Installation Instructions and Homeowner s Manual
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HO MEOWNER
ELECTRIC FIREPLACE
MODEL NO. OL-L6G
WARNING! IF INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY, DO NOT STO RE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS
IN THE VICINITY OF THIS OR AN Y OTHER APPLIANCE.

Advertisement

Table of Contents
loading

Related Manuals for Olmo OL-L6G

Summary of Contents for Olmo OL-L6G

  • Page 1 INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HO MEOWNER ELECTRIC FIREPLACE MODEL NO. OL-L6G WARNING! IF INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

  • Page 2: Table Of Contents

    Thank you and congratulations on your purchase of a OLMO fireplace. Table Of Contents IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, fire hazard and will void the guarantee.

  • Page 3: Measure

    Measure 20mm 250mm 0.79 895mm 9.84 35.23 48mm 1.89 810mm 31.89 700mm 27.56 Hot air extra Power/Flame switch 0.9kw output Cold air enter 1.8kw output...

  • Page 4: General

    Installation Instructions General 1. Read all instructions before using the appliance. 16. This appliance has hot and arcing or sparking parts 2. This appliance is hot when in use. To avoid inside. Do not use it in areas where gasoline, paint, burns, do not let bare skin touch hot surfaces.

  • Page 5: Electrical Connection

    Electrical Connection WARNING: Electrical outlet wiring A 10 AMP,220 Volt, 50 Hz circ uit with a properly must comply with local building codes grounded outlet is required. Preferably, the fireplace and other applicable regulations to will be on a dedicated circuit as other appliances on reduce the risk of fire, electrical shock the same circuit may cause the circuit breaker to trip or and injury to persons.

  • Page 6: Replacing The Light Bulbs

    Replacing the Light Bulbs This fireplace uses one or two clear 220Volt, 60 Watt, E-14 socket base light bulbs (small base, chandelier candle type). The 60 Watt bu lbs are located under the log set/ember bed. 1. Turn off the power switch and unplug the power cord. Fig 1 2.

  • Page 7: Assembling Instruction

    Assembling Instruction Part Description Part Description Item # Part # Item # Part # Mantel 3004126 Ember Bed 3004208 Ribbon Bracket 3004134 Bottom 3004218 Backing Strip 3004144 Upside Front Fret 3004320 Screw 1002150 Bulb/Holder 1002030 Screen Bracket 3004277 Flame Fan 1002014 Acrylic Screen 1002108...

  • Page 8: Operating Instruction

    Operating Instruction Manual Operation There are three switches located at the right-hand While all upside of the three switches are pushed, the downside of the fireplace. way of control is changed to remote control. The power switch is the right one of the three switches. The downside of the power switch is for hand control and flame on, and the upside for remote control.
