Lorex D231A41B User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual

Advertisement

Table of Contents
loading

Related Manuals for Lorex D231A41B

Summary of Contents for Lorex D231A41B

  • Page 1 User Manual...
  • Page 3 User Manual #LX400111; r. 3.0/56507/56507; en-US...
  • Page 4 Thank you for purchasing this product. Lorex Corporation is committed to providing our customers with a high quality, reliable security solution. This manual refers to the following models: D231A41B For the latest online manual, downloads and product updates, and to learn about our complete line of accessory products, please visit our website at: lorex.com...

  • Page 5: Table Of Contents

    STEP 3: Connect mouse..............6 STEP 4: Connect monitor .............. 7 STEP 5: Connect power ..............7 STEP 6: Lorex Setup Wizard ............8 STEP 7: Upgrade Firmware to Latest Version (If Available) ..... 8 Quick Access to System Information..........8 Camera Installation................10...
  • Page 6 Table of contents Active Deterrence................38 12.1 Automatic Deterrence Settings ............38 12.2 Manually Activate Deterrence Features..........39 Managing Passwords and User Accounts ..........40 13.1 User Accounts ................40 13.1.1 Changing Passwords ............40 13.1.2 Adding Users..............41 13.1.3 Modifying Users .............42 13.1.4 Deleting Users ...............42 13.2 Account Groups ................42 13.2.1 Adding Groups...............42...
  • Page 7 Installing a New Hard Drive............83 DDNS Setup (Advanced)...............87 19.1 STEP 1: Port Forwarding .............87 19.2 STEP 2: Create a Lorex Account ............87 19.3 STEP 3: Activate Your Warranty ............88 19.4 STEP 4: Sign Up for a DDNS Account ..........88 19.5 STEP 5: Enable DDNS on the Recorder ..........89...

  • Page 9: Important Safeguards

    Important Safeguards In addition to the careful attention devoted to quality standards in the manufacturing process of your product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to ensure your enjoyment and proper use of the product and accessory equipment.

  • Page 10: Service

    Important Safeguards 6. Overloading: Do not overload wall outlets or extension cords as this can result in the risk of fire or electric shock. Overloaded AC outlets, extension cords, frayed power cords, damaged or cracked wire insulation, and broken plugs are dangerous. They may result in a shock or fire hazard.

  • Page 11: Use

    Important Safeguards 2. Conditions Requiring Service: Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: • When the power supply cord or plug is damaged. • If liquid has been spilled or objects have fallen into the product. •...

  • Page 12: Package Contents

    Package Contents Your security recorder package includes the following components: 1080p HD Security DVR Power Adapter Ethernet Cable USB Mouse HDMI Cable NOTE Hard drive size, number of channels, and camera configuration may vary by model. Please refer to your package for specific details.

  • Page 13: Recorder Overview

    NETWORK: Glows when network is in normal state. Turns off when there is a net- work error. 3.2 Back Panel 1. Video Inputs: Connect Lorex HD or standard analog cameras to the system. For a full list of compatible cameras, visit lorex.com/compatibility.

  • Page 14: Basic System Setup

    This step is for verification of the camera image only. It is recommended to connect cameras to a nearby power adapter for this step. The Lorex Setup Wizard that runs at startup will assist you in naming and organizing your cameras, so it is also recommended to leave cameras connected until the wizard asks you to install cameras in their permanent mounting location.

  • Page 15: Step 4: Connect Monitor

    Basic System Setup 4.4 STEP 4: Connect monitor Connect the recorder to a monitor using the included HDMI cable. Connect the recorder to a monitor using a VGA cable (not included). CAUTION The system will automatically match the resolution of the connected monitor the first time you use the recorder. If you need to switch monitors, make sure you set the recorder to an output resolution supported by the new monitor BEFORE switching.

  • Page 16: Step 6: Lorex Setup Wizard

    Basic System Setup 4.6 STEP 6: Lorex Setup Wizard When you first power up your recorder, the Lorex Setup Wizard will begin. The Wizard will help you configure core system settings and set up your cameras. It is recommended to review 5 Camera Installation, page 10 before choosing a permanent mounting position for your cameras.
  • Page 17 Basic System Setup To quickly open a window that displays important system information: • From the Live View display, right-click to open the Quick Menu, then click Info. #LX400111; r. 3.0/56507/56507; en-US...

  • Page 18: Camera Installation

    Ensure that you review 5.2 Ensuring Accurate Person/Vehicle Detection, page 10 for chan- nels you are planning to use Person/Vehicle detection on. NOTE Cameras differ in terms of mounting instructions. Please see your camera’s documentation at lorex.com for spe- cific installation instructions. 5.1 Installation Tips General camera installation tips that apply to all camera models.

  • Page 19: Installing Cameras

    5.3 Installing Cameras 1. Mount the cameras to the desired mounting surface according to the instructions that came with the cameras (visit lorex.com for the most up-to-date documentation). Choose a firm mounting surface that can support the full weight of the camera.

  • Page 20: Connecting Camera Extension Cables

    For all extension cable options, including maximum extension cable length, refer to your camera’s documentation at lorex.com. 1. Connect the male power connector on the BNC extension cable to the female power connec- tor on the camera.

  • Page 21: Using The Mouse

    Using the Mouse The mouse is the primary control device for the system. Connect the included mouse to the USB port on the front or rear panel. 1. Left-button: • In live view, while in a split-screen display mode, click an individual channel to view it in full-screen.

  • Page 22: Using The On-Screen Display

    Using the On–Screen Display Use the system’s on–screen display to navigate menus and configure options and settings. NOTE To access the on-screen display, you must connect the included mouse and a monitor (not included) to the re- corder. See , page for full instructions. 7.1 Navigation Bar The Navigation Bar along the bottom of the recorder’s Live View display allows you to access the Main Menu and control basic functions of the recorder.

  • Page 23: Camera Toolbar

    Using the On–Screen Display • Right-click anywhere on the Live View screen. 1. Main Menu: See 14 Using the Main Menu, page 44 for full instructions on using the Main Menu. 2. Playback: Opens the Playback Menu. This allows you to search for video recordings saved on the recorder’s hard drive.

  • Page 24: On-Screen Keypads

    Using the On–Screen Display 4. Snapshot: Save a snapshot of the current camera image to a USB flash drive (not included). 5. Mute/Unmute: Click to mute/unmute listen-in audio. 6. Warning Light — Deterrence Cameras Only: Click to manually turn on the camera’s warning light for 10 seconds.

  • Page 25: Recording

    Recording By default, the system is set to immediately record video from connected cameras continuously, 24 hours a day. You can customize the recording settings according to your needs. 8.1 Video Recording Types The system supports the following recording types: •...

  • Page 26: Setting The Recording Schedule

    Recording 4. Configure the following settings. Except where noted, options for Main Stream and Sub Stream are the same: • Super Codec: (Main Stream only) Click to enable ( ) / disable ( ) Super Codec. This setting will help reduce system requirements for unimportant recordings to maximize hard drive storage.

  • Page 27: Setting Up Scheduled Or Manual Recording

    Recording 2. Click STORAGE. Click the SCHEDULE tab on the side panel, then Record on the top panel. 3. Under Channel, select the channel you would like to configure or select All. 4. Configure the schedule as needed: • Check Continuous, MD (Motion Detection), or Alarm to select the recording type you would like to configure.

  • Page 28: Configuring Hard Drive Overwrite

    Recording To set options for manual recording: 1. From the Live View display, right-click to open the Quick Menu, then click Manual Record. 2. Under Main Stream, select how the system will record the Main Stream for each channel: • Auto: Main Stream recording will follow the recording schedule. •...

  • Page 29: Playback

    Playback Search through and playback recorded video files on the system. 9.1 Playing Back Video from the Hard Drive To play back recorded video: 1. From the Live View display, right-click to open the Quick Menu, then click Playback. 2. Use the calendar on the right to select the day to playback. 3.
  • Page 30 Playback 4. Viewing Modes: • Bookmark List: Shows all bookmarked recordings for a single channel on the se- lected date. • File List: Shows all available recordings for the selected date and channel(s) in list format. • Fullscreen: Shows video in fullscreen. Right-click to return to split-screen viewing.

  • Page 31: Playing Back Video From A Usb Drive

    Playback 8. Playback Controls: • Play / Pause • Stop • Play Backwards • Previous Frame: Go to the previous frame when video is paused. • Next Frame: Go to the next frame when video is paused. • Slow Playback: Click repeatedly to slow the video down by half speed up to 16× slower than normal.

  • Page 32: Smart Search

    Playback For full instructions on backing up video to a USB flash drive, see 10 Backup, page 27. To play back video from a USB flash drive: 1. Connect the USB thumb drive (not included) with video files on it into a free USB port on the recorder.

  • Page 33: Video Clip Backup

    Playback To perform a Smart Search: 1. From the Live View display, right-click to open the Quick Menu, then click Playback. 2. Use the calendar on the right to select the day to playback. 3. Check a single channel you want to play back. Click the icon to the right of the channel name to choose the video quality ( for Main Stream, for Sub Stream).
  • Page 34 Playback 3. Use the calendar on the right to select the day to playback. 4. Check the channels you want to play back. Click the icons to the right of each channel name to choose the video quality ( for Main Stream, for Sub Stream).

  • Page 35: Backup

    Backup Backup video files to external USB flash drive (not included). 10.1 Formatting the USB Flash Drive It is recommended to format your USB thumb drive (not included) before using it with the system. CAUTION Formatting the USB device will permanently erase all data. This step cannot be undone. Prerequisite: •...

  • Page 36: Using Video Clip Backup

    10.4 Viewing Backed Up Files Use the free Lorex Player to play back .dav files. 10.4.1 Viewing Backed Up Files on PC 1. Download and install the Lorex Player for PC from the recorder’s product page at lorex.com #LX400111; r. 3.0/56507/56507; en-US...

  • Page 37: Viewing Backed Up Files On Mac

    2. Double-click one of the files on the left to begin playback. Click to open a back up video file in another location 3. Use the Lorex Player controls to control playback or select other files for playback. NOTE For a full overview of Lorex Player controls, see 10.4.3 Lorex Player Controls, page 30.

  • Page 38: Lorex Player Controls

    Backup 10.4.3 Lorex Player Controls 1. File List: Double-click to open a file. 2. Viewing Mode: Select between single-channel viewing and various split-screen options. 3. Hide/Show File List 4. Playback Controls: • : Playback files in sequence. • : Synchronize playback times.
  • Page 39 Backup 9. Digital Zoom: Click, then click-and-drag over a camera image to zoom in. Right-click to re- turn to the full image. 10. Drag: Click, then click-and-drag to move around a camera image that has been digitally zoomed in. 11. Fullscreen: Click to open the player in full screen. Press ESC to exit full screen. 12.

  • Page 40: Motion Detection

    Motion Detection In addition to general motion detection, the system supports smart Person/Vehicle detection. Both types of detection can be configured using the menu shown below. 11.1 Configuring Motion Detection Set preferences for motion detection on each channel, and select channels you want to enable smart Person/Vehicle detection on.
  • Page 41 Motion Detection 5. Click Setup next to Area to configure which areas of the image will be enabled for motion detection. A grid will appear on the monitor: • The camera image appears with a red grid overlay. This means the entire image is enabled for motion detection.
  • Page 42 Motion Detection 7. Choose how the system will react when motion is detected: • Show Message: Check to enable an on-screen pop-up when one of your cameras detects motion. On-screen pop-up shows the channels an event occurred on and the type of event. •...
  • Page 43 Motion Detection 8. Click Smart Motion Detection to enable Person/Vehicle detection: NOTE See 5.2 Ensuring Accurate Person/Vehicle Detection, page 10 for important camera installation notes related to channels with Person/Vehicle detection enabled. #LX400111; r. 3.0/56507/56507; en-US...
  • Page 44 Motion Detection #LX400111; r. 3.0/56507/56507; en-US...

  • Page 45: Search For Person/Vehicle Detection Events

    Motion Detection • Click Enable to activate Person/Vehicle detection on the selected channel. CAUTION A maximum of 2 channels will support Person/Vehicle detection at once. By default, channels 1 and 2 have Person/Vehicle detection enabled. • Select a Sensitivity level (a high sensitivity value will detect smaller objects than a low value).

  • Page 46: Active Deterrence

    The recorder allows you to customize automatic light-triggering when motion is de- tected to deter intruders (see 12.1 Automatic Deterrence Settings, page 38). You can also trigger the lights and sirens manually using the recorder or Lorex connectivity software (see 12.2 Man- ually Activate Deterrence Features, page 39).

  • Page 47: Manually Activate Deterrence Features

    • Activate deterrence features using the Lorex Home app. For details, see , page . To activate deterrence features on all connected cameras: • From the Live View display, click on the Navigation Bar.

  • Page 48: Managing Passwords And User Accounts

    Managing Passwords and User Accounts Passwords are enabled by default and are required to access the Main Menu or connect to the system using a computer or mobile device. You will be prompted to create a custom password after you connect for the first time. NOTE If you forget the password to the system, contact technical support to have it reset.

  • Page 49: Adding Users

    Managing Passwords and User Accounts 13.1.2 Adding Users You can allow multiple users to log in to the system. When adding different users, you can assign what menus they have access to. For example, you may want your friend to monitor your system while you are away, while not giving full access to your system.

  • Page 50: Modifying Users

    Managing Passwords and User Accounts 5. Click OK. NOTE Now, you can log in to the system locally, or remotely using the user name and password you created. When logging into the system with a user account, the user will only have access to the menus you assigned. 13.1.3 Modifying Users Modify account details, such as account username or permissions.

  • Page 51: Modifying Groups

    Managing Passwords and User Accounts 3. Click Add Group. 4. Configure the following: • Group Name: Enter a name for the group. • Memo: (Optional) Enter a description of the group. • Authority: Check the permissions you would like the user account to have. Under the System tab, select the menus the user account may access.

  • Page 52: Using The Main Menu

    Using the Main Menu To access the main menu: • From the Live View display, right-click to open the Quick Menu, then click Main Menu. • Click on the Navigation Bar, then click Main Menu. 14.1 Playback See chapter 9 Playback, page 21 for details. 14.2 Alarm Set preferences for alarm events such as video loss, motion detection, Person/Vehicle detection, and system warnings.

  • Page 53: Video Loss

    Using the Main Menu 6. Alarm events that match your search criteria are displayed: • The Event column is formatted to show <[Event Type]: [Channel Number]>. • Click Details to see more information on the selected event. • Motion events have more options than other alarm events. You can view the event by clicking in the Playback column, or back up the video clip to a USB flash drive (not included) by clicking Backup.

  • Page 54: System Warnings

    Using the Main Menu 6. Choose how the system will react when video loss occurs: • Show Message: Video loss error message will appear on the recorder’s display. • Record Channel: Select the numbered tiles next to this option to record video from the corresponding channels.

  • Page 55: Backup

    Set the system’s monitor resolution, configure Sequence mode, and other display settings. 14.4.1 Setting the Recorder’s Output Resolution The first time you power up the system and complete the Lorex Setup Wizard, the system will automatically match the resolution of the connected monitor. You can set the recorder to a differ- ent output resolution at any time.

  • Page 56: Listen-In Audio

    Using the Main Menu 2. Click DISPLAY, then click the DISPLAY tab. 3. Click Apply. The recorder will restart before changes take effect. 14.4.2 Listen–In Audio Enable and set volume for camera audio feeds in the Live View display. NOTE Audio will only be heard if you are viewing an audio-enabled camera in single-channel view.

  • Page 57: General Display Settings

    Using the Main Menu 2. Click DISPLAY, then click the DISPLAY tab. 3. Set the desired transparency value. The transparency of the current menu will update in- stantly to show how other menus will be affected. 4. Click Apply. 14.4.4 General Display Settings Configure miscellaneous display settings.

  • Page 58: Customize Split-Screen Views

    Using the Main Menu 14.4.5 Customize Split-Screen Views For each of the split-screen viewing modes, you can customize the order that channels are dis- played on screen. To customize viewing modes: 1. From the Live View display, right-click to open the Quick Menu, then click Main Menu. 2.

  • Page 59: Camera

    Using the Main Menu 2. Click DISPLAY, then click the SEQUENCE tab. 3. Click to enable ( ) / disable ( ) Sequence mode. NOTE • Enabling Sequence mode is not necessary for configuration. • You can also enable Sequence mode from Live View by clicking on the Navigation Bar, or by right-clicking to open the Quick Menu and clicking Sequence.

  • Page 60: Configuring Snapshot Recording

    Using the Main Menu 2. Click CAMERA, then click the IMAGE SETTINGS tab. 3. Select the channel you want to configure. 4. Select COAXIAL for cameras connected using BNC cabling, or UTP for balun installations. 5. Configure the color settings for the selected channel. 6.

  • Page 61: Changing On-Screen Overlay

    Using the Main Menu 14.5.3 Changing On-Screen Overlay Remove or change the location of the date/timestamps and channel names. You can also change channel names from this menu. To change the on-screen overlay: 1. From the Live View display, right-click to open the Quick Menu, then click Main Menu. 2.

  • Page 62: Connecting Multi-Format Cameras (Cable Type)

    Using the Main Menu 3. Select the channel you want to configure. 4. Configure the following settings: • Preview: Check to set and preview privacy masks. • 1–4: Click the numbered boxes to create a corresponding privacy mask on the camera image.

  • Page 63: Network

    Using the Main Menu 2. Click CAMERA, then click the CVI UPGRADE tab. 3. Click Browse to search for the .bin firmware file on the USB flash drive. 4. Check cameras you would like to upgrade using the selected firmware file. 5.

  • Page 64: Configuring System Ports (Connection)

    Using the Main Menu 14.6.2 Configuring System Ports (Connection) Configure ports used by the system. If you are using DDNS connectivity, port forwarding is re- quired for the HTTP Port (default: 80) and TCP Port (Client Port) (default: 35000). NOTE Port forwarding is not required unless you are using DDNS for remote access.

  • Page 65: P2P Setting

    CAUTION P2P connection is the primary method used for remote access to your security system using the Lorex Home app. If you disable P2P connectivity, you will only be able to access your system over the Internet using DDNS. See 19 DDNS Setup (Advanced), page 87 for details.

  • Page 66: System

    Using the Main Menu 2. Click NETWORK, then click the P2P SETTING tab. 3. Click to enable ( ) / disable ( ) P2P connectivity. 4. Click Apply. 14.7 System Configure general system settings, such as date & time, time zone, and DST. It also allows you to check for firmware updates over the Internet and restore the system to default settings.

  • Page 67: Configuring Holidays

    Using the Main Menu CAUTION It is important to always ensure your system date and time are accurate. Inaccurate time stamps may render your footage unusable for court evidence. To set system date and time: 1. From the Live View display, right-click to open the Quick Menu, then click Main Menu. 2.

  • Page 68: Configuring Ip Filter

    Using the Main Menu To configure holidays: 1. From the Live View display, right-click to open the Quick Menu, then click Main Menu. 2. Click SYSTEM. Click the GENERAL tab on the side panel, then Holiday on the top panel. 3.

  • Page 69: Save System Settings To A Usb Flash Drive

    Using the Main Menu 2. Click SYSTEM, then click the SECURITY tab. 3. Under Type, select which type of filter to apply: • Network Access — Whitelist: IP addresses that are permitted to access the recorder. • Network Access — Blacklist: IP addresses that are not permitted to access the recorder. •...

  • Page 70: Import System Settings From A Usb Flash Drive

    Using the Main Menu 3. Under Device Model, select the USB device where you would like to save the configuration. 4. Click Export to save your current system configuration. 14.7.6 Import System Settings from a USB Flash Drive If you have backed up your system configuration, you can import it to apply all your saved menu settings.

  • Page 71: Upgrading Firmware Manually

    Using the Main Menu 14.7.8 Upgrading Firmware Manually The primary method for upgrading system firmware is automatically over the Internet. The sys- tem also supports firmware upgrades from a USB thumb drive (not included). Prerequisite: • Save the .bin firmware file for your unit onto a USB flash drive (not included), and connect the drive to one of the system’s free USB ports.

  • Page 72: Configuring Recording File Length

    Using the Main Menu 2. Click STORAGE, then click the BASIC tab. 3. Ensure HDD Full is set to Overwrite to overwrite the oldest recordings when the hard drive is full. NOTE Selecting Stop Record for the system to stop recording when the hard drive is full. 4.

  • Page 73: Setting The Snapshot Schedule

    Using the Main Menu 2. Click STORAGE. Click the SCHEDULE tab on the side panel, then Record on the top panel. 3. Under Channel, select the channel you would like to configure or select All. 4. Set the duration for pre-recording in seconds. 5.

  • Page 74: Formatting The Hard Drive

    Using the Main Menu 4. Configure the schedule as needed: • Check Continuous, MD (Motion Detection), or Alarm to select the recording type you would like to configure. • Click-and-drag on each day to customize the recording schedule. The schedule is set up as a grid, which each block representing one hour.

  • Page 75: Recording Calculator (Rec Estimate)

    Using the Main Menu 2. Click STORAGE, then click the HDD MANAGER tab. 3. Under Type next to the hard drive you want to configure, select Read/Write or Read only. 4. Click Apply. 14.8.7 Recording Calculator (REC Estimate) Use the recording calculator to get an estimate of your maximum recording time in days for the installed hard drive, or how much hard drive space would be required to retain a specific amount of days.

  • Page 76: Account

    Using the Main Menu To configure FTP settings: 1. From the Live View display, right-click to open the Quick Menu, then click Main Menu. 2. Click STORAGE, then click the FTP tab. 3. Click to enable ( ) / disable ( ) FTP connection, and select either FTP or SFTP depending on your configuration.

  • Page 77: Log

    Using the Main Menu To access the Version menu: 1. From the Live View display, right-click to open the Quick Menu, then click Main Menu. 2. Click INFORMATION, then click the VERSION tab. 14.10.2 Log The Log menu allows you to search for system logs. To search for system logs: 1.

  • Page 78: Hdd Info

    Using the Main Menu The following alarms are shown in the Event Status menu: • No HDD: No Hard drive is detected. • Disk Error: Hard drive error detected. • Disk Full: Hard drive is full. • Net Disconnection: System is not connected to the network. •...

  • Page 79: Network Test

    Using the Main Menu To access the Load menu: 1. From the Live View display, right-click to open the Quick Menu, then click Main Menu. 2. Click INFORMATION. Click the NETWORK tab on the side panel, then LOAD on the top panel.
  • Page 80 Using the Main Menu 2. Click Apply to save the settings for that channel. 3. Click Copy. 4. Click the numbered boxes to indicate the channels you want to copy settings to, or click All to copy to all channels. 5.

  • Page 81: Smart Home & Voice Assistance

    Audio recording and / or use of listen-in audio without consent is illegal in certain jurisdictions. Lorex Corporation assumes no liability for use of its prod- ucts that does not conform with local laws.

  • Page 82: Pan/Tilt/Zoom (Ptz) Cameras

    16.1 Connecting PTZ Cameras to the Recorder Lorex HD PTZ cameras connect to your recorder just like any other camera with no need to run special wiring — these cameras can accept PTZ commands directly through the video cable.

  • Page 83: Basic Ptz Controls

    4. Configure the highlighted fields as needed. NOTE For Lorex HD PTZ cameras, there is no need for configuration — leave all fields at their default values. For third-party PTZ cameras, select Serial next to Control Mode. For the correct settings to use in the remain- ing fields, please reference your camera documentation.

  • Page 84: Advanced Ptz Controls

    Pan/Tilt/Zoom (PTZ) Cameras 1. Navigation Controls: Click the directional arrows to move the PTZ camera manually. 2. Zoom-to-Area: Click, then click-and-drag to draw a box on the camera image. The PTZ camera will zoom in to the selected area. 3. Mouse Tracking: Click to enable/disable mouse tracking. When enabled, click-and-drag in the direction you would like the PTZ camera to move.

  • Page 85: Presets

    Pan/Tilt/Zoom (PTZ) Cameras 4. Tour: Perform the tour number specified in the No. field. For instructions on creating a tour, see 16.5 Tours, page 77. 5. Flip: Rotate the camera 180° from its current position. 6. Pattern: Perform the pattern number specified in the No. field. For instructions on creating a pattern, see 16.6 Patterns, page 77.

  • Page 86: Autoscan

    Pan/Tilt/Zoom (PTZ) Cameras 5. Move the camera to the desired starting position, then click Start. 6. Using the on-screen controls, move the camera in any pattern you wish. When finished, click End. To run a pattern: • Under No., select the number of the pattern you want to go to, then click 16.7 AutoScan An autoscan automatically cycles between a left and right point.

  • Page 87: Connecting Audio Devices

    Connecting Audio Devices The system supports Lorex HD audio cameras, which transmit audio through the same coax ca- ble used for video connection. The system can also record one audio channel using the AUDIO IN port on the rear panel. You must have a self-powered microphone or an audio camera with an RCA–type audio connection to use this port.
  • Page 88 ) audio recording. CAUTION Audio recording and / or use of listen-in audio without consent is illegal in certain jurisdictions. Lorex Corporation assumes no liability for use of its products that does not conform with local laws. • Audio Format: Choose the desired format for audio recording (G711a or AAC recommended).
  • Page 89 ) audio recording. CAUTION Audio recording and / or use of listen-in audio without consent is illegal in certain jurisdictions. Lorex Corporation assumes no liability for use of its products that does not conform with local laws. • Audio Format: Choose the desired format for audio recording (G711a or AAC recommended).

  • Page 90: Replacing The Hard Drive

    Replacing the Hard Drive The system comes with a pre-installed 3.5" SATA hard drive. You can replace the hard drive with one up to a maximum size of 10TB. 18.1 Removing the Hard Drive CAUTION Make sure that the system is OFF and the power adapter is disconnected before removing/installing a hard drive. To remove the hard drive: 1.

  • Page 91: Installing A New Hard Drive

    Replacing the Hard Drive 4. Remove the power and SATA cables from the hard drive. 5. Carefully pick up the hard drive to lift the bottom panel, being mindful of the sharp edges of the bottom panel. Remove the hard drive screws (4×) from the bottom panel. Hold onto the hard drive so it remains in place when all screws have been removed.
  • Page 92 Replacing the Hard Drive To install a new hard drive: 1. Insert the 2 hard drive screws closest to the SATA and power ports on the hard drive and tighten them half way. 2. Power off the system, and unplug all cabling from the system. 3.
  • Page 93 Replacing the Hard Drive 4. Turn the recorder over carefully, then remove the top panel. CAUTION The wiring to the front panel button and USB port runs along the top panel of the recorder. When separating the top panel, rest it carefully beside the bottom panel as shown below. 5.
  • Page 94 Replacing the Hard Drive 6. Carefully pick up the bottom panel with the hard drive, being mindful of the sharp edges of the bottom panel. Slide the 2 pre-inserted screws into the locked position, then tighten the screws. Insert and tighten the 2 remaining hard drive screws. 7.

  • Page 95: Ddns Setup (Advanced)

    Login at the top of the page. 2. Select Create an Account. NOTE If you have already set up an account, select I Have a LOREX Account and log in. Proceed directly to , page . #LX400111; r. 3.0/56507/56507; en-US...

  • Page 96: Step 3: Activate Your Warranty

    19.3 STEP 3: Activate Your Warranty Activate the manufacturer’s warranty on your recorder. To activate your product warranty: 1. From your Lorex account, click the WARRANTIES tab. 2. Click Activate Warranty. 3. Enter your product information (attaching bill of sale optional).

  • Page 97: Step 5: Enable Ddns On The Recorder

    19.5 STEP 5: Enable DDNS on the Recorder Enter your DDNS information into the menu of your recorder. You can find the information ref- erenced below on your My Lorex account, or on the confirmation email sent to you after regis- tering for DDNS service.

  • Page 98: Troubleshooting

    Troubleshooting When a malfunction occurs, it may not be serious or difficult to correct. The following chart con- tains solutions to most common problems. Please refer to the topics below before calling Lorex Technical Support. Error Possible Causes Solutions System is not receiving power, or Cable from power adapter is loose •...
  • Page 99 See 15 Smart Home & Voice Assis- tance, page 73 for full instructions. • If the issue persists, visit lorex.com/SmartHome complete setup instructions, FAQS, and a list of available voice commands. #LX400111; r. 3.0/56507/56507; en-US...

  • Page 100: Technical Specifications

    Technical Specifications 21.1 General Video Transmission HD Analog Technology 4 Channels Channels 21.2 Inputs/Outputs 4 × 1Vp-p BNC Type Video Input(s) 1 × VGA, 1 × HDMI Video Outputs(s) Audio Input(s) 1 ch: RCA Audio Output(s) 1 ch: RCA 21.3 Display Display Output Resolution 1080P, 720P Live Display...

  • Page 101: Connectivity

    Technical Specifications 21.8 Connectivity Mobile Viewing Android, iOS Compatible App Lorex Home™ PC/MAC Remote Viewing Yes/Lorex Cloud Email Notification Text and Snapshot Network Interface 10/100 Base-TX, RJ45 DDNS Yes (Optional) USB Interface USB 2.0 × 2 21.9 Additional Specifications FW Upgrade...

  • Page 102: Notices

    Notices This product has been certified and found to comply with the limits regulated by FCC, EMC, and LVD. Therefore, it is designated to provide reasonable protection against interference and will not cause interference with other appliance usage. However, it is imperative that the user follows the guidelines in this manual to avoid improper usage, which may result in damage to the product, electrical shock and fire hazard injury.
  • Page 104 Legal disclaimer As our product is subject to continuous improvement, Lorex Corporation & subsidiaries reserve the right to modify product design, specifications & prices without notice and without incurring any obligation.E&OE.
