Definitive Technology Mythos Nine Owner's Manual

Definitive Technology
Thank You
Thank you for choosing the Definitive Technology Mythos Nine Loudspeaker
System. Our engineers have spent many years in developing this product. In order
to ensure that you experience the finest performance possible, we encourage you
to take a moment to fully read this owner's manual and familiarize yourself with
the proper installation and set-up procedures for your Mythos Nine speakers.

Specifications

Mythos Nine
Dimensions: 28" long x 5.4" wide x 4.13" deep (711mm l x 137mm w x 105mm d)
(speaker only, not including bracket)
Weight: 13 lbs. (6 kG)
Sensitivity: 90 dB
Frequency Response: 38 Hz – 30 kHz
Nominal Impedance: 8 ohms
Driver Complement: Two each 4 ⁄ " (11.4cm) BDSS High output drivers pressure coupled to
1
2
two 4 ⁄ " x 8" (11.4cm x 20.3cm) Low Bass Radiators, One 1" (25mm)
1
2
ferro-magnetic fluid damped Pure Aluminum dome tweeter.
Specifications subject to change without notice.
MYTHOS NINE
Unpacking Your Mythos Nine Speakers
Please Inspect For Shipping Damage
Each loudspeaker leaves our plant in perfect condition. Any visible or concealed
damage most likely occurred in handling after it left our plant and should be reported
at once to your Definitive dealer or the delivery company that delivered your
loudspeaker. Please unpack your system carefully. Save all cartons and packing
materials in case you move or need to ship your system. Record the serial number
found on the back of the Mythos Nine in the appropriate place on the product
registration card, answer all questions and send it in.
VERY IMPORTANT: Accessories
Various parts and accessories that you will need to use your Mythos Nine are in the
carton but are easy to overlook. Open both ends of the shipping carton. Carefully
examine the contents of the shipping carton and packing material to find the plastic
bags with accessories.
OWNER'S MANUAL
Mythos Nine Loudspeakers
