Reversing the Door Swing of Your Appliance

Should you desire to reverse the opening direction of the door, please follow the instructions below.
Safely reversing the door swing of your appliance should require at least two people.
1 1
1 2
1 3
1 4
9 8
1 5
PRW24C02BPG Use, Care, and Installation Guide
1. Remove the 2 screws from the lower door axis
1
2
4
2. Remove the 3 hinge screws from the top right
3
5
6
3. Unscrew 2 screws and remove the door magnet
7
4. Remove the 3 black decorative covers (8)
5. Install the lower door axis (10) and install the
10
Installation Instructions
(1) and remove a top screw on top of the hinge
(4). Then remove the door (2) and remove the
axis plate (1) from the door.
hinge (3) and remove the top right hinge.
(5) and unscrew 2 screws and remove the
door stopper (6). Remove 2 screws from upper
door axis (7) mounted on top of the door and
remove it. Then, install the door magnet on the
opposite side of the door frame. Take out the
new upper door axis and door stopper from
the hardware package and install them with 2
screws. Rotate the door 180 degrees.
from the top left of the cabinet. Install the
black decorative covers to the top right of
the cabinet and install the new top hinge (9)
from the hardware package that includes
the installation manual at the top left of the
cabinet with 3 screws.
door once correctly aligned. Secure the door
with the top screw on top of the hinge (4).
