INDICE 1.0 Introduzione...........................4 1.1 Informazioni di sicurezza............................4 1.1.1 Protezione da scariche elettriche ........................4 1.1.2 Installazione ..............................4 1.1.3 Protezione dagli incendi ..........................4 1.1.4 Protezione da solidi e liquidi...........................4 1.2 Normative .................................4 2.0 Dimensioni .............................5 3.0 Componenti dell’apparecchiatura ....................5 4.0 Avviamento rapido........................6 5.0 Imballo e trasporto ........................7 5.1 Imballo..................................7 5.2 Trasporto ...................................7...
Page 3
INDEX 1.0 Introduction ..........................14 1.1 Safety information..............................14 1.1.1 Protecting against electric shock ........................14 1.1.2 Installation ..............................14 1.1.3 Protection against burns and fire .........................14 1.1.4 Weather protection............................14 1.2 Compliance ................................14 2.0 Size ...............................15 3.0 Components of the unit......................15 4.0 Quick turn on..........................16 5.0 Packaging and transport ......................17 5.1 Packaging ................................17 5.2 Transport .................................17...
1.0 Introduzione 1.1 Informazioni di sicurezza Attenzione! Questo prodotto è adatto solo ad un uso professionale, non ad un uso domestico. 1.1.1 Protezione da scariche elettriche • Togliere l’alimentazione prima di effettuare qualsiasi operazione all’interno dell’apparecchiatura. • Non utilizzate l’apparecchiatura in assenza di una connessione di terra. •...
4.0 Avviamento rapido In questo capitolo troverete elencate brevemente le operazioni necessarie per utilizzare immediatamente il di- spositivo. Queste istruzioni sono indispensabili per la connessione e l’alimentazione dell’apparecchio, ma non de- scrivono in modo completo le sue funzionalità. Vi invitiamo quindi a leggere anche gli altri capitoli di questo manuale, in modo da apprendere tutte le informazioni relative al dispositivo.
1 manuale di istruzioni Attenzione! • La responsabilità di Griven S.r.l. cessa all’atto della consegna del materiale al vettore: reclami per eventuali danni dovuti al trasporto dovranno essere indirizzati direttamente al corriere. • Si accettano reclami entro e non oltre i 7 giorni dal ricevimento merce.
6.2 Collegamento della tensione d’alimentazione L’apparecchio può funzionare con tensioni da 100 a 240Vac e con frequenze di 50 e 60Hz. Attenzione! • Prima di collegare l’apparecchio assicuratevi che la fornitura elettrica corrisponda a quelle ammesse. • Non installate mai l’apparecchio senza la connessione di terra. •...
Collegate i cavi di segnale al morsetto “6”, come riportato nella seguente figura. Pin 1: GND Pin 2: DATA- Pin 3: DATA+ Attenzione! La schermatura ed i conduttori non devono fare alcun tipo di contatto tra loro o con la custodia metallica dei connettori. Il pin numero 1 e la custodia non devono essere collegate alla massa elettrica dell’apparecchio.
7.0 Utilizzo del dispositivo 7.1 Impostazione indirizzo DMX Il numero dei canali DMX utilizzati dal transformer box per il suo funzionamento varia a seconda del valore del dip-switch n°10. Nella seguente tabella sono indicate le funzioni corrispondenti ai valori dei dip-switch. Dip 10 Funzione Canali DMX...
7.2.2 Funzioni DMX con uscite indipendenti (Dip 10=OFF) Canale Funzione Valore Descrizione 0-15 Intensità luminosa 100% del proiettore 1 16-150 Controllo proporzionale intensità luminosa 100-0% del proiettore 1 Dimmer Strobo 151-160 Intensità luminosa 0% del proiettore 1 Controllo proporzionale effetto strobo 0-100% (255=max) del 161-255 proiettore 1 0-15...
10.0 Parti di ricambio Tutti i componenti dell’apparecchiatura sono disponibili come parti di ricambio presso i rivenditori Griven. Le viste esplose, lo schema elettrico, il diagramma elettronico e la brochure promozionale sono disponibili su richiesta. Per facilitare il lavoro del centro di assistenza ricordate di specificare il numero di serie ed il modello di transfor- mer box di cui avete richiesto i ricambi.
Page 14
1.0 Introduction 1.1 Safety information Warning! This unit is suitable for professional use only, not for domestic use. 1.1.1 Protecting against electric shock • Disconnect the unit from mains supply before servicing it or performing any other action. • Always ground/earth the unit electrically. •...
Page 15
2.0 Size 270mm 217mm 10,63in 8,54in 255mm 10in 3.0 Components of the unit Components description: A. Dip-switch panel B. Power supplies terminal box C. DMX Terminal box D. Led terminal box English...
Page 16
4.0 Quick turn on In this chapter brief essential instructions for an immediate use of the unit are listed. These instructions are neces- sary to connect and power up the unit, but they will not describe in complete details the functions of the unit it- self.
Page 17
• Griven S.r.l. will accept claims for broken or missing goods only within seven days of receipt of the goods. • Returns of equipment will not be accepted without prior authorization granted by Griven S.r.l. and if not duly ac- companied by relevant shipping documents.
Page 18
6.2 Connection to mains power The unit can operate with voltage from 100 to 240Vac with frequency of 50 and 60Hz. Warning! • Before connecting the unit, verify that power supplies features are compatible with the unit features. • The unit must never be installed if not grounded electrically. •...
Page 19
Connect the DMX signal cables to the pin “6”. Pin 1: GND Pin 2: DATA- Pin 3: DATA+ Warning! All data wires must be isolated one from another, from the shield and from the metal housing of the connectors. Pin number 1 of the housing is not to be connected to the electric ground of the unit. Insert a terminal plug with a 120 Ω...
Page 20
7.0 Use of the unit 7.1 Setting DMX address The number of DMX channels used by the unit to operate will depend from value of dip-switches n°10. The following table reads the functions corresponding to the dip-switches values. Dip 10 Funzione Canali DMX 4 indipendent output...
Page 21
7.2.2 DMX functions with 4 indipendent output Channel Function Value Description 0-15 Luminous output intensity 100% of projector 1 Proportional control of the luminous output intensity 100-0% 16-150 Dimmer of projector 1 Strobe 151-160 Luminous output intensity 0% of projector 1 161-255 Proportional control of the strobe effect 0-100% of projector 1 0-15...
Page 22
9.0 Spare parts All the components of the unit are available as spare parts at Griven's dealers. The exploded views, the wiring di- agram, the electronic layout and the advertising brochure are available on request. To make aftersale assistance easier, remember to specify the serial number and the model of the fixture which the spare parts are requested for.
