- Page 1 Maxi USER MANUAL solarlighting.com © Sunna Design, Inc. 2020 – Sunna Design reserves the right iSSL Maxi, v5, SL4200-Z10073-00_A to modify the information in this document. USER MANUAL...
- Page 2 Maxi, v5, SL4200 USER MANUAL SOL thank you for choosing iSSL Maxi Solar Street Light and hope it will give you satisfaction.This manual will familiarize you with the features and operation standards of SOL’s iSSL Maxi Solar Street Light.
- Page 3 Do not open the product without formal written authorization from Sunna Design, Inc., as this will invalidate the warranty. Changes or modifications to Sunna Design, Inc. equipment not expressly approved by Sunna Design, Inc. could void the user’s authority to operate the equipment as well as its warranty.
-
Page 4: Parts List
Maxi, v5, SL4200 USER MANUAL Parts list For safety reasons, please ensure that every element is correctly attached and tightened on the product. Necessary tools (not included) 0,15 in. Allen key 0,5 in. socket wrench © 2020, Sunna Design, Inc. -
Page 5: Available Models
Maxi, v5, SL4200 USER MANUAL Available models iSSL Maxi ROAD iSSL Maxi AREA © 2020, Sunna Design, Inc. - Page 6 Maxi, v5, SL4200 USER MANUAL Checkpoints • Pole iSSL Maxi is designed to fit on standard poles. Diameter at the top of the pole ø 2,36 in. +/-0.04 60mm +/- 1,2 should be 2.36 in. Tolerance is ±0.04 CAUTION ! Poles have to be chosen 4 in.
-
Page 7: Installation Steps
Maxi, v5, SL4200 USER MANUAL Installation steps Bracket installation Spigot installation © 2020, Sunna Design, Inc. - Page 8 Maxi, v5, SL4200 USER MANUAL LED optical ajustment Adjust the tilt according to the area to light up Locking on pole © 2020, Sunna Design, Inc.
-
Page 9: Start-Up Steps
Maxi, v5, SL4200 USER MANUAL Start-up steps Start-up Initialization LED status © 2020, Sunna Design, Inc. - Page 10 Maxi, v5, SL4200 USER MANUAL Calibrage / Calibration During commissioning, your product will initialize itself. The aim of this step is to calibrate the product so that you can enjoy its optimal performance. To that end, the product will fully discharge the battery before initiating a normal charge cycle.
-
Page 11: Maintenance
Maxi, v5, SL4200 USER MANUAL Description status LED Status LED : Display & warning function Green LED Orange LED Red LED Description Initialization Flash Day detected Flash Night detected Flash Bluetooth connected : if connected, no other status displayed... - Page 12 Maxi, v5, SL4200 USER MANUAL Motion sensor (optional) Adding a motion sensor (optional) allows a more powerful lighting during 30s when motion is detected. This solution aims to combine a strong lighting power with a long autonomy. Settings are set at the factory. The number of detections depends on chosen lighting profile (contact us for further informations) and the detection will stop if the level of energy left in the battery goes below 20%.
-
Page 13: Troubleshooting
Maxi, v5, SL4200 USER MANUAL Troubleshooting EVENT STATUS OF DIAGNOSTIC CAUSE SOLUTION INDICATOR LED LED MODULE Product OFF Switch not engaged Switch on the switch DOES NOT (the HMI LED will light TURN ON AT BOOT OR * FLASH... - Page 14 ADDRESS : Sunna Design, Inc. 990 Biscayne Boulevard, Office 701 Miami, FL 33132 – USA sales@solarlighting.com toll free: (800) 959-1329 solarlighting.com © Sunna Design, Inc. 2020 – Sunna Design reserves the right Z10073-00_A to modify the information in this document.
