Welcome to Digatron

This manual covers the operation of your DT-50S instrument. This includes any 52, 53 or 54 instrument. All 50 series instruments
function the same; the only difference is the number of displays.
Both racers and recreational riders can use this instrument. Racers may be interested in recording in time segments, either laps or
sections of the strip or course. Recreational drivers will usually be interested in recording without laps.
This book provides the information you need to quickly set up and use your instrument. It is a great reference guide.
If you are interested in learning more about how your Digatron instrument can help you analyze your engine functions and driving
techniques, please visit our website, www.digatronusa.com, or phone (509) 467-3128.
Note: These instructions cover current versions. If you have an older version, and
find the instructions don't exactly match, please contact Digatron at
support@digatronusa.com
or toll free at 866.344.2876.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DT-50S and is the answer not in the manual?

Questions and answers

Related Manuals for Digatron DT-50S

Summary of Contents for Digatron DT-50S

  • Page 1: Table Of Contents

    Repairs and Warranty ..................8 Welcome to Digatron This manual covers the operation of your DT-50S instrument. This includes any 52, 53 or 54 instrument. All 50 series instruments function the same; the only difference is the number of displays. Both racers and recreational riders can use this instrument. Racers may be interested in recording in time segments, either laps or sections of the strip or course.

  • Page 2: Instrument Functions

    Instrument Functions A. Power/Record Start Vehicle. Instrument turns on and starts recording automatically when a tach signal is received. Records for 2 hours, then records over oldest data. B. Overall Maximums Press Press and Repeat release to cycle steps 1 & 2 hold.
  • Page 3 E. Maximums by Lap Select a lap. See D. Lap Times. Displays engine data, Displays lap data. showing maximum Press and hold to values for this lap. view Event number. EVENT Changes lap backward or forward one. Displays flash when your best lap is SET UP LIGHT shown.

  • Page 4: Batteries Not Needed

    Batteries Not Needed When your vehicle is running, the DT-50S series instrument gets power from the lighting coil. To use your instrument for an extended time without power from the lighting coil, you can buy a wall adaptor to power your instrument.

  • Page 5: Tach Calibration Number (Rpm1)

    Tach Calibration Number (RPM1) The Tach limit requires two separate parameters. The first is the maximum revolutions per minute (RPM) for safe engine operation. The second number, the Tach calibration, allows the instrument to display the correct RPM for your engine. The instrument divides the Tach input signal by the Tach calibration number.

  • Page 6: Recording

    Your instrument is designed to be water resistant. We recommend keeping it as dry as possible. Please cover or remove your instrument before washing your vehicle. Digatron offers tach bags to help keep the instrument dry. If moisture does get inside the instrument, remove the endcap without switches and let the instrument air out in a dry environment.

  • Page 7: Button Functions

    Button Functions Time (top, side button): (2) functions A. Displays lap/segment time and number. B. Press and hold to show best lap/segment time. Engine (bottom, side button) (2) functions A. Cycles between three sets of data. B. Press and hold to show maximums and designators. Power / Exit (2) functions A.

  • Page 8: Designators Defined

    When returning an instrument for repair, please use the repair form found on our website or enclose a note indicating your return address, phone number and a detailed description of the problem. Send your instrument and sensors so that we can check the complete system. Send repairs to: Digatron LLC 120 N. Wall St. Ste 300 Spokane, WA 99201 www.digatronusa.com...
