Room&Board ASHBY Assembly Instructions

Step 1: Lay the Base Frame on top of the Feet, and secure using 4
Decorative Nickel Bolts and Lock Washers. (Base Frame should be
oriented so that the countersunk holes face the floor.)
Step 2: Place one of the End Panels on the left side of the Base Panel
so that the silver metal inserts are facing inward. Use 2 Decorative
Nickel Bolts and Lock Washers to secure the End Panel to the Base
from underneath the Base Frame, but DO NOT tighten the Bolts
completely yet. Repeat this procedure on the right.
Step 3: Attach one of the Sides to the End Panels with 4 Decorative
Nickel Bolts and Lock Washers using the enclosed Z Wrench. Place
the Bolts through the end slat of the Side and into the End Panel, but DO
NOT tighten completely.
Step 1: Attach Feet to Base
Step 2: Attach End Panels to Base
Step 3: Attach Side to End Panels

CRIB ASSEMBLY INSTRUCTIONS

For ASHBY Crib
DO NOT USE POWER TOOLS!
Step 4: Screw a Bronze Bolt and Lock Washer in each of the top
holes of the center columns of inserts on the End Panels. Leave the bolts
sticking out about an inch. This configuration puts the Mattress in the highest
position, which is the height recommended for newborns. To select a lower
position, place the bolts in lower holes. Place the Mattress Support
Platform over the Bolts. The notches in the Platform fit snugly over the
Bolts.
Step 5: Attach the other Side to the End Panels as in step 2. Now tighten
all 16 Bolts on crib completely.
