2.1.8
Front I/O connector
To install front panel connector
To install front panel audio connector
AAFP
To install USB 3.2 Gen 1 connector
To install USB 2.0 connector
USB 3.2 Gen 1
USB 2.0
This connector will only fit in one orientation. Push the connector until it clicks into place.
ROG STRIX B550-A GAMING
2-11
