PEX 8624-AA RDK
Hardware Reference Manual
Website:
Technical Support:
Copyright © 2010 by PLX Technology, Inc. All Rights Reserved – Version 1.1
May 03, 2010
Version 1.1
May 2010
www.plxtech.com
www.plxtech.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PEX 8624-AA RDK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PLX Technology PEX 8624-AA RDK

  • Page 1 PEX 8624-AA RDK Hardware Reference Manual Version 1.1 May 2010 Website: www.plxtech.com Technical Support: www.plxtech.com/support Copyright © 2010 by PLX Technology, Inc. All Rights Reserved – Version 1.1 May 03, 2010...
  • Page 2 © 2010 PLX Technology, Inc. All rights reserved. PLX Technology, Inc. retains the right to make changes to this product at any time, without notice. Products may have minor variations to this publication, known as errata. PLX assumes no liability whatsoever, including infringement of any patent or copyright, for sale and use of PLX products.

  • Page 3: A T M

    This document contains PLX Confidential and Proprietary information. The contents of this document may not be copied nor duplicated in any form, in whole or in part, without prior written consent from PLX Technology, Inc. PLX provides the information and data included in this document for your benefit, but it is not possible to entirely verify and test all the information, in all circumstances, particularly information relating to non-PLX manufactured products.

  • Page 4: Table Of Contents

    Midbus probe footprints (JP1 – JP2) ..................19     2.5V Header (JP3) ........................21     JTAG Header (JP4) ........................21   PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...
  • Page 5 Figure 2-2. PCI Express up to 5GT/s Gen 2 Connections ................5   Figure 2-3. Use mini-SAS Connector for NT Function Setup..............7   Figure 2-4. PEX 8624-AA RDK Reference Clock Circuit ................. 7   Figure 2-5. PEX 8624-AA RDK Reset Circuit ................... 8  ...

  • Page 7: General Information

    1. General Information The PLX PEX 8624-AA RDK is a Rapid Development Kit based on the PEX 8624, a 24-lane, 6-port PCI Express Gen 2 switch. The PEX 8624-AA RDK provides a complete hardware and software development platform that facilitates getting designs up and running quickly, lowering risk and reducing time-to-market. This RDK allows the upstream port of the PEX 8624 to be directly plugged into a system board’s x8 or x16 PCI Express connector, or...

  • Page 8: Pex 8624 Features

    PCI Express Mini Card Electromechanical (CEM) Specification, Revision 1.1 (PCI ExpressCard Mini CEM r1.1) IEEE Standard 1149.1-1990, IEEE Standard Test Access Port and Boundary-Scan Architecture, 1990 (IEEE Standard 1149.1-1990) PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 9: Pex 8624-Aa Rdk Features

    Up to six Lane Status indicator LEDs for visual inspection of link speed and status  Voltage level monitoring circuit for 1.0V and 2.5V power to the PEX 8624 PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 10: Pex 8624-Aa Rdk Hardware Architecture

    PEX 8624-AA RDK PCI Express Interfaces The PEX 8624-AA RDK is designed around the PEX 8624, a 6-port, 24-lane Gen 2 switch, and is based on the form factor specified in the PCI Express CEM 2.0 Specification. The PEX 8624-AA RDK offers five PCI Express (PCIe) interfaces: a x8 PCI Express Card Edge connector (P1), three x16 PCI Express Edge Card connectors (SLOT 1, SLOT 2, &...

  • Page 11: Configuration Modules And Receptacle Cm1

    Configuration Module Receptacle CM1 is a 200-pin high-speed Mezzanine Connector. It is soldered on the PCB of PEX 8624-AA RDK. It directly connects to lane 4 to lane 7 of the PEX 8624, lane 4 to lane 7 of PCI Express card edge connector P1, lane 0 to lane 3 of PCI Express Edge Card Connector SLOT 2, and lane 0 to lane 3 of 4x mini-SAS connector IP1.

  • Page 12: Pci Express Card Edge Connector P1

    CM1 receptacle, the PEX 8624’s lanes 4-7 are routed to Connector P1 and become the upper four lanes of Port 0’s x8 link. By default, the PEX 8624-AA RDK sets this port to be the upstream port. Connector P1 also provides 12V and 3.3V power, along with PERST# and REFCLK_P/N to the RDK.

  • Page 13: Reference Clock Circuitry

    Figure 2-3. Use mini-SAS Connector for NT Function Setup Reference Clock Circuitry The PEX 8624-AA RDK reference clock circuitry contains a one-to-four differential clock fan out buffer (U2) from SpectraLinear (CY28400-2). The clock fan out buffer supports four 100 MHz PCI Express reference clocks with the option for constant frequency and spread spectrum outputs.

  • Page 14: Reset Circuitry

    Hot-Plug capable through the use of the I2C bus and external I/O expander devices. The PEX 8624-AA RDK implements Hot-Plug control circuitry for SLOT 1 and SLOT 2. SLOT 1 uses the on-chip parallel Hot-Plug controller while SLOT 2 uses the Serial Hot-Plug control capability through the I2C and I/O expander.

  • Page 15: Serial Hot-Plug Controller Circuits

    Serial Hot-Plug Controller Circuits PEX 8624-AA RDK also implements the serial hot-plug controller circuitry to PCI Express SLOT 2. By default, the RDK is configured to bypass the serial hot-plug controller. In order to configure port 1 at PCI Express SLOT 2 as a Serial Hot-Plug port with the port 0 is still a x4 upstream port, use the EEPROM to write 2’b00 to the bit [14:13]...

  • Page 16: Serial Eeprom

    PCI Express connector SLOT 2. Serial EEPROM The PEX 8624-AA RDK contains an 8-pin DIP socket for a serial EEPROM (U17). The board is populated with a blank On Semi CAT25080LI-G 32-Kbit device. The CAT25080LI-G device can directly interface to the PEX8624.

  • Page 17: Power Distribution

    Power Distribution The PEX 8624-AA RDK has two sources of DC power. The first source is the card edge connector (P1). The x8 connector provides up to 2.1A at 12V and 3.0A at 3.3V from the PCI Express edge card connector it plugs in. The power from P1 is intended to power the PEX 8624, PCI Express connector SLOT 2, and the on-board electronic components.

  • Page 18: Port Link Status Indication (D17 - D22)

    Port Link Status Indication (D17 – D22) The PEX 8624-AA RDK provides up to six green color link status LEDs, D17 to D22, to indicate its port 0, 1, 5, 6, 8 and 9 link states. LED on, off, and three blinking patterns cover all five states of port link status. (See...

  • Page 19: Gpio Pins

    PEX 8624 Voltage Level Monitoring (D10 – D11) The PEX 8624-AA RDK provides voltage level monitoring circuit to monitor the 1 volt and 2.5 volt power to the PEX 8624. The circuit contains an Intersil multiple voltage supervisory ISL6132, two bi-color LEDs, D10 and D11, and various value resistors.

  • Page 20: On-Board Connectors, Switches, And Jumpers

    3. On-Board Connectors, Switches, and Jumpers DIP Switches The PEX 8624-AA RDK contains nine user controllable DIP switches (SW1-SW9) for selecting the slot ID for the serial hot-plug, enable/disable Hot-Plug signals, enable/bypass the serial hot-plug and parallel hot-plug, upstream port select, port configuration, NT upstream port select, I C address settings and test mode settings.

  • Page 21: Parallel Hot-Plug Signal And Control (Sw3)

    Figure 3-4. Switch SW4 Default Settings Switch SW4 is for PLX internal test only. Changing the settings for SW4 is not recommended. PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 22: Upstream Port Select (Sw5)

    Port Configuration and NT Upstream Port Select (SW6) default STN0_PCFG1 STN1_PCFG0 STN2_PCFG1 NT_USPT_SEL0 ON NT_USPT_SEL1 ON NT_ENABLE# HIGH Figure 3-6. Switch SW6 Default Settings PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 23: Test Mode Select (Sw7)

    NT Port ON, ON Port 0 NT_USPT_SEL[1:0] ON, OFF Port 1 3.1.7 Test Mode Select (SW7) Figure 3-7. Switch SW7 Default Settings PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 24: I 2 C Address And Other Mode Select (Sw8)

    REV_17# relates to OFF: For normal operation STRAP_RESERVED17# pin 3: REV_17# ON: For PLX use only OFF: For normal operation PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 25: Push-Button Switches

    Serial Hot-Plug Controller Attention Button (S2) The PEX 8624-AA RDK provides a manual switch S2 for the attention button to the serial hot-plug circuit. When pushed and released, the switch generates an active low pulse to the Attention Button Input of the serial hot-plug controller.

  • Page 26: Figure 3-9. Midbus 2.0 Footprint Dimensions, Pin Numbering And Specification (Copied From Agilent's Document)

    C1n-Downstream C2p-Upstream C2p-Downstream C2n-Upstream C2n-Downstream C3p-Upstream C3p-Downstream C3n-Upstream C3n-Downstream C4p-Upstream C4p-Downstream C4n-Upstream C4n-Downstream C5p-Upstream C5p-Downstream C5n-Upstream C5n-Downstream C6p-Upstream C6p-Downstream C6n-Upstream C6n-Downstream PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 27: Header (Jp3)

    Port (JP5 – JP6) (See Section for details) Table 3-10. Pin assignment of JP5 and JP6 Pin Number Signal Name I2C_SCL I2C_SDA PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 28: Atx Hd Power Connector (J1)

    Pin Number Signal Name In Schematics DB_SEL0_I PWRFLT_B#_I DB_SEL1_I MRL_B#_I PRSNT_B#_I BUTTON_B#_I MRL_C#_I BUTTON_C#_I PWRFLT_C#_I PRSNT_C#_I PWRGD_A_I PWRGD_B_I MRL_A#_I BUTTON_A#_I PWRFLT_A#_I PRSMT_A#_I PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 29: Plx Use Header (J4)

    This is for PLX use only. Table 3-14. Pin assignment of J4 Pin Number Signal Name In Schematics SPARE2_O SPARE1_IO STRAP_RESERVED16 PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...

  • Page 30: Bill Of Materials/ Schematics

    4. Bill of Materials/ Schematics PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...
  • Page 31 SMT, SOT-223 2.5BS 2.5V@1A Mouser: pn: IC, low voltage 8-bit SN74CBTLV324 595- FET bus switch, SMT,20-pin TSSOP U14-U15 5APWR SNCBTLV32 3.3V 45APWR PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...
  • Page 32 S1-S3 Cap. Ceramic, 399-1083-2- Kemet C0603C102J5R 0.001uF, X7R, 50V SMT, 0603 ACTU C0603C103J5R Cap, Ceramic, Kemet SMT, 0603 C58-C60,C89-C90, 0.01uF,50V 5% PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...
  • Page 33 LRF2512-LF- Res. 2W, 0.02 ohm TTelectronics SMT, 2512 R32,R35,R41,R44 R020-F ERJ- Res. 1/10W, 4.7 Panasonic SMT, 0603 3GEYJ4R7V ohm 5% PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...
  • Page 34 Res. 1/10W, 12.4K SMT, 0603 R91,R94 America FKHFT ohm, 1% Yageo 90C6031A1372 Res. 1/10W, 13.7K SMT, 0603 R92,R96 America FKHFT ohm, 1% PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...
  • Page 35 Res. 1/10W, 15 ohm Panasonic SMT 0603 R124 P15GCT-ND 3GEYJ150V ERJ- Res. 1/18W, 390 Panasonic SMT 0805 R68-R71 P391ACT-ND 6GEYJ391V ohm 5% THROUGH-HOLE COMPONENTS PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...
  • Page 36 Module #3, x8 to Plug to receptacle CM1 of 91-0096-000-A SMT, Plug card edge connector PEX 8624RDK PARTS SHOULD NOT BE ASSEMBLED PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...
  • Page 37 Jumper shunt, for AMP/Tyco 382811-6 2-pin JP3(1-2) 0.1" hdr. Customer Name PLX Part # 91-0080-102-B Product Name PEX8624RDK Date March 26, 2010 PEX 8624-AA RDK Hardware Reference Manual – Version 1.1 Copyright © 2010 by PLX Technology, Inc. All rights reserved...
  • Page 38 Reset Express Slots Converters Circuit LEDs DIPSWITCHES INTERFACE PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
  • Page 39 RX3n_IP1 TX3n_IP1 TX3- RX3- FCI84517_10x20 FCI84517_10x20 I_PASS_26CKT_75783_0036 I_PASS_26CKT_75783_0036 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
  • Page 40 RX31p TX31n ITP15 ITP15 ITP16 ITP16 RX31n PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. RX31n ITP1-ITP16 are probe holes 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 The hole size of GP1-4 should be www.plxtech.com...
  • Page 41 P5_1/P5_2 to P6_1/P6_2 are probing holes for refclk signals at P1. They should be placed close to the connector. See layout requirement on page 3 for details. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085...
  • Page 42 HP_SL2_CTL MRLI#_S SW DIP-2 SW DIP-2 Default Settings 1: off (disable MRL#_S) PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 2: off (disable Serial HP) 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 43 PWRLED_B# GREEN GREEN GREEN GREEN 4.7K 4.7K BUTTON_B#_I PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. BUTTON_B#_I {8} SW PUSHBUTTON SW PUSHBUTTON 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 44 GREEN TV11 TV11 TV16 TV16 DR_14 5V_A GREEN GREEN TV12 TV12 TV17 TV17 DR_15 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 3.3VCC CMD15-22SRUGC CMD15-22SRUGC GREEN GREEN TV13 TV13 TV18 TV18 DR_16 870 W Maude Ave, Sunnyvale, CA 94085...
  • Page 45 PEX_PERn39 MICTOR 38 MICTOR 38 REXT_4 REXT_B4 PEX8624AA_19X19 PEX8624AA_19X19 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com...
  • Page 46 PEX8624AA_19X19 2.5VCC TP3 marks with 2.5V TP2 marks with GND TP4 marks with GND PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085...
