TY-51095L Air Impact Wrench
TY-51095L Pneumatic Impact Wrench Passport
Upon receipt of the TY-51095L Air Impact Wrench,
read and follow all safety information and operating instructions before first use.
Retain this passport for future reference
Tarboya Pneumatic Tools Co., Ltd
www.tarboyatools.com
9938501|TY-51095L Passport
/ 1 11
Advertisement
Table of Contents
Related Manuals for Tarboya TY-51095L
Summary of Contents for Tarboya TY-51095L
- Page 1 TY-51095L Air Impact Wrench TY-51095L Pneumatic Impact Wrench Passport Upon receipt of the TY-51095L Air Impact Wrench, read and follow all safety information and operating instructions before first use. Retain this passport for future reference Tarboya Pneumatic Tools Co., Ltd www.tarboyatools.com...
-
Page 2: Table Of Contents
TY-51095L Air Impact Wrench Content This passport is a single document, combined with a technical description and operating instructions, and consists of the following sections: 1.General Information………….……………………….……….……………………………………………….……3 Graphical Symbols……………………………………….………………………………………….3 2.Description……………………….…….…..……………………………………………………………….…….…3 Overview……………………………………………………………………..……………………….3 3.Warranties……….……………….………………………………………………………………………….……….3 4.Safety Considerations.…………………………………………..…………………………………………….……3 Personal Injury Protection……………………………………………………………..……………4 Installation, precautions…………………………………………………………………………..…4 Operation, precautions………………………………………………………………………………4 5.Technical Specifications….…..….…..……..…………………………………………………………….……….. -
Page 3: General Information
The robust six-vane motor is fine-tuned to install and remove threaded fasteners with ease. 3. Warranties Tarboya warrants TY-51095L will not have any material or manufacturing defects for the period of 12 months from the date of delivery. The warranty for flawless function of the goods and the materials used is granted for the period of 12 months from the date of delivery of the goods. -
Page 4: Personal Injury Protection
Put the machine into service only if the supply pressure hose is not damaged. • Check the pressure hose and air connections regularly. If damaged, have them replaced in the service authorized to carry out such repairs. Contact Tarboya Personal Injury Protection •... -
Page 5: Technical Specifications
TY-51095L Air Impact Wrench An impact wrench left unattended, or with the air hose attached, can be activated by unauthorized persons leading to their injury or injury to others. • Remove air hose when tool is not in use and store tool in secure location away from reach of children and untrained users. -
Page 6: Elements
TY-51095L Air Impact Wrench MODEL TY-51095L DRIVE 1” ANVIL LENGTH 8” SPEED 3,300 RPM BOLT CAPACITY 50MM APPLIED TORSION 1,300-3,500Nm MAX TORQUE 3,800NM HAMMER MECHANISM ROCKING DOG CLUTCH AIR CONSUMPTION 27.5CFM AIR PRESSURE 0.63MPa AIR INLET 1/2” AIR HOSE 1/2”... -
Page 7: Installation
TY-51095L Air Impact Wrench 7.Installation Prior to use The impact wrench requires the attachment of a quick-connector into its air inlet. To do so, wrap approximately 3" of pipe thread sealer tape (not included) around the male threads of a quick-connector. -
Page 8: Operation
• After each service, check that the machine's vibration level is normal. If not, contact your nearest authorized workshop. For more information, contact Tarboya. Every day Before undertaking any maintenance or changing a piston on the Air Impact Wrench, always switch off the air supply, bleed the machine by depressing the start and stop device, and disconnect the air hose from the machine. -
Page 9: Periodic Maintenance
A copy of this passport is supplied with each machine TY-51095L.All rights reserved. No part of this publication may be reproduced without prior consent granted by Tarboya Manufacturer’s Address... -
Page 10: Troubleshooting
TY-51095L Air Impact Wrench 10. Troubleshooting Problem Possible Cause Solution There is grit or gum in the Flush the tool with air tool oil or gum solvent tool. The tool is out of oil. Lubricate the tool • Adjust the regulator on the tool to the maximum setting The air pressure is low. -
Page 11: Exploded View
TY-51095L Air Impact Wrench 11. Exploded View No. Description No. Description Description No. Description Hex Screw(4 pcs) Gasket Spring Pin Spring Pin Spring Washer(8 pcs) 16 D Handle Gasket O Ring Oil Seal Washer(4 pcs) Protecting Jacket Hex Screw Hammer Case...
