Summary of Contents for Orphek Amazonas 500
- Page 1 Orphek Amazonas 500 Watts LED Operational & Safety Guide Orphek Lighting...
- Page 2 Celsius above the room temperature! Soon you will find out that by using Orphek LED lighting products, you will achieve more color and growth, with less cooling and electricity than metal halides or any other traditional form of lighting.
- Page 3 Orphek Amazonas 500 Watts LED at glance Table of contents What are the features? Check Orphek Amazonas 500 Watts LED versatility What is in the box? What are the dimensions? What are the specifications? Industrial Product Sketch...
- Page 4 Safety Guide and in this Operational Guide before beginning installation or use of Orphek Amazonas 500 Watts LED. Orphek is not liable for any damages of any kind resulting from the purchase, use, misuse, or inability of/to use the product(s) or arising directly or indirectly from the use or loss of use of the product(s), from the purchaser’s lack of knowledge or...
- Page 5 Industrial Product Sketch Fig. 1 Base view Fig. 2 Top view Fig.3 Side view...
- Page 6 Acrylic lens options: 5/12/24/36/60 degrees No wire bonds for high reliability High efficiency Mean Well driver Low thermal resistance Check Orphek Amazonas 500 Watts LED versatility Available in many Kelvin temperatures and custom spectrums (white: 300k – 18000K/ Blue: 450-460nm)
- Page 7 What is in the box? One Light Unit One Power Cord (59”/ 1.5m) One Power cord extension (118”/ 3m) What are the dimensions? Diameter: 17.5” (445mm) Height: 12” (305mm) What are the specifications? Color/Materials Light Unit Body Material: Black high quality aluminum Fin with copper heatpipe/ tempered glass cover Weight Light Unit Weight: 33 lbs (15kg)
- Page 8 Electrical Mean Well Driver Model: 2X HLG – 240H – 36A Input voltage: 100~240VAC / 227 VAC (for North America only) Frequency: 47~63 Hz Power consumption: 500 – 510 Watts PF (power factor): 0.980 Input Current (Amps): 2.336 Input voltage: 200V Output voltage: 36V Electrical outlet: Region appropriate...
- Page 9 Orphek Amazonas500 Watts LED Ratio Map Fig. 1 * The ratio seen in fig.1 is only used as 1 example of the LED ratio offered by Orphek, not necessarily the one purchased. Customers customizing their own have different ratio maps with different spectrum results!
- Page 10 Orphek Amazonas 500 Watts LED Operational Guide Table of contents Getting Started Turning on the unit for the first time Final Observations Assistance & Warranty for your purchased Orphek Amazonas 500 Watts LED...
- Page 11 Orphek Amazonas 500 Watts LED is a plug in, plug out unit, that said all you need to do is to insert the electrical plug into the socket to switch on your unit and unplug it to switch off.
- Page 12 Orphek is proud to be committed to customer assistance excellence! If you have any question regarding your Amazonas 500 Watts LED unit (s), Orphek provides online Technical Support, answering to inquires from all over the world. From technical details about the product to installation, maintenance and troubleshooting of your Orphek unit (s) we offer you full support.
- Page 13 Because Orphek products are submitted to warranty policies like any other product sold in any market any place in the world. Because Orphek sells 1000s of units worldwide and we need to track yours in order to help you! WHY DO I NEED TO SEND YOU PHOTOS AND VIDEO OF THE...
- Page 14 WHEN I WILL RECEIVE THE SUPPORT I NEED? Orphek offers technical support 24 hours a day, 365 days of the year. All you need to do is contact us with the information requested above. WHEN WILL ORPHEK NOT PROVIDE THE SUPPORT I NEED? Orphek offers all its clients a proper channel to request assistance &...
- Page 15 2. To any Orphek lighting product that has been submerged to water; or have any kind of water infiltration. 3. To cosmetic problems or defects that result from normal wear and tear under ordinary use, and do not affect the performance or use of the product;...
- Page 16 & delivery partners, but sometimes damage may occur for many reasons.In this case you should verify our shipping policies. Orphek does not render services of installation of any of its products therefore it will not be held responsible for damage of any kind or cost resulted from installations.
- Page 17 CONNECTION WITH THIS PRODUCT. ALL WARRANTIES ARE VOID IF THERE IS DAMAGE TO THE ORPHEK LIGHTING PRODUCT THAT IS NOT A RESULT OF A DEFECT IN THE MATERIALS OR WORKMANSHIP. THE SOLE AND EXCLUSIVE REMEDY FOR ALL CLAIMS THAT YOU MAY...
-
Page 18: Table Of Contents
Damages outside the warranty claim period: If you have purchased your Orphek product from a dealer, local shop or online shop, please contact them directly and check how they can help you. If you have purchased your product directly from us, contact contact@orphek.com with the same information that should be... -
Page 19: First Observations
Safety Instructions for Cleaning your Amazonas 500 Watts LED How to clean your Orphek Amazonas 500 Watts LED First Observations 1.Only authorized and qualified electrical workers should install, repair or perform maintenance on electrical equipments. But if you still opt to do it yourself: Check basic... -
Page 20: Epilepsy & Photosensitivity
Never rely on your memory, read our manual and the safety guide before you start to install your Orphek Amazonas 500 Watts LED and have it with you for reference during installation. If you have any questions, or did not understand any information of this guide please kindly contact Orphek Customer Assistance Team. -
Page 21: Important
These are some of the safety tips. Orphek cannot provide you a full guide. Please check a complete electrical safety guide for all the safety rules of electrical installation procedures). - Page 22 Orphek LED Lighting company (Check our warranty policies), before, during or after installing your unit(s) Your Orphek Amazonas 500 Watts LED is not waterproof, it is water resistant. Water might permanently damage it. This damage is not covered under the warranty. Protect these components from water submerging or infiltration of any kind.
-
Page 23: Watts Led
Safety Instructions for Storing your Orphek Amazonas 500 Watts LED Improper storage will damage temporarily or permanently your Orphek Amazonas 500 Watts LED unit(s) (Please check for our warranty policies before storing your Orphek products) ! Please keep the original package(s) to store the unit(s). - Page 24 9. Do not pull cords while cleaning your unit(s). OBs.: Amazonas 500 Watts LED unit (s) can be also cleaned with air compressors as long as you will follow the instructions of the manual of the compressor used.
