KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION
Elegance collection
user guide
S10SB-A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elegance S10SB-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kharma Elegance S10SB-A

Summary of Contents for Kharma Elegance S10SB-A

  • Page 1 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Elegance collection user guide S10SB-A...

  • Page 2: Safety Instructions

    KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Safety instructions IMPORTANT SAFETY INSTRUCTIONS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, WARNING! DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated Important «...
  • Page 3 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Safety instructions IMPORTANT SAFETY INSTRUCTIONS – ELEGANCE ACTIVE VERSION Please read all instructions carefully and completely before operating your active Elegance. Always disconnect AC power before connecting or disconnecting any cables, or when cleaning any component This product uses a three conductor power cord, which in cludes an earth-ground connection.

  • Page 4: Table Of Contents

    KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Table of content Safety instructions Preface Introduction to the Elegance Collection Part list Unpacking Connect your subwoofer Control subwoofer Subwoofer placement Room acoustics Positioning subwoofer Using your Kharma Subwoofer Specifications Warranty Warranty coverage Warranty exclusion...

  • Page 5: Preface

    KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Preface Congratulations, You are now a Kharma Loudspeaker Owner. Your new Elegance subwoofer, properly installed, will give you all the satisfaction and enjoy- ment you expect from Kharma. Technically at the fore-front of current loudspeaker design, the Elegance will reveal the full emotional range of music and will do so with vivid dynamics and detail.

  • Page 6: Introduction To The Elegance Collection

    All of these innovations are very clearly audible in even a short listening session. Better detailed bass, incredible During the past years Kharma has been researching new detail base actually. Ultra high resolution in the midrange technologies as how to improve and set a new standard depicting many layers and sound colours like in excel- again to the high-end audio world.

  • Page 7: Part List

    KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Part list Each box contains: Elegance Subwoofer 4 x Spike disc Standard power cord Besides you have also received: 1 x Manual 1 x Burn-in CD Important Please read the manual thoroughly before taking further steps.

  • Page 8: Unpacking

    KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Unpacking Opening the box Upon opening the box, inspect the speakers carefully for any sign of transit-damage. If there is damage, immediately call your dealer or the trucking firm that made the delivery. Do not delay in reporting the dam- age.
  • Page 9 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Step 2: Turn box upside down Carefully turn the box upside down and lift up the cardboard box. Step 3: Remove bag, foam and place spike discs...

  • Page 10: Connect Your Subwoofer

    Mixing different types and/or lengths of speaker cable can upset the precise timing and balance of your speaker. We recommend use of our own Kharma (KIC) pure silver-gold interlink cable for maximum result. Always turn off the power of your entire system before making Important connections to your speakers.
  • Page 11 LAN Connection The Elegance Subwoofer can be controlled wireless with the iPad app: Kharma Control. Therefore the iPad must be on the same network as the subwoofer. Hence the LAN connector on the back of the subwoofer should be connected to the same router / switch that provides the Wifi signal used on the iPad.
  • Page 12 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Standalone Network When it is prefered to have a dedicated network for the Elegance Subwoofer, an easy way to control the subwoofer via the iPad is explained below. The Apple Airport Express can setup a dedicated Wi-Fi network for the subwoofer that needs a cabled LAN connection.
  • Page 13 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION 1. Create a new network and give the network a name and password 2. The network setup is completed 3. The Elegance subwoofer can now be detected in the iPad app: Kharma Control.

  • Page 14: Control Subwoofer

    When no device becomes visible in the app, please check the network configurations. Opening app The Kharma Control app opens with the below image. This will be visible for a short time, before any device can be controlled.
  • Page 15 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Device selection The Device Selection shows which unit is detected in the network. Hence the subwoofer must be connected to the same network as the iPad. When the module is detected in the network, the following functions are available: •...
  • Page 16 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Demo Mode Under the settings menu in device selection, their is a demo mode available. The demo mode gives the option to interact with three different devices without having a real device available. Demo Mode...
  • Page 17 The preset menu is intended to give basic settings during installation and to access custom presets. The basic settings can be found under button Kharma 1 to 5. The “Custom..” button will hold a list of local saved custom presets.
  • Page 18 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Sub menu When the “Sub” button in the left frame is used, all subwoofer control parameters become visible. These can be subdivided in the functional blocks illustrated below. Filter graph Subwoofer volume Phase settings PEQ points...
  • Page 19 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Subwoofer volume The subwoofer volume can be controlled from 0 to 100% by using the slider or the entry field. When using the entry field, please be aware that the vol- ume will jump to the entered value. The mute button can be used to silence the connected subwoofers.
  • Page 20 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION High-pass filter: A high-pass filter (HPF) can be set by enabling or disabling the filter with the trapezium button. The filter is enabled when the button is brown. An entry field can be used to set the cut-off frequency. There are three different filter types to choose from: Bessel, Butterworth and Linkwitz-Riley.
  • Page 21 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION PEQ points Besides the LPF and HPF, also 5 parametric equalizer (PEQ) points can be used to filter the subwoofers. These 5 individual PEQ points can be set by using the entry fields indicated below or making use of the interactive graph of the filter.
  • Page 22 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Filter graph The filter graph shows as well the individual PEQ points as the effective filter that is applied to the audio signal. The effective filter is shown by the white line and is a summation of the LPF, HPF and PEQ points that are enabled.
  • Page 23 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Save custom preset: With the “Save” button, a custom preset can be stored under a particular name. The preset will save all current parameters: PEQ points, LPF, HPF, volume and phase. The saved preset can be found by switching to the preset menu and use the “Custom..”...

  • Page 24: Subwoofer Placement

    KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Subwoofer placement Room acoustics A good listening room has just the right amount of reflection and absorption. The performance of any loudspeaker depends upon the speaker’s lo- cation in the room and the acoustical conditions in that part of the room. Furnish- ing, size and proportions all effect tonal balance, imaging and bass characteristics.

  • Page 25: Positioning Subwoofer

    KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Positioning subwoofer As mentioned above we recommend experimenting with the Elegance sub- woofer placement in order to obtain the best spectral balance, openness and perception of depth. For good results, the speakers should be no closer than 20cm from the rear wall and at least 20cm from the side walls.

  • Page 26: Using Your Kharma Subwoofer

    If you have been unsuccessful in locating the specific source of trouble or if you have located it, but have been unable to correct it, please consult the Authorized Kharma-dealer from whom you purchased the system. Kharma Dealers are audio specialists and can be of great assistance.
  • Page 27 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Specifications S10SB-A 10” active subwoofer System Features High pass and low pass filtering 5 Parametric equalizer points Phase control Latency 600 microseconds only Mixed-mode 64 bits digital processing 5 Factory presets Up to 40 custom presets...

  • Page 28: Warranty

    In case of malfunction the customer has to present the Kharma product in its original packing to an authorized dealer. If qualified service appears inevitable, the dealer will ship the product to an appointed service station or to the factory, depending on the required service.
