P R E S R V ™
Product Specifications
W I N E C O O L E R
D U A L Z O N E

Dimensions

23- "
7/8
Top View
Max 135°
25- "
3/4
23- "
3/4
21- "
7/8
Side View
NOTE: Cabinet depth provided includes a 3/4" overlay panel.
NOTE: A screw is present on the top hinge of the unit, adding an additional 1/8" to the height of the
cooler. If installing cooler flush with cabinet fronts, additional clearance may be needed.
16 PRW24C02BPG Use, Care, and Installation Guide
