LED TV
SERVICE MANUAL
CHASSIS : LB9KB / LG9KB
MODEL : 43LT340C0TB
CAUTION
BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL71433001 (1904-REV00)
Copyright © 2019 LG Electronics Inc. All rights reserved. Only training and service purposes.
43LT340C0GB
CONFIDENTIAL

Advertisement

Table of Contents
loading

Related Manuals for LG 43LT340C0TB

Summary of Contents for LG 43LT340C0TB

  • Page 1 SERVICE MANUAL CHASSIS : LB9KB / LG9KB MODEL : 43LT340C0TB 43LT340C0GB CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. P/NO : MFL71433001 (1904-REV00) Copyright © 2019 LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 2 SPECIFICATION ..................6 SOFTWARE UPDATE ................9 BLOCK DIAGRAM ................. 10 EXPLODED VIEW .................. 11 DISASSEMBLY GUIDE ................13 TROUBLE SHOOTING GUIDE ..........APPENDIX - 2 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 3: Safety Precautions

    When the exposed metal has no return path to the chassis the reading must be infinite. An other abnormality exists that must be corrected before the receiver is returned to the customer. - 3 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 4: Servicing Precautions

    - 4 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 5 1. Clip each fuse or resistor lead at top of the circuit board hollow stake. 2. Securely crimp the leads of replacement component around notch at stake top. - 5 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 6: Specification

    : 1/2, 2/5, 2/3, 3/4, 5/6 16-QAM : 1/2, 2/5, 2/3, 3/4, 5/6 64-QAM : 1/2, 2/5, 2/3, 3/4, 5/6 256-QAM : 1/2, 2/5, 2/3, 3/4, 5/6 - 6 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 7: Component Input

    1360*768 47.712 60.015 85.50 VESA (WXGA) 1280*1024 63.981 60.020 108.0 VESA (SXGA) 1920*1080 66.587 59.934 138.5 HDTV 1080P 1920*1080 67.50 60.00 138.5 HDTV 1080P - 7 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 8 1920*1080 27.00 24.00 74.25 HDTV 1080P 1920*1080 26.973 23.976 74.175 HDTV 1080P 1920*1080 33.75 30.00 74.25 HDTV 1080P 1920*1080 33.716 29.976 74.175 HDTV 1080P - 8 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 9: Auto Download

    (2) Enter a four digit password and press OK button. (The TV is set with the initial password “1-1-0-5”.) (3) Select “TV Manager” - “Ez Download”. - 9 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 10: Block Diagram

    BLOCK DIAGRAM - 10 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 11 It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer. - 11 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 12 EXPLODED VIEW (MODULE) IMPORTANT NOTICE MRC use only * MRC : Module Repair Center - 12 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 13: Disassembly Guide

    1. Unlock screws (“1”: 5 EA, ”2”: 2 EA, “3”: 1 EA) to separate back cover assembly from module. Detach the Side AV Label(“4”). (Push the LATCH) 2. Detach the Tape(“5, 6”). - 13 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 14 3. Separate connectors (“7”) from Main/Power PCB and module. Separate Speaker(“8”: 2 EA) from module. 4. Unlock screw (“9”: 10 EA) to separate from module. - 14 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.
  • Page 15 (Disassemble ⓑ→ⓐ) 6. Unlock screw(“12”: 4 EA) to separate vesa Detach the supporter(“13”: 4 EA) ⓑ ⓑ ⓐ ⓐ (Assemble the screw after insert ⓐ→ⓑ) - 15 - Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes.

  • Page 16: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 17 E. Noise Circuit noise, mechanical noise F. Exterior error Exterior defect First of all, Check whether there is SVC Bulletin in GSCS System for these model. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 18 ☞A4 & A2 Always check & record S/W Version and White Replace Main Board Re-enter White Balance value Balance value before replacing the Main Board Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 19 ☞A18 Check various Check and No Video/ Normal voltages of Power replace No audio voltage? Board (13.2V…) MAIN B/D Replace Power Board and repair parts Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 20 1. Reconnection 2. Install Booster S/W Upgrade Contact with signal distributor Normal or broadcaster (Cable or Air) Picture? Normal Picture? Replace Main B/D Close Close Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 21 Replace Main/T-con B/D error cable normal Request repair for external device/cable Check external External HDMI device and Replace Main/T-con B/D device/Cable error cable normal Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 22 (Check normal operation of HDMI/ Screen Normal Main /T-con External Input, Component, screen? normal? RGB and HDMI/DVI by connecting Jig, pattern Generator ,Set-top Box etc. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...

  • Page 23: Power Error

    Measure voltage of each output of Power B/D Normal? Normal Replace Main B/D voltage? Normal Close Check ST-BY 3.5V voltage? ☞A18 Replace Power B/D Replace Power Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 24 Normal Replace Main B/D Check Power B/D voltage? voltage ※ Caution Check and fix exterior Replace Power B/D of Power B/D Part Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 25 Reboot by SW down load function UNKNOWN No meaning (same as initial value) COMP_END OLED threshold voltage degradation(Compensation) completes. PNWASHDONE Power off by panel noise wash function complited. (OLED) Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 26 13.2V of Power Screen normal voltage Speaker off Board Cancel OFF Replace Power Board and repair parts Check Replace MAIN Board Disconnection Speaker disconnection Replace Speaker Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 27 (In case of Connect and check Normal External Input other external audio? signal error) device Check and fix external device Check and fix external device Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...

  • Page 28: Function Error

    Replace Main B/D (Power B/D don’t have problem) If R/C operate, Normal Close operating? Explain the customer cause is interference from light in room. Replace R/C Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 29 Recognition error - S/W Version HDMI/ Check and fix DVI, Optical Fix in Replace Main B/D Recognition external device/cable accordance error with technical information Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 30 “Part related to nose” in the Owner’s then proceed as shown in the solution manual Manual. (For models without any fix information, provide the description) Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 31 Revised date 14/14 Zoom part with Module Replace module exterior damage damage Cabinet Replace cabinet damage Remote control Replace remote control damage Stand Replace stand dent Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 32 Exchange Module (1) ~ (3) A-6/11 ~ A-8/11 Inverter/ Module Exchange T-Con (1) ~ (2) A-9/11 ~ A-10/11 Exchange Power Board(PSU) A-11/11 Continue to the next page Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 33 Check items after Main B/D replacement E. Etc Adjustment Test pattern – ADJ Key How to use JIG (Power B/D Diagnostic Smart Jig Multi Gender Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 34 Revised Check LVDS Content date No Video/Normal audio C1801: 13V Reassemble After turning on the power and disassembling the case, check C1801 Voltage 13V Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 35 2. Enter into White Balance. 3. After recording the R, G, B (GAIN, Cut) value of Color Temp (Cool/Medium/Warm), re-enter the value after replacing the MAIN BOARD. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 36 TUNER input signal strength checking method date  Advanced Channels Channel Tuning Manual Tuning When the signal is strong, use the attenuator (-10dB, -15dB, -20dB etc.) Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 37 Content Version checking method date <ALL MODELS> 1. Checking method for remote control for adjustment Version Press the IN-START with the remote control for adjustment Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 38 1. Check the signal strength or check whether the screen is normal when the external device is connected. 2. After measuring each voltage from power supply, finally replace the MAIN BOARD. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 39 Revised Content connection diagram date As the part connecting to the external input, check the screen condition by signal Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 40 A. Video error_Color error symptom date Revised Content Check Link Cable(LVDS) reconnection condition date Check the contact condition of the Link Cable, especially dust or mis insertion. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 41 Screen darkness to disconnection of the FFC cable pin. G color transient due to poor FFC cable CABLE G Color Excessive connection A - 1/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 42 LVDS cable connection problem CABLE Color spread LVDS cable connection problem Due to foreign substance withi nLVDS CABLE Screen stop cable PIN A - 2/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 43 Main IC problem Main Dark picture Dark left-side screen Top/bottom screen part Main Broken picture Picture problem due to tuner Inner side quality problem A - 3/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 44 Screen spread Screen corner appears blurry Main Color Spread Color spread on the screen Main Blurry Screen Blurry picture on the screen A - 4/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 45 Screen picture spread problem Screen problem No problem at the initial stage. Right-side Main During Heat run, right-side picture picture problem problem A - 5/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 46 BLU internal foreign matter inflow MODULE Internal matter 6 block image broken MODULE Image broken MODULE Image broken Screen sync signal broken A - 6/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 47 BLU Vertical spreading on cube screen in no MODULE Vertical smear signal MODULE Over color Screen contour part brightly Over color A - 7/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 48 Center of the screen 1 block dark MODULE Screen darkness MODULE Vertical bar Center Vertical Bar Darkness at the MODULE bottom of the MODULE internal BLU breakage screen A - 8/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 49 T-Con is defective and the picture below T-CON image broken the screen is broken A - 9/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 50 The entire screen is dark and bit noise T-CON Image Broken occurs The entire screen is dark and bit noise T-CON Image Broken occurs A - 10/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 51 Appendix : Exchange Power Board (PSU) No Light No picture/Sound Ok A - 11/11 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 52 Established B. Power error _No power symptom date Revised Content Check front Power Indicator date ST-BY condition: On or Off Power ON condition: Turn Off Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 53 Established B. Power error _No power symptom date Revised Check power input voltage and ST-BY 3.5V Content date Check the VLED Check the DC 13.2V/20V Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 54 POWER OFF MODE checking method date <ALL MODELS> Entry method 1. Press the IN-START button of the remote control for adjustment 2. Check the entry into adjustment item 3 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...

  • Page 55: Checking Method

    1. Press the Setting button on the remote control 2. Select the Sound function of the Menu 3. Select the Sound Out 4. Select TV Speaker Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 56 3. Connect the tester P5600 to the speaker terminal and if you hear the ‘Chik~ Chik~’ sound when you touch the GND and output terminal, the speaker is normal. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 57 2.Check the standby 3.5V on the terminal (③) 3.AS checking the Pre-Amp(IR LED light) , the power is in ON condition, an Analog Tester needle should move slowly, otherwise, it’s defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 58 Standard Repair Process Detail Technical Manual Error Established E.Etc symptom date Revised Content How to use the Service remote control date 1. How to access the remote control Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 59 Digital EYE function ON/OFF For some Model, access to the Test Pattern TILT Used for screen tilting change (Access to the old PDP control mode) Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 60 Connects to external input 1,2,3 COMP1,2 (Added function) Connects to Component 1,2 HDMI1,2,3,4 Connects to HDMI 1,2,3,4 (Add function) DVI (Add function) Connects to DVI Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 61 - Record the R, G, B (GAIN, Cut) value of the color temperature before main board replacement. After replacing the main board, key in the recorded value. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 62 You can view 11 types of patterns using the ADJ Key Checking item : 1. Defective pixel 2. Residual image 3. MODULE error (ADD-BAR,SCAN BAR..) 4. Video error (Classification of MODULE or Main-B/D!) Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 63 Smart JIG Power Diagnosis Muitl Gender Guide (P/N : RAD32507801) (P/N : RAD33187801) Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...

  • Page 64: Main Board

    24 Marking Check UK74 28Pin 28Pin 12Pin 12Pin 28Pin UK75 Cable Connection UK78 Includes 49UJ63 SK79 17Y/18Y 16/18Y 16Y/17Y 16Y/17Y/18Y (SJ/UJ/UK/SK) (UH) (UH/UK) (UH/SJ) (LH/LJ/LK) Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 65 SJ95/UJ98 SJ85/UJ94 SJ80, UJ77 UJ75/UJ78 ’17 UJ65/UJ68 UJ63/UJ67 LJ61/LJ68 LJ55/LJ58 SK80/SK85/SK95 UK78/UK75/SK79 ‘18 UK63/UK64/UK65/UK7050 32LK61/62, 43/49LK61 LU34, LU54 B8, C8, E8 ‘18 OLED G8, W8 Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 66 ▶ Power Board Muitl Gender JIG “A: 2013 LCD POWER” 2014 ▶ Connect the Muiti Gender to the connector (black) as shown in picture 2 of the Smart JIG. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 67 - 20V Power Board : Change the switch to 24V of Smart Jig Voltage - 13.2V/18V Power Board : Change the switch to 24V of Smart Jig Voltage Power B/D Smart Jig Voltage Switch 13.2V/18V Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 68 ▶ Fix the LCD MODEL switch to 24V.(Smart JIG) ▶ Disconnect the Main Board 24Pin Power Cable connector. ▶ Connect the 24Pin Power Cable connector to the Muitl Gender JIG 24Pin connector Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 69 ▶ When the OK LED(24V,12V) turns on, Power Board is normal. ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 70 ▶ When the OK LED(24V,12V) turns on, Power Board is normal. ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 71 ▶ When the OK LED(24V,12V) turns on, Power Board is normal. ▶ Connect the 24Pin Power Cable connector to the Muitl Gender JIG 24Pin connector Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 72 ▶ Connect the 24Pin Power Cable connector to the Muitl Gender JIG 24Pin connector ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 73 ▶ Connect the 24Pin Power Cable connector to the Muitl Gender JIG 24Pin connector ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 74 ▶ When the NG LED turns on, the Power Board ▶ Fix the LCD MODEL switch to 20V.(Smart JIG) can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 75 ▶ When the NG LED turns on, the Power Board ▶ Fix the LCD MODEL switch to 20V.(Smart JIG) can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 76 ▶ Connect the 18Pin Power Cable connector to the Muitl Gender JIG 24Pin connector ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 77 ▶ Connect the 28Pin Power Cable connector to the Muitl Gender JIG 28Pin connector ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 78 ▶ Connect the 28Pin Power Cable connector to the Muitl Gender JIG 28Pin connector ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 79 ▶ Connect the 12Pin Power Cable connector to the Muitl Gender JIG 12Pin connector ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 80 ▶ Connect the 12Pin Power Cable connector to the Muitl Gender JIG 24Pin connector ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
  • Page 81 ▶ Connect the 28Pin Power Cable connector to the Muitl Gender JIG 28Pin connector ▶ When the NG LED turns on, the Power Board can be judged as defective. Copyright © 2019 LG Electronics. Inc. All rights reserved. Only for training and service purposes...
