- Page 1 Issue: 1 Description: ROBINHOOD SUPERTUB SLIM SERIES 3 DRAWER MODEL WITH S/S TAP Model Number: ST7003SLIM Model pictured: ST7003SLIM All dimensions in mm; Model may vary slightly from images pictured...
- Page 2 Allow 10mm clearance between the units. Mark the position on the floor as reference. Important safety information This Robinhood Supertub is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the Robinhood Supertub.
- Page 3 Installing the Supertub Confirm if the washing machine waste inlet needs to be moved from right to left before securing the unit to the wall. If they do need to be changed see page 6 of these installation instructions. Fit the four adjustable feet supplied to the bottom of the cabinet and adjust to align with worktop or washing machine height.
- Page 4 Installing the washing machine water inlet and waste outlet Washing machines hoses Some parts are hidden for clarity Confirm if the washing machine waste inlet needs to be moved from right to left before securing the unit to the wall. If they do need to be changed see page 6 of these installation instructions. Cold water washing machine required, identify cold water 3 way ball valve confirm that the valve is shut horizontal and remove the ¾”...
- Page 5 Note: The Cabinet Drawers’ maximum loading capacity is 30kg evenly distributed 1. The handles are to be connected to all two drawers of the Robinhood laundry tub. 2. To fix handle to the drawer, firstly clear the existing holes from the front using the screws supplied.
- Page 6 Changing the washing machine inlet from right to left The washing machine outlet waste hose can be connected to either side of the Robinhood Supertub. On the outside of the laundry tub, remove the screws from the white plastic washing machine waste inlet and the white plastic blanking plate.
- Page 7 The product was not used, cleaned or cared for in accordance with our instructions. The product was used outdoors. All Robinhood rangehoods are suitable for indoor use only, and not suitable over BBQs or charcoal cookers designed for outdoor use.
