Wall Mounting Speakers Using The Mythos Bracket
The Mythos Solo XL Loudspeaker comes with dual custom designed wall
mounting brackets and a wall template that makes secure mounting a breeze.
The rear panel of the speaker features threaded inserts for the adjustable
Mounting Screws (included). These Mounting Screws then fit easily into the
Keyhole Slots on the Wall Mounting Brackets, also included. Follow these
directions for installing the Wall Mounting Brackets.
• Use the Mounting Template (included) to make sure the location you have
selected for wall-mounting does not conceal electrical wiring or plumbing.
Make sure the speaker clears the ceiling, adjacent walls, corners, beams,
lighting fixtures and door/window frames. Leave at least 1-1/2
speaker location to allow the speaker to slide down onto its brackets.
• Mark the location of pilot holes noted on the Mounting Template, and pre-
drill for mounting screws (not included). Use screws rated to hold securely in
the wall material (we recommend #10 screws).
• If there is no stud behind the chosen location, be certain to use wall anchors
(not included) to secure the bracket screws. Follow the wall anchor
manufacturer's directions.
• For masonry walls, use a masonry drill bit to pre-drill holes, and use #10
masonry anchors and screws (not included).
• When the Wall Mounting Brackets are securely screwed to the wall and you
have pulled the three runs of wire (Left, Center and Right) through the
Brackets as shown, insert the Mounting Screws into the rear panel of the
speaker by removing the plastic plugs on the Mounting Screw Holes.
• Line up the speaker's protruding Mounting Screws with the keyhole slots on
the Wall Mounting Brackets, and let the speaker slide straight down,
allowing the screw heads to slip behind the smaller end of the keyhole slots
for a secure mount.
6
" above the
"
