  • Page 1 VIPA Accessories Teleservice module | 900-2C610 | Manual HB39E_TM | RE_900-2C610 | Rev. 13/28 July 2013...
  • Page 2 Copyright © VIPA GmbH. All Rights Reserved. This document contains proprietary information of VIPA and is not to be disclosed or used except in accordance with applicable agreements. This material is protected by the copyright laws. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to VIPA), except in accordance with applicable agreements, contracts or licensing, without the express written consent of VIPA and the business management owner of the material.

  • Page 3: Table Of Contents

    Manual VIPA TM Contents Contents About this manual ..................1 Safety information ..................2 Chapter 1 Assembly and installation guidelines......1-1 Safety information for Users..............1-2 Installation dimensions ................. 1-3 Assembly....................1-4 Cabling....................1-6 Installation guidelines ................1-7 Chapter 2 Hardware description .............
  • Page 4 Contents Manual VIPA TM HB39E - TM - RE_900-2C610 - Rev. 13/28...

  • Page 5: About This Manual

    Deployment This chapter concerns on the deployment of the Teleservice module (TM) from VIPA with a PLC. With the fast introduction you will get an overview about the possibilities of teleservice. Another part of this chapter is the configuration of the TM by means of the integrated Web page.
  • Page 6 About this manual Manual VIPA TM This manual describes the Teleservice module TM-C Router VPN from Objective and VIPA. It contains a description of the construction, project implementation contents and usage. This manual is part of the documentation package with order number VIPA HB39E_TM and relevant for:...

  • Page 7: Safety Information

    Manual VIPA TM Safety information Safety information Applications The Teleservice module is constructed and produced for: conforming with • communication and process control specifications • general control and automation applications • industrial applications • operation within the environmental conditions specified in the technical data •...
  • Page 8 Safety information Manual VIPA TM HB39E - TM - RE_900-2C610 - Rev. 13/28...

  • Page 9: Chapter 1 Assembly And Installation Guidelines

    Manual VIPA TM Chapter 1 Assembly and installation guidelines Chapter 1 Assembly and installation guidelines Overview In this chapter you will find all information, required for assembly and installation of the Teleservice module (TM). Content Topic Page Chapter 1 Assembly and installation guidelines......1-1 Safety information for Users..............

  • Page 10: Safety Information For Users

    Chapter 1 Assembly and installation guidelines Manual VIPA TM Safety information for Users Handling of VIPA modules make use of highly integrated components in MOS- Technology. These components are extremely sensitive to over-voltages electrostatic that can occur during electrostatic discharges.

  • Page 11: Installation Dimensions

    Manual VIPA TM Chapter 1 Assembly and installation guidelines Installation dimensions Dimensions Make sure that a clearance of at least 100mm exists above and 70mm below the middle of the bus rail. Dimensions assembled 127 mm 86 mm 89 mm 132 mm HB39E - TM - RE_900-2C610 - Rev.

  • Page 12: Assembly

    Chapter 1 Assembly and installation guidelines Manual VIPA TM Assembly General The modules are installed on a profile rail. You may use the following standard 35mm profile rail: 35 mm 35 mm 27 mm 27 mm Assembly procedure The following sequence represents the assembly procedure as viewed from the side.
  • Page 13 Manual VIPA TM Chapter 1 Assembly and installation guidelines The following sequence shows the steps required for the removal of Removal modules in a side view. procedure • For the removal take the module at the bottom and pull it forward with a strong jerk.

  • Page 14: Cabling

    Chapter 1 Assembly and installation guidelines Manual VIPA TM Cabling Overview At the upper side of the Teleservice module there are connectors for power supply and digital inputs/outputs. The output is designed as low-side output and may be configured. The connectors are plugs with screw contacts. If connected the plugs may be fixed with screws.

  • Page 15: Installation Guidelines

    Manual VIPA TM Chapter 1 Assembly and installation guidelines Installation guidelines General The installation guidelines contain information about the possible interference causes. Here we describe possible ways of interference that may disturb the controlling system and how you have to approach shielding and screening issues to ensure the electromagnetic compatibility (EMC).
  • Page 16 Chapter 1 Assembly and installation guidelines Manual VIPA TM In the most times it is enough to take care of some elementary rules to Basic rules for guarantee the EMC. Please regard the following basic rules when installing your PLC.
  • Page 17 Manual VIPA TM Chapter 1 Assembly and installation guidelines Electrical, magnetic and electromagnetic interference fields are weakened Isolation of by means of an isolation, one talks of absorption. conductors Via the isolation rail, that is connected conductive with the rack, interference currents are shunt via cable isolation to the ground.
  • Page 18 Chapter 1 Assembly and installation guidelines Manual VIPA TM 1-10 HB39E - TM - RE_900-2C610 - Rev. 13/28...

  • Page 19: Chapter 2 Hardware Description

    Manual VIPA TM Chapter 2 Hardware description Chapter 2 Hardware description Overview Here the hardware components of the Teleservice module (TM) are more described. The technical data are at the end of this chapter. Content Topic Page Chapter 2 Hardware description ............. 2-1 Properties.....................

  • Page 20: Properties

    Talk2M LINK/ACT 4 3 2 1 Order data Type Order number Description TM-C Router VIPA 900-2C610 DC 12 ... 24V, MPI, 5xEthernet RJ45, Router functions, DI 1xDC 24V, DO 1xDC 24V 0.2A HB39E - TM - RE_900-2C610 - Rev. 13/28...

  • Page 21: Structure

    Manual VIPA TM Chapter 2 Hardware description Structure TM-C Router Connector for digital I/O Connector for DC 12...24V power supply Earthing screw 900-2C610 USER TM-C LEDs INTERNET Talk2M Reset button LINK/ACT 4 3 2 1 4xLAN-RJ45 Ethernet interface 1xWAN-RJ45 Ethernet interface...
  • Page 22 The TM is delivered with the following IP address parameters for the LAN interface: IP address: 10.0.0.53 Subnet mask: 255.255.255.0 To change the IP address parameters the configuration tool "eBuddy" from VIPA may be used. Note! Per default the LAN interface is always activated. HB39E - TM - RE_900-2C610 - Rev. 13/28...
  • Page 23 255.255.255.0 Gateway: 0.0.0.0 To change the IP address parameters the configuration tool "eBuddy" from VIPA may be used. Note! Per default the WAN interface is always de-activated. For the first connection the LAN interface is to be used. HB39E - TM - RE_900-2C610 - Rev. 13/28...
  • Page 24 "TM - Reset". Caution! An unauthorized complete reset, which possibly was not carefully executed, leads automatically to the expiring of the warranty! Then the device must be sent back to VIPA for reprogramming. HB39E - TM - RE_900-2C610 - Rev. 13/28...
  • Page 25 Manual VIPA TM Chapter 2 Hardware description The Teleservice module is to be power supplied by DC 12 ... 24V ±20%. Connector power supply Here the power consumption amounts to 3 ... 6W. For power supply there is a 2-pin connector at the upper side of the TM module.

  • Page 26: Technical Data

    Chapter 2 Hardware description Manual VIPA TM Technical Data Order no. 900-2C610 Type TM-C Router Inputs and outputs Inputs 1 DI: 0/24 V DC, isolated Outputs 1 DO: open drain, max. 200 mA at DC 30 V Communication serial port...

  • Page 27: Chapter 3 Deployment

    Overview This chapter concerns on the deployment of the Teleservice module (TM) from VIPA with a PLC. With the fast introduction you will get an overview about the possibilities of Teleservice. Another part of this chapter is the configuration of the TM by means of the integrated Web page.

  • Page 28: Fast Introduction

    Chapter 3 Deployment Manual VIPA TM Fast introduction Important note! The information in this manual should simplify you the deployment of remote controlling VIPA PLCs. More information concerning this may be found in german and english at: support.ewon.biz www.ewon-online.de Power supply The Teleservice module is to be supplied with DC 12...24V ±20%.
  • Page 29 Access via The software tool "eBuddy" may be found at the download area of eBuddy www.vipa.com. For installation execute eBuddySetup.exe and follow the instructions. • Start eBuddy. • Switch to the list view with "Switch to list mode". Here every TM available in you network is listed.
  • Page 30 • Open the Web page of the corresponding Teleservice module. • Open with Settings > Gateway the page for adjusting an I/O server. Set as I/O server "ISOTCP to MPI (Siemens S7-300/400)". • To access the VIPA PLC enter the following parameters: MPI/PROFIBUS destination node: 2 (standard)

  • Page 31: Assembly

    Manual VIPA TM Chapter 3 Deployment Assembly General The modules are installed on a profile rail. You may use the following standard 35mm profile rail: 35 mm 35 mm 27 mm 27 mm Assembly procedure The following sequence represents the assembly procedure as viewed from the side.

  • Page 32: Cabling

    Chapter 3 Deployment Manual VIPA TM Cabling Overview At the upper side of the Teleservice module there are connectors for power supply and digital inputs/outputs. The output is designed as low-side output and may be configured. The connectors are plugs with screw contacts. If connected the plugs may be fixed with screws.

  • Page 33: Tm - Configuration - Ebuddy

    Manual VIPA TM Chapter 3 Deployment TM - Configuration - eBuddy To deploy the Teleservice module, the VIPA software tool "eBuddy" is Overview necessary. With this new IP address parameters may be assigned to the TM; you may load and transfer new firmware, backup/restore applications and access the integrated web page of the TM.
  • Page 34 Chapter 3 Deployment Manual VIPA TM Industrial Ethernet exclusively supports IPv4. At IPv4 the IP address is a Basics 32Bit address that must be unique within the network and consists of 4 IP address numbers that are separated by a dot.
  • Page 35 Manual VIPA TM Chapter 3 Deployment Address classes For IPv4 addresses there are five address formats (class A to class E) that are all of a length of 4byte = 32bit. Class A 0 Network-ID Host-ID (24bit) (1+7bit) Class B...
  • Page 36 Chapter 3 Deployment Manual VIPA TM For the access to the Teleservice module valid IP address parameters are Changing the necessary. The IP addresses are assigned by the network administrator. IP address Per default the Teleservice module is delivered with the IP address 10.0.0.53.
  • Page 37 TM, for example if the voltage supply is interrupted during transfer or if the firmware file is defective. In this case, please call the VIPA-Hotline! The proceeding of the update is shown as a proceeding bar. Wait here until the bar is at 100%.
  • Page 38 Backup Open the dialog window with clicking to "Backup/restore application". Select "Backup". Even if you want to forward the backup to the VIPA support the files relevant to the support should also be saved. Here activate the option "Include support files". Click to [Continue >].

  • Page 39: Tm - Reset

    Caution! An unauthorized complete reset, which possibly was not carefully executed, leads automatically to the expiring of the warranty! Then the device must be sent back to VIPA for reprogramming. User-Reset There is the following proceeding for the user reset: •...

  • Page 40: Tm - Web Page

    Chapter 3 Deployment Manual VIPA TM TM - Web page Access to the • Start the VIPA configuration tool "eBuddy". Web page • Switch to the list view with "Switch to list mode". Here every TM available in your network is listed.

  • Page 41: Tm - Plc Linking

    IP address parameters and the Web page of the TM may be accessed. Connect VIPA PLC To get access to the VIPA PLC, the VIPA CPU is to be connected to the via MPI MPI jack of the Teleservice module via a suited MPI cable.
  • Page 42 Chapter 3 Deployment Manual VIPA TM • Select the suitable IO protocol. In this case ISOTCP to MPI (Siemens I/O server configuration S7-300/400) and click [Next>>]. • Enter the communication settings of your PLC and select the used protocol. After that click [Save>>] to finish and to activate the gateway configuration.
  • Page 43 Manual VIPA TM Chapter 3 Deployment • After clicking [Save>>] you will receive the following message, that confirms your configuration was successful. HB39E - TM - RE_900-2C610 - Rev. 13/28 3-17...

  • Page 44: Tm - Project Integration - Pg/Pc Interface Via Netpro

    Teleservice With the teleservice the Teleservice module works as gateway. As gateway via the served communication connections you have access to the VIPA PLC, which is connected via MPI to the TM. So that the TM can work as gateway, you have to integrate this to your hardware configuration.
  • Page 45 Manual VIPA TM Chapter 3 Deployment Integrate the TM The integration of the Teleservice module to your project happens as module to the PG/PC interface. After the configuration this may be defined as access path Siemens SIMATIC for the PLC functions.
  • Page 46 Chapter 3 Deployment Manual VIPA TM • Open the properties of the PG/PC station. Properties PG/PC station • Access the register "Interfaces" and click to [New...]. • Select the type "Industrial Ethernet" and click to [OK]. • De-activate "Set MAC address..."...
  • Page 47 Manual VIPA TM Chapter 3 Deployment Now your graphical net view should show the following structure: Import the TM To import the Teleservice module to your project the first downloaded module via station station file is necessary. file • Start in NetPro the import via Edit > Import.
  • Page 48 Chapter 3 Deployment Manual VIPA TM Define access via Depending on the access modes to your Teleservice module, there are the IP address following possibilities to preset IP address parameters: Access via Ethernet Enter here IP address and subnet mask of your TM. The IP address parameters must correspond to the IP address parameters, which were preset with the software tool "eBuddy".

  • Page 49: Tm - Project Integration - Pg/Pc Interface Via Evcom

    MPI interface. To do this on the PC side the driver "eVCOM" from VIPA is to be installed. Contrary to "Project integration via NetPro" no adjustment is necessary on the PLC side. This version is easy to use but slower than "Project integration via NetPro".
  • Page 50 Chapter 3 Deployment Manual VIPA TM Define access via Depending on the access mode to your Teleservice module, there are the IP address following possibilities to preset the IP address: Access via Ethernet The IP address must be the same as the IP address, which was preset by the software tool "eBuddy".

  • Page 51: Vpn Connection - Talk2M

    Manual VIPA TM Chapter 3 Deployment VPN connection - Talk2M VPN (Virtual Private Network) is an interface in a network, which serves to bind devices from their original net to another attainable net. The networks do not have to be compatible. A VPN connection is secured by coding mechanisms.
  • Page 52 Chapter 3 Deployment Manual VIPA TM Talk2M (Talk to Machine) is a service, by means of which you may reach Talk2M your plant word-wide via cellular radio or DSL/LAN. Talk2M communicates fully secured over VPN. Since Talk2M only uses outgoing connections,...

  • Page 53: Vpn Connection - Pc-Talk2M

    Manual VIPA TM Chapter 3 Deployment VPN connection - PC-Talk2M For the access with your PC to Talk2M following steps are necessary: Approach • Install the software "eCatcher" at your PC. • Create a Talk2M account via eCatcher. • Add your Teleservice module to the account.
  • Page 54 Chapter 3 Deployment Manual VIPA TM • Create an account by clicking to [Create a Free+ account]. With the first Creating a Talk2M account creation of an account you get a 15€ credit. • Enter a Talk2M-Account name, a user name, a password and your email address.
  • Page 55 Manual VIPA TM Chapter 3 Deployment Network settings If there is no connection to Talk2M possible, for communication via Talk2M for the use of the following network settings must be checked. Please ask here if Talk2M necessary your system administrator.
  • Page 56 Chapter 3 Deployment Manual VIPA TM Configure Talk2M If the connection to the Talk2M server was successfully established, the and connect to TM configuration dialog is shown. 3-30 HB39E - TM - RE_900-2C610 - Rev. 13/28...

  • Page 57: Vpn Connection - Tm-Talk2M Via Dsl/Lan

    Manual VIPA TM Chapter 3 Deployment VPN connection - TM-Talk2M via DSL/LAN Principle PLC system 198.10.11.1 255.255.255.0 VIPA 900-2H681 USER MODEM LINK/ACT 4 3 2 1 Talk2M Router Configuration IP: 198.10.11.10 255.255.255.0 198.10.11.1 Internet IP: 172.16.100.3 Ethernet SN: 255.255.0.0 Connect TM to Start the program eCatcher.
  • Page 58 Chapter 3 Deployment Manual VIPA TM Proceeding • Click to add a new Teleservice module. registration of a TM The following dialog window opens: at Talk2M • In the Name field enter a suited name for your TM. You may leave the Description field empty.
  • Page 59 Manual VIPA TM Chapter 3 Deployment • Mark your Teleservice module and click • You can modify the setting in the following window. • Click to continue with the activation of your Teleservice module. HB39E - TM - RE_900-2C610 - Rev. 13/28...
  • Page 60 Chapter 3 Deployment Manual VIPA TM • The following dialog window with an Activation Key opens. • Copy the Activation Key with [Copy] or into clipboard respectively into a text file. This Activation Key is required at a later time.
  • Page 61 Manual VIPA TM Chapter 3 Deployment • Open the Web page of your TM by entering the LAN IP address of your Proceeding establishing TM Teleservice module into the address bar of your Internet browser. The connection for default username and password are adm.
  • Page 62 Chapter 3 Deployment Manual VIPA TM • Confirm with [Next>>]. • Set time and date in the following window. If time and date are correct click [Save] otherwise click [Edit] to change the data. • Existing data will be deleted and entered data of your TM will be set.
  • Page 63 Manual VIPA TM Chapter 3 Deployment • Next you will be asked to configure the WAN connection. The WAN Proceeding configuration of the interface is marked with "INTERNET" and "Talk2M". Make sure that your WAN connection WAN interface is connected to a ADSL-Router or a network by a network cable.
  • Page 64 Chapter 3 Deployment Manual VIPA TM We recommend the first possibility, because you always have access to your system, even if the digital input is not able to be activated. • Click [Next>>] to continue. • At Address settings select "DHCP" for an automatic address allocation respectively "static"...
  • Page 65 Manual VIPA TM Chapter 3 Deployment • A test of the WAN connection opens in the following window. Wait until the test is finished and the next window opens. • If the test was successful, you will get a confirmation. Click [Next wizard>>] to register your TM on Talk2M-Account.
  • Page 66 Chapter 3 Deployment Manual VIPA TM Proceeding When the Internet connection was successfully established via WAN configuration of the interface, you can register your TM on Talk2M-Account. Talk2M connection • Select Register with activation key. • Paste the activation key, that you previously copied in the clipboard, in the Activation Key box.
  • Page 67 Manual VIPA TM Chapter 3 Deployment • Now your TM will establish a WAN connection to connect with the Talk2M-Server. This may take a moment. • If the diagnosis box reads: "SUCCESS: VPN connection configured and tested" your TM has registered successfully on Talk2M.
  • Page 68 Chapter 3 Deployment Manual VIPA TM TM connection with connect your automation components (e.g. PLCs) MPI/PROFIBUS/PPI, you have to configure the gateway of your TM. components via MPI/PROFIBUS/PPI • For that click [Next wizard>>]. • Select the suitable IO protocol. In this case ISOTCP to MPI (Siemens S7-300/400) and click [Next>>].
  • Page 69 Manual VIPA TM Chapter 3 Deployment • Enter the communication settings of your PLC and select the used protocol. After that click [Save>>] to finish and to activate the gateway configuration. Note! You have the possibility, to see the connected MPI/PROFIBUS stations by clicking of destination node.
  • Page 70 Chapter 3 Deployment Manual VIPA TM 3-44 HB39E - TM - RE_900-2C610 - Rev. 13/28...
