- Page 1 203471KE (B1 ~ B3) EASTERN KING SIZE BED ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE www.coastercompany.com PAGE 1 OF 6 REVISION 0: 04/01/2014...
-
Page 2: Assembly Tips
203471KE (B1 ~ B3) ITEM : ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1 . Remove hardware from box and sort by size. 2 . Please check to see that all hardware and parts are present prior to start of assembly. 3 . Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. -
Page 3: Hardware Identification
203471KE (B1 ~ B3) ITEM : ASSEMBLY INSTRUCTIONS HARDWARE IDENTIFICATION HARDWARE PACK IS HARDWARE PACK IS Z - B2 (BOX 2) Z - B1 (BOX 1) LOCATED IN 203471KE (B2) LOCATED IN 203471KE (B1) BOLT 6PCS BOLT 4PCS SMALL ALLEN WRENCH... - Page 4 Headboard & Leg "R" Marking behind the Headboard & Leg 203471KE (B1~B3) - BOX 1 TO BOX 3 STEP 2 2.1 Loosen the bolt and align and fasten bed rail (M) to headboard (HB) and footboard (D) using the bolt and fully tighten with big Allen wrench (7).
- Page 5 203471KE (B1 ~ B3) ITEM : ASSEMBLY INSTRUCTIONS STEP 3 3.1 Align and fasten drawer bottom trestle bar support with leveler (K) to drawer bottom trestle bar support (L) and drawer bottom trestle bar (H) by turning clockwise until tight.
- Page 6 203471KE (B1 ~ B3) ITEM : ASSEMBLY INSTRUCTIONS STEP 5 5.1 Align and fasten bed slat with 3 holes (G) to center rail (N) and bed slat support with leveler (J) using bolt (5) and tighten with small Allen wrench (6).Adjust leveler to touch the floor.
