu and are not on the map screen, press the NAV key to view the map showing current vehicle position. If a route has not been planned, pressing this key will display the map screen and the following information: •...
  • Page 14 BAND: Press the BAND key to access the BAND screen and switch between AM, FM1, FM2, XM1, or XM2, if equipped. See “Finding a Station” on page 3-2. SEEK Press the SEEK up or down arrows to go to the next or previous radio station and stay there. See “Finding a Station”...

  • Page 15: Touch-Sensitive Screen Buttons

    Features and Controls Touch-Sensitive Screen Buttons Touch-sensitive buttons are located on the navigation screen. When you have successfully selected a but- ton on the screen, a beep will sound. This feature can also be turned off. See Configure Menu on page 2-38 for more information.
  • Page 16 (Zoom In): Touch this screen button to get a closer look at a smaller section of the map you are traveling on. (Zoom Out): Touch this screen button to see a larger scale of the map you are traveling on. You can also view your highlighted route.

  • Page 17: Maps

    Maps The maps are stored on a DVD-ROM. The contiguous United States, parts of Hawaii, and Canada are contained on one disc. The map database includes interstate freeways, state highways, country roads, and major and general streets. Refer to the “Navigation System Map Disc” manual to view the explanation of map coverage.

  • Page 18: Symbols

    Symbols The following symbols are the most common that ap- pear on a map screen. Your vehicle is shown as this symbol. It indicates the cur- rent position of your vehicle on the map. This red bulls-eye symbol will appear on the map to show your destination after a route has been planned.

  • Page 19: Navigation Menu

    Features and Controls Navigation Menu (Navigation Menu): Touch the navigation menu symbol screen button at the bottom of the map screen to access the main navigation menu. The main navigation menu allows you to choose from a list of options and to use the available touch screen buttons to make system adjustments and plan routes.

  • Page 20: Route Overview

    Features and Controls Route Overview Selecting the Route Overview screen button will show the map with the route highlighted. The total distance and estimated travel time are also displayed. Map Appearance Selecting the Map Appearance screen button allows you to ad- just the appearance of a map based on your preferences.
  • Page 21 Map Appearance (continued) Single: This feature allows one map to be displayed. Split Screen: This feature allows two maps to be displayed, which can be independently adjusted in both scale and map orientation. For more information on the symbols that can appear on a map screen, see Symbols on page 2-7. 2-10 Features and Controls 3D view: This feature gives maps a 3-dimensional view, and...

  • Page 22: Voice Volume

    Voice Volume Selecting the Voice Volume screen button allows you to adjust the volume of the voice guidance prompts that provide various messages as you approach points where you need to maneu- ver your vehicle, such as an intersection. To adjust the volume of the voice prompts you receive from the system, do the following: 1.

  • Page 23: Edit Route

    Features and Controls Edit Route Selecting the Edit Route screen button allows you to recalculate a route based on your preferences. Condition: The Search Condition screen allows you to select your route preference by choosing from Fastest, Shortest, or Alternative route. By selecting the Fastest route, you will be routed along main roads and highways, which does not nec- essarily mean it will be the shortest route.

  • Page 24: Route Preview

    Route Preview Selecting the Route Preview screen button once route guidance has begun will display the map screen with the route highlighted. The route is traced by the vehicle symbol as you travel. You can preview the route from the starting position to the final destination by touching the arrow screen buttons inside the Route Preview pop-up menu.
  • Page 25 To return to previewing the route to the final destination, do the following: 1. Touch the Edit screen button. 2. Touch the Next screen button. 3. Touch the OK screen button, then the Back screen button to return to the Route Preview screen. Now when you touch the arrow screen buttons to preview the route, it will trace the route to the final desti- nation rather than the route to the next POI.

  • Page 26: Navigation Setup

    Features and Controls Navigation Setup Selecting the Nav Setup screen button will display the Nav Setup menu. From this menu, several options may be se- lected, adjusted, or turned on and off. Touch the up or down arrow screen buttons to the left of the menu options to scroll through the list.
  • Page 27 Features and Controls Navigation Setup (continued) Enter Speed Change?: This feature allows you to adjust esti- mated speeds for Freeway, Main street, or Residential driving. These speed values are used to calculate estimated travel time. To change estimated speeds, touch the Yes screen but- ton.
  • Page 28 Features and Controls Exit Information: This feature will display map icons which can be selected to display the next exit’s informa- tion, including Point of Interest (POI) facilities such as gas stations, restaurants, and lodging. Touch the On screen button to display exit information icons, or touch the Off screen button to cancel the display of exit information icons.

  • Page 29: Memory Points

    Features and Controls Memory Points Touching the Memory Points screen button will display the Memory Points menu. This menu contains options for register- ing, deleting, and editing marked points stored in memory, such as memory points, preset destinations, and areas to avoid. Memory Points: Choosing to add a memory point will take you to the Destination menu.
  • Page 30 Features and Controls Register Home: Touch this screen button to get access the Register Home screen. Choose a method of des- tination entry and enter the destination you would like to store as home. Once your entry is complete, touch the Register Point screen button to store this point as home.

  • Page 31: Destination

    Destination The Destination menu will give you several ways to plan a route by entering destination points. Touch Dest at the bottom of the map screen to display the Destination menu. Destination Button 2-20 Features and Controls...
  • Page 32 Features and Controls Search Area: The Destination menu allows you to select the area to be searched for your destination. A map of the United States, including Hawaii, and Canada will be shown. The map is divided into 9 regions. Before selecting a destination, review the search area map on the right side of the menu to make sure your destination is located in the highlighted region.

  • Page 33: Preset Destinations

    Features and Controls Preset Destinations The preset destination entry method allows you to select destina- tions that were registered as presets 1 through 5. These presets, along with the home symbol preset, are located at the bottom of each page of the Destination menu. Besides the home preset destination and Emergency destination entry method, these are the only presets available for selection while the vehicle is moving.
  • Page 34 Features and Controls Touch a character on the screen to select it. You may also touch the 0 - 9 screen button at any time from the alpha keypad to reach the numeric keypad. (Space): Touch this screen button to enter a space between characters or the words of a name. (Backspace): Touch this screen button if you have selected an incorrect character.
  • Page 35 Features and Controls Address The Address destination entry method allows you to input an address by providing the system with a house number, street name, and city. If you know the city where the address is located, touch the City screen button. The City screen allows you to select from the last five cities entered, the Nearest five cities to the cur- rent location, or you may enter in the name of the city.
  • Page 36 Features and Controls As information is entered, the system will automatically search for available names, and the List screen button will become available. Touch the List screen button to view name choices and select the desired street name, or touch the Back screen button to continue to spell the street name, further reducing the number of available items.

  • Page 37: Point Of Interest (Poi)

    Point of Interest (POI) The Point of Interest (POI) destination entry method allows you to choose a destination from the POI list. Selecting the POI screen button from the Destination menu brings up the POI entry menu. The POIs in the database are cross refer- enced between Name, Category, and City.
  • Page 38 Features and Controls If an arrow appears to the right or left of the item name, the complete name is too long for the display. Touch the right or left arrow screen buttons to scroll to the end or beginning of the name. The POI for Restaurant is broken down into several distinct categories.

  • Page 39: Previous Destination

    Features and Controls Previous Destination The Previous Destination entry method allows you to select a destination by choosing from a list of previously entered destinations. Touch the number next to the desired previous destination to select it. Emergency The Emergency destination entry method allows you to select a destination by choosing from a list of emergency facilities.

  • Page 40: Previous Start Point

    Features and Controls The Map destination entry method displays the last location on the map, and the road preference. Scroll across and touch the map at the location you would like to set as your destination. Once you have located the desired destination, touch the Enter Destination screen button and then the OK screen button. The route will then be calculated.
  • Page 41 Features and Controls Phone Number The Phone Number destination entry method allows you to search for a point of interest (POI) destination by entering the POI phone number. Enter the POI phone number on the numeric keypad and touch the OK screen button. The destina- tion location will then be displayed.

  • Page 42: Freeway Entrance/Exit

    Features and Controls This will bring up a list of streets with that name. Select the desired street name from the list. Now begin entering the second street name, and choose the desired street name from the list. After both street names in the intersection have been selected, a list of cities containing the selected intersection will appear.

  • Page 43: Destination Preview Menu

    Features and Controls Destination Preview Menu Each time a destination is entered, a screen with the destination preview menu will appear. This screen will display a zoomed in view of the destination, as well as the following options: Enter Destination: Touch this screen button to enter the current destination as the only destination in the system.
  • Page 44 Info (Information): When a POI icon is selected on the screen, you can touch this screen button to display the name, address, and telephone number, if available, for the selected POI. See “Navigation Options” later in this section for more information on POIs and their icons. Route Preference: This option will display the Route Preference screen.

  • Page 45: Route Overview Menu

    Features and Controls Route Overview Menu Each time a destination has been selected and entered, the route overview menu can be displayed by touching the Route screen button on the map screen. The following three options will be displayed: Start: This option will choose the current highlighted route, and begin route guidance.

  • Page 46: Navigation Options

    Features and Controls Navigation Options Once you select a destination and begin your route, you can touch the Nav Options screen button at the bottom of the map screen to view a menu with additional route options. Choose from the following route options: POI Icon Off: This option allows you to turn off Point of Inter- est (POI) icons shown on the map.
  • Page 47 The Local POI List screen will list the closest POIs from the categories you have selected. You can sort these POIs by dis- tance, icon/category, or name. You can also touch the Route screen button to display POIs along your current route. Once you select the desired POI, a map of the area with a symbol marking the destination will be displayed.
  • Page 48 Features and Controls Right Screen: If you currently have a split-screen, this option allows you to adjust options for the screen to the right. If the position on the map is away from the current vehicle position and you touch the Nav Options screen button, you will only have the following four options: POI Icon Off: This option allows you to turn off Point of Inter- est (POI) icons shown on the map.

  • Page 49: Colors On The Screen

    Features and Controls Colors on the Screen When a route has been planned, it will be highlighted on the screen in blue. Different colors are also used to distinguish between interstate freeways, state highways, county roads, major streets and secondary streets. Highways will be shown as a thicker line than a general street.

  • Page 50: Screen Color

    Features and Controls Screen Color When the exterior lamps are on, the navigation screen will change to a lighter background and change colors for better viewing in the daytime. At night, the screen will go to a darker background. Touch the Auto screen button for automatic adjustment.
  • Page 51 Language Your vehicle has been set for the English language, but you may also select French for all instructional text and voice prompts. However, names on the map when using the navigation functions will not change. If you wish to change the language, the map DVD must be inserted. Then, do the following: 1.

  • Page 52: Display Off

    To change the hours and minutes on the clock, do the following: 1. Touch the Manual Adjust screen button. 2. Touch the up or down arrow screen buttons to increase or decrease the hours and minutes. 3. Touch the Back screen button to return to the previous screen. 12Hr/24Hr: This feature allows you to choose whether the time is displayed in standard or military time.

  • Page 53: Global Positioning System (Gps)

    Global Positioning System (GPS) The navigation system determines the position of your vehicle by using satellite signals, various vehicle sig- nals and map data. The Global Positioning System (GPS) locates the current position of your vehicle using signals sent by the United States Department of Defense GPS satellites.

  • Page 54: Vehicle Positioning

    Vehicle Positioning At times, the position of the vehicle on the map may be inaccurate due to one or more of the following reasons: • The road system has changed. • The vehicle is being driven on winding roads or on a long straight road. •...

  • Page 55: Problems With Route Guidance

    A road is new, was recently changed or is not listed on the DVD. The route to the destination may not be shown. See Ordering Map DVDs below If the System Needs Service Return to the point of installation or contact Delphi Customer Service at 877-667-8700. Ordering Map DVDs Go to www.shopdelphi.com or contact Delphi Customer Service at 877-667-8700.

  • Page 56: Database Coverage

    Features and Controls Database Coverage Explanations Coverage areas vary with respect to the level of map detail available for any given area. Some areas will fea- ture greater levels of detail than others. If this happens, it does not mean there is a problem with the system. As the map DVD is updated, more detail may become available for areas which previously had limited detail.
  • Page 57 Features and Controls NOTES: 2-46...

  • Page 58: Navigation Audio System

    Navigation Audio System Notice: Before adding any sound equipment to your vehicle, like a tape player, CB radio, mobile telephone, or two-way radio, make sure that it can be added by checking with your point of installation. Also, check federal rules covering mobile radio and telephone units. If sound equipment can be added, it is very important to do it properly.

  • Page 59: Finding A Station

    Finding a Station BAND: Press this hard key to access the BAND screen and to switch between AM, FM1, FM2, XM1, and XM2, if equipped. Tuning Knob: Use the tuning knob on the lower left corner of the navigation system to choose a radio TUNE station.

  • Page 60: Setting Preset Stations

    Navigation Audio System Setting Preset Stations Up to 30 stations, six AM, six FM1, six FM2, six XM1, and six XM2, if equipped, can be programmed using the six screen buttons on the bottom of each band menu. To set preset stations, do the following: 1.
  • Page 61 Navigation Audio System This audio screen will display the current audio information, such as band and station. You can touch this smaller band menu screen button to bring up the full band menu. (Audio): Press this hard key to display the audio menu. Several options are available for adjustment from this menu.

  • Page 62: Digital Signal Processing (Dsp)

    Navigation Audio System Digital Signal Processing (DSP) If your vehicle is equipped with DSP, you have a choice of four different listening experiences. DSP can be used while listening to the audio system or the CD player. You can choose from the following DSP settings: Normal: Touch this screen button to adjust the audio to deliver all occupants the best possible sound quali- ties.

  • Page 63: Xm™ Satellite Radio Service

    Navigation Audio System This system relies on receiving specific information from these stations and will only work when the informa- tion is available. In rare cases, a radio station may broadcast incorrect information that will cause the radio features to work improperly. If this happens, contact the radio station. While the radio is tuned to an RDS sta- tion, the station name or call letters will appear on the display instead of the frequency.
  • Page 64 Navigation Audio System XM™ Options (if equipped) Touch the XM Options screen button to access the XM Op- tions menu. This menu allows you to seek or scan for stations based on their category. Touch the On screen button next to XM Info Timeout to hide XM™...
  • Page 65 Radio Display Condition Message XL (Explicit Language XL on the radio display, Channels) after the channel name, in- dicates content with explicit language. XM Updating Updating encryption code No XM signal Loss of signal Loading XM Acquiring channel audio (after 4 second delay) Channel Off Air Channel not in service Channel Unavail...
  • Page 66 Navigation Audio System Radio Display Condition Message No CAT Info Category Name not avail- able Not Found No channel available for chosen category No Information No Text/Informational mes- sage available XM Radio ID Radio ID label (channel 0) Unknown Radio ID not known (should only be if hardware failure) Check XM Receiver...

  • Page 67: Playing A Cd

    Navigation Audio System Playing a CD Remove the navigation map DVD from the slot and return it to its case. Insert a CD partway into the slot, label side up. The player will pull it in. There will be a 12 to 15 second delay while the CD is read, before it begins to play.
  • Page 68 Navigation Audio System Repeat: Touch this screen button to repeat the track that is currently being played. Touch it again to turn this feature off. (Forward): Touch this screen button to advance quickly within a track. As the CD advances, elapsed time will be displayed to help you find the correct passage.

  • Page 69: Cd Messages

    Navigation Audio System CD Messages CD ERROR: If this message appears on the screen, the CD is not being read by the system. The CD could be dirty, scratched, wet, or upside down. You may also be driving on a very rough road. When the road be- comes smoother, the CD should play.
  • Page 70 Navigation Audio System Random: Touch the Random screen button for less than two seconds to play the tracks on the current disc in random, rather than sequential, order. Touch it again to turn off random play. When Random is touched for more than two seconds, the player selects D.
  • Page 71 Navigation Audio System Track Scan: To use this function, press and hold the SEEK key for at least two seconds, but less than four seconds, at which time a single chime will sound to alert you that the CD changer has entered TRACK SCAN mode for the current CD.

  • Page 72: Rear Seat Entertainment System

    Navigation Audio System Rear Seat Entertainment System Your vehicle may have a DVD Rear Seat Entertainment (RSE) system. While playing a DVD or audio CD in the RSE, press the CD key to view the RSE screen and to switch to DVD as your main audio source.
  • Page 73 Navigation Audio System RSE ERROR: If this message appears on the navigation screen, the RSE system is not working properly. See “DVD Messages” under “Rear Seat Entertainment System” in the index of your vehicle’s owner manual for more information. NO DISC: If this message appears on the navigation screen, the DVD slot is empty. Insert a DVD or CD. The DVD or CD should play.
  • Page 74 Navigation Audio System Index Audio System ...3-1 Colors on the Screen ...2-38 Database Coverage Explanations ...2-45 Destination ...2-20 Rear Seat Entertainment System ...3-15 Getting Started, Navigation ...1-4 Global Positioning System (GPS) ...2-42 Maps ... Menu Navigation ...2-8 Navigation ... 1-2, 1-4 Menu ...2-8 Using the System ...
