Motion sensor (optional)
Adding a motion sensor (optional) allows a more powerful lighting during 30s
when motion is detected. This solution aims to combine a strong lighting power
with a long autonomy.
Settings are set at the factory. The number of detections depends on chosen
lighting profile (contact us for further informations) and the detection will stop
if the level of energy left in the battery goes below 20%.
LED
100%
20%
0%
Diagram 2:
Example of lighting profile
Technical characteristics:
Detectable difference in temperature between the target
and background is more than 4°C (7,2°F)
Movement speed: 2,6 to 3.2 fps
Detection object = human body
(minimal size is 27,5 in. x 9,8 in.)
© 2020, Sunna Design, Inc.
3h
MOTION DETECTION
DAY NIGHT
iSSL+, v5, SL4100
USER MANUAL
1h
DAY
10
