Delfield Meridian MDBR1-SH Specifications

MERIDIAN SERIES
Solid Door Single Section Dual Temp Refrigerator/Freezer
Reach-Ins
MODELS
❑ MDTR1-SH Refrigerator top/freezer bottom
❑ MDBR1-SH
Freezer top/refrigerator bottom
MDTR1-SH MDTR1-SH
SPECIFICATIONS
Exterior: Top and bottom are constructed
of heavy gauge galvinized steel. Sides are
aluminum. Shroud is heavy gauge stainless
steel.
Interior: Liner is heavy gauge, corrosion
resistant, aluminum. Two epoxy coated wire
shelves per section are supported by stainless
steel shelf clips which are placed in aluminum
pilasters and are adjustable on 1" centers.
Shelves are rated at 250lb. load capacity each.
Doors: Unit is provided with two half height
hinged glass doors. Doors are provided with
locks; magnetic door gasket, easily removable
without tools; cam lift, self closing, edge mount
door hinges (2/door).
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable glass doors and stainless steel shroud, for lasting
good looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to find, don't intrude into
kitchen traffic
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Mini watt door heaters eliminate condensation with
minimal energy cost
• Easy to read dial thermometer
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Epoxy coated shelves—corrosion resistant, 250-lb.
capacity. Flexible placement on 1" centers allows
maximum storage
• Aluminum interior stands up to food acids without
corroding
Refrigeration Systems: Each compartment has
its own separate refrigeration system. Condensing
units are located on top of the cabinet, outside the
food zone, behind the removable upper shroud.
Evaporator coils are located inside the cabinet
mounted to the interior ceiling of each compartment.
Defrost is automatic. Condensate travels down a tube
in the cabinet side wall to a recepticle mounted to the
exterior bottom of the cabinet where it evaporates
with the aid of an electric heater. Each compartment's
temperature is individually monitored and controlled.
Two exterior dial themometers monitor temperature.
Refrigerator compartment maintains temperature
between 33˚F and 41˚F. Freezer compartment
maintains temperature between +5˚F and -5˚F.
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
• Lots of interior storage space for the money
• Rugged metal legs, adjustable to compensate for
uneven floors
OPTIONS AND ACCESSORIES
❑ Stainless steel exterior sides
❑ Stainless steel interior
❑ Stainless steel kick plate
❑ Door and end laminate
❑ Stainless steel exterior back
❑ Digital thermometer
❑ TXV
❑ Chrome Shelves
❑ Tray Slides
❑ 220/50/1 electrical
❑ Electronic control
❑ Stainless steel legs
❑ Casters
Miscellaneous: Unit comes with one 10' cord
and plug with single point connection to all
cabinet and refrigeration system electronics. Each
compartment is illuminated by a door switch
activated, 25 watt, incondescent light mounted to
the interior ceiling. Unit comes standard with four,
adjustable stainless steel legs, mounted in the field.
Unit is standard with a two year parts, one year
labor warranty and additional three year parts
warranty only on the compressor part.
Approval _________________
Phone: 800-733-8948
Fax: 800-669-0619
Date____________________
Email: info@delfield.com
