Suntime Havana Duo Seat Instructions

Havana Duo Seat Instructions (LALC133)
Congratulations on your new purchase. Before assembly please refer to the parts list
below to ensure all parts are correct.
Please retain for future use.

Warnings:

This product is not for commercial use
Keep children away during assembly. This item contains small parts which
can be swallowed by children.

Parts List:

Assembly Guide

Please follow the diagram shown in section I. Please assemble both bar D or E across
frame A. Please adjust and ensure the length of bar D and E can be initially fitted to
frame A before assembly, the following the below instruction:
i) Please insert the short side of the Alley Key (Part J) into the hole located
in the middle of the bar.
ii) Make approx. half a turn in a clockwise position, and remove the Allen
Key from the hole.
iii) Repeat step i) and ii) until the bar has been extended to a tight position.
iv) Repeat step i) and ii) however in a counter-clockwise position when
disassembling part D.
Both seat frames then should be assembled onto frame B. Please find the diagram in
section I for the screw locations on frame B.
Two pieces of frame C are to be secured in both side of frame B. Please locate the
screw locations in the diagram below.
