- Page 1 Elastix Appliance Assembly Process Guide ELX-3000 PaloSanto Solutions January, 2012 ...
-
Page 2: Individual Parts
INDIVIDUAL PARTS Hardware Brand Model Type Notes: Mainboard Intel D525MW Innovation Hardware included: Series - SATA drive data cable Processor Intel Dual Core Intel® Intel® NM10 Express Chipset Atom™ processor D525 Memory Kingston / Corsair DDR3 800/1066/1333 2 GB Up to 4 GB Hard Drive Seagate / Samsung... -
Page 3: Pre-Installation
ELX-3000 Connect the Power Cord Cable to the PSU connector on the back of the ELX-3000 and then to a nearby outlet Press the power button to turn on the appliance Place in the optical drive a CD or DVD containing the latest Elastix stable 32 bits version found in http://sourceforge.net/projects/elastix/files/Elastix%20PBX%20Appliance%20Software/... - Page 4 Reboot the appliance if necessary until the following screen is displayed: ELASTIX INSTALLATION Press ENTER to begin the installation Select English as the language for the installation: ...
- Page 5 Select as the type of keyboard: Choose “Remove all partitions on selected drives and create default layout.”: ...
- Page 6 Confirm the removal of the partitions by selecting Yes: Choose not to review or modify the partitioning layout: ...
- Page 7 Select to configure the Network Interface: Select to activate on boot and to enable IPv4 support: ...
- Page 8 Manually assign the IP address 192.168.1.251 / 24: Enter 192.168.1.1 as the Gateway and Primary DNS addresses: ...
- Page 9 Type elx.palosanto.com as the hostname: Select the time zone according to the city where the appliance is going to be used in: ...
- Page 10 Type palosanto as the password for root: Wait until the package installation finishes: ...
- Page 11 After the automatic reboot, type palosanto as the password for the MySQL root user: Reenter the MySQL root user password just typed: ...
- Page 12 Type palosanto as the password for the admin user: Reenter the password for the admin user just typed: ...
-
Page 13: Post Installation Tests
04e0a1db3707367c7030e476418416a7 Confirm correct access to Elastix’s web UI is possible: Connect the Ethernet port on the ELX-3000 to a free Ethernet port on a computer nearby (using a normal Ethernet straight-thru patch cord) b. Configure that NIC on the computer with IP address 192.168.1.1 (mask 255.255.255.0) From a web browser on the computer go to the URL: https://192.168.1.251... - Page 14 Place and screw both covers to the top of the case Place the warranty seals on all three outside edges on the case’s top cover (the cover with the Elastix logo) Generate and place the label with the Serial Number on the right side of the case (when the power button is...
