1x4 3G/HD/SD-SDI Distribution
Amplifier with Reclocking
User Manual
0
1
4
0
1
4
rev: 120626
Made in Taiwan
The SP-3014
1x4 3G/HD/SD-SDI Distribution Amplifier with Reclocking
conformance to safety regulations and requirements, and has been certified for international use.
However, like all electronic equipments, the SP-3014 should be used with care. Please read and
follow the safety instructions to protect yourself from possible injury and to minimize the risk of
damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
Introduction ................................................................................................................ 1
Features ........................................................................................................................ 1
Package Contents ...................................................................................................... 1
Specifications .............................................................................................................. 2
Panel Descriptions .................................................................................................... 3
Hardware Installation ............................................................................................ 4
Warranty ....................................................................................................................... 5
Signal Measurement .................................................................................................. 6
