Summary of Contents for Hans Grohe Talis M51 160 2jet 72815007

  • Page 1 ZH 用户手册 / 组装说明 EN Instructions for use / Assembly instructions Talis M51 160 2jet 72815007...
  • Page 2 中文 大小 (参见第页 9) 安全技巧 装配时为避免挤压和切割受伤,必须戴上手 流量示意图 (参见第页 9) 套。 冷热水管间过大的压力差必须予以平衡。 备用零件 (参见第页 14) 安装提示 清洗 (参见第页 10) • 安装前必须检查产品是否受到运输损害。 安装 后将不认可运输损害或表面损伤。 操作 (参见第页 13) • 管道和阀门必须根据通用标准进行安装、冲洗 和检查。 汉斯格雅建议,清晨或在水流长时间停滞后,前 • 请遵守当地国家现行的安装规定。 半升水不作饮用水使用。 技术参数 1 MPa 工作压强: 最大 0,1 - 0,5 MPa 推荐工作压强: 1,6 MPa 测试压强: (1 MPa = 10 bar = 147 PSI) 70°C 热水温度: 最大 65°C 推荐热水温度: 70°C / 4 分钟 热力消毒: 最大 该产品专为饮用水设计!...
  • Page 3: Safety Notes

    English Dimensions (see page 9) Safety Notes Flow diagram (see page 9) Gloves should be worn during installation to prevent crushing and cutting injuries. Spare parts (see page 14) The hot and cold supplies must be of equal pressures. Cleaning (see page 10) Installation Instructions Operation (see page 13) • Prior to installation, inspect the product for transport damages. After it has been installed, no transport or Hansgrohe recommends not to use as drinking water surface damage will be honoured. the first half liter of water drawn in the morning or after a prolonged period of non-use. • The pipes and the fixture must be installed, flushed and tested as per the applicable standards. • The plumbing codes applicable in the respective countries must be observed. Technical Data Operating pressure: max. 1 MPa Recommended operating pressure: 0,1 - 0,5 MPa Test pressure: 1,6 MPa (1 MPa = 10 bar = 147 PSI) Hot water temperature: max. 70°C Recommended hot water temp.:...
  • Page 4 (3 Nm) SW 10 mm SW 24 mm (4 Nm) 150° 110°...
  • Page 5 150° 75° 75° 24 x 15° 45° 105° 105° 45°...
  • Page 6 110° 55° 55° 24 x 15° 25° 85° 85° 25°...
  • Page 7 CLICK (1 Nm) > 2 min...
  • Page 8 60 °C 10 °C 0,3 MPa SW 3 mm 60°C 36°C 55°C 38°C 50°C 43°C SW 3 mm (5 Nm)
  • Page 9 Ø 28 Ø Ø 33 G1/2 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 Q = l/min 9 12 15 18 21 24 27 30 Q = l/sec...
  • Page 10 • • • • Hansgrohe • Hansgrohe • www.hansgrohe-int.com/guarantee • • QuickClean • QuickClean • • QUICK CLEAN...
  • Page 11: Warranty

    English Cleaning Recommendation for Hans- • After cleaning rinse thoroughly with clean water to remove any cleaner residue. grohe Products • The use of steam cleaners is not permitted. The high Today, modern sanitary and kitchen tapware, showers, temperatures can damage the products. accessories, washstands, tubs and radiators consist of Important very different materials to comply with the needs of the...
  • Page 13 开 / open 热 / hot 冷 / cold 关 / close...
  • Page 14 93159000 95704000 95493000 98127000 93148000 98864000 (11x2) 97735000 98365000 96737000 98211000 98398000 (21x2,5) (23x2) 92527000 97685000 (27x1,5) 98146000 (25x1,5) 98422000 92732000 (7x1,5) 98865000 98140000 95909000 (20x1) 95910000 97827000 97489000 (8x1,75) (900 mm) 97523000 95561000 97548000 95049000 95507000 98551000...
