Delfield F17VD Specifications

F17VD
Component Crafted Versa Drawer™ Equipment Stand

Models

F17VD84 84" Versa Drawer with (2) 32" drawers
84.00"
64.00"
UNFIN.
END
84.00 X 9.50 X 1.25
MAPLE CUTTING BOARD
32" VERSA DRAWER 32" VERSA DRAWER
UNFIN.
END
F17VD84
F17VD84

Specifications

Exterior Top: Constructed of one-piece heavy-gauge
stainless steel with integral 2.12" (5.4cm) high square nosing
at front and 1" (2.5cm) x 10" (25.4cm) sides and rear. 1.25"
thick x 9.5" wide maple cuttin board mounted on stainless
steel posts at front
Exterior Sides, Back and Bottom: heavy-gauge stainless
steel side with removable stainless steel mechanical access
panel on compressor end. Back, bottom and other end are
constructed of galvanized steel.
Interior: Interior of each drawer section is a polyethylene
rotocast liner with ABS drawer front liners
Drawers: Heavy-gauge stainless steel exterior front, with a
thermoformed ABS plastic interior liner. Frame and tracks are
constructed of 11 and 12-gauge stainless steel. Roller track
assemblies have self-lubricating Delrin™ rollers.
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
20.00"
S/S
END

Standard Features

30.75"
• 4 temperature operation-each drawer is
completely independent and can operate as
a refrigerator, freezer, chiller or thaw cabinet
at any time
• Easy to use microprocessor control with
push button function selection
• HACCP electronic record keeping, alarm
notifications, and service diagnostics
• Heavy-gauge stainless steel top with 2"x4"
backsplash is standard
S/S
1 2
END
• Standard on 6" adjustable legs
• Mechanical access on compressor end of 26.00"
unit
7.62"
6.12"
• 32" heavy duty full extension drawers with
(2) 12"x20" pan capacity per drawer
LOUVERED S/S PANEL
• NSF 7 certified
• High density polyurethane foam throughout
• Dart style quick change gaskets
• 8' long electrical cord
• Environmentally friendly HFC-404A
refrigerant
• 1.25"x9.5" maple cutting board
• One year parts, one year labor and 5 year
compressor warranty
Refrigeration System: Environmentally friendly HFC-
404A refrigerant. Each independent drawer has it's own
evaporator coil with expansion valve. Digital control acts
as thermometer, thermostat and diagnostic center for each
drawer. Hot gas defrost system is also utilized during thaw
operation.
Electrical Connections: 115 volt, 60 Hertz, single phase.
Unit is wired to a J-box and must be hardwired to the power
source in the field.
Installation: Units built into chef counters or production
centers must accomodate 24" of clearance on compressor end
for service access.
The Delfield Versa Drawer is a unique food holding device that includes
an open food container disposed within a refrigerated cabinet such that
both the container and interior of the cabinet are exposed to the same
refrigerated environment, thereby eliminating the need for conventional
dual environment systems which refrigerate food disposed within
insulated, closed containers, while maintaining the interior of the cabinet
at ambient temperature.
Phone: 800-733-8948 or +1 989-773-7981
Fax: 800-669-0619
REMOVABLE
www.delfield.com
Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
Options &
Accessories
• Casters
• Stainless steel end
• 230/50/1 electrical
