- Page 1 VIPA Networking Solutions TM | 900-2C5x0 | Manual HB39 | TM | 900-2C5x0 | en | 18-18 TM-C Router www.vipa.com/en/service-support/manuals...
- Page 2 VIPA GmbH Ohmstr. 4 91074 Herzogenaurach Telephone: +49 9132 744-0 Fax: +49 9132 744-1864 Email: info@vipa.com Internet: www.vipa.com 900-2C5x0_000_TM-C Router,3,GB - © 2018...
-
Page 3: Table Of Contents
VIPA Networking Solutions Table of contents Table of contents General........................4 1.1 Copyright © VIPA GmbH ................. 4 1.2 About this manual..................... 5 1.3 Safety information..................... 6 Product Summary....................7 2.1 Introduction....................... 7 2.2 Versions......................7 2.3 Order numbers....................7 2.4 Properties...................... -
Page 4: General
This material is protected by the copyright laws. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to VIPA), except in accord- ance with applicable agreements, contracts or licensing, without the express written con- sent of VIPA and the business management owner of the material. -
Page 5: About This Manual
Tel.: +49 9132 744-1150 (Hotline) EMail: support@vipa.de 1.2 About this manual Objective and contents This manual describes the Teleservice module 900-2C5x0 from VIPA. It contains a description of the structure, project engineering and deployment. Product Order number as of state:... -
Page 6: Safety Information
VIPA Networking Solutions General Safety information Supplementary information and useful tips. 1.3 Safety information Applications conforming The system is constructed and produced for: with specifications communication and process control general control and automation tasks industrial applications operation within the environmental conditions specified in the technical data... -
Page 7: Product Summary
Order numbers Product Summary 2.1 Introduction The present Manual describes the hardware of the VIPA TM-C modules. The VIPA TM-C modules are 3 industrial routers. The TM-C modules are fully compatible with the Talk2M cloud connectivity services (www.talk2M.com). 2.2 Versions... -
Page 8: Properties
VIPA Networking Solutions Product Summary Typical applications 2.4 Properties Characteristic Value Design Industrial design (24 VDC power supply, DIN Rail mounting, extended temperature) Processor ARM9 Clock Backed up real time clock (RTC) Backup battery lifetime has 10 years expectancy Ethernet Interface... -
Page 9: Safety, Environmental And Regulatory Information
VIPA Networking Solutions Safety, Environmental and Regulatory Information Applicable Directives, Standards and Compliance Safety, Environmental and Regulatory Information 3.1 Scope The present heading addresses Safety, Environmental & Regulatory Information for the VIPA TM-C modules. 3.2 Power supply The external power supply is a third party device that is not part of this certification. The device shall be supplied by a LPS power supply certified according to IEC/UL60950-1 or Class 2 per NEC. -
Page 10: Field Implementation And Environmental Conditions
3.4 Field implementation and environmental conditions Protection grade The VIPA TM-C has an IP20 protection grade. Therefore, the VIPA TM-C is NOT suited for outdoor mounting. It has to be integrated in an electrical cabinet, protected from excessive heat, humidity and dust. Do not push any sharp object into the air vents or openings of the equipment. - Page 11 VIPA Networking Solutions Safety, Environmental and Regulatory Information Field implementation and environmental conditions SIM card slot DIN rail mounting bracket Screw holes intended to receive M4 screws with an 8mm diameter head To ensure a proper ventilation of the equipment, a free gap of at least 2 cm must be respected in front of all upper &...
- Page 12 VIPA Networking Solutions Safety, Environmental and Regulatory Information Field implementation and environmental conditions CAUTION! In any other mounting position than the one explained here above, the specified temperature has to be derated to -25°C to +40°C. Cabling Shielded cables must be used for Ethernet and USB connectivity to comply with the EMC requirements.
-
Page 13: Battery
VIPA Networking Solutions Safety, Environmental and Regulatory Information Battery Environmental conditions The equipment will operate properly within the following environmental limits if it has been correctly mounted according to the above mentioned recommendations: Operating temperature -25°C to +70°C Relative Humidity... -
Page 14: Hardware Description
VIPA Networking Solutions Hardware Description Dimensions Hardware Description 4.1 Dimensions HB39 | TM | 900-2C5x0 | en | 18-18... -
Page 15: Structure
VIPA Networking Solutions Hardware Description Structure 4.2 Structure Front Reset button Status LEDs panel LAN/WAN Ethernet ports and corresponding status LEDs (Red: WAN / Green: LAN) USB slot SD card slot Upper side Main connector including power input terminal, 1 DO and 2 DI... - Page 16 VIPA Networking Solutions Hardware Description Structure ICON Description DO_COM Output signal (0V ground) connected to the emitter of the MOSFET transistor Output signal connected to the drain of the MOSFET transistor DO_VDC Common of the external predrive power supply (12 - 24 VDC)
- Page 17 VIPA Networking Solutions Hardware Description Structure Possible features Digital Output and Inputs can be used on the TM-C, some features can be externalized by wiring the main connector. Connector Description On a key switch to authorize or prevent the Internet con- nection.
- Page 18 Digital IN 2 - Green = ON: Signal on input 2 detected Talk2M - Green ON = Talk2M VPN connection established Internet Green ON = Internet is configured on the VIPA TM-C Status LED panel (TM-C - WiFi) SMA male connector for WiFi antenna...
-
Page 19: Radio Communication Modems
VIPA Networking Solutions Hardware Description Radio communication modems Status LED panel (TM-C - 3G+) SMA female connector for GSM antenna Modem status Green ON = Modem connected Reception signal level Red ON = poor signal Reception signal level Red ON = Signal is OK... - Page 20 5 bands GPRS/EDGE Class 33 Antenna Connector Type SMA Antenna GSM/GPRS/UMTS antenna is available from VIPA with 900-0AB51 as refer- ence The product complies with the R&TTE directive, the FCC, the IC and Japan regula- tions related to the GSM modems.
-
Page 21: Lan Switch Specifications
VIPA Networking Solutions Hardware Description LAN Switch Specifications Used Wireless Frequen- cies Channels 12, 13 & 14 are not supported Used channels and frequencies are between: Channel 1 - 2,412 Ghz and 11 - 2,462 4.4 LAN Switch Specifications Boot process During the (re)boot process, the TM prevents the switch feature from working. -
Page 22: Ip Address And Access To The Web Configuration
5.3 Setting the TM-C LAN IP Address You can easily establish your first communication with your TM-C by using our com- panion tool eBuddy which can be downloaded from www.vipa.com under ‘Service-Support è Downloads è Software’. Connect one of the LAN-ports (by default, port No. 1 is always a LAN port) of your TM-C with your PC point-to-point or through a network where there is no risk that the TM's default IP-address (10.0.0.53) would conflict with another connected device. - Page 23 VIPA Networking Solutions IP Address and Access to the Web Configuration Setting the TM-C LAN IP Address Start the eBuddy utility on your PC in the home page. Select "Set IP Address". Fill in the Serial Number of your TM-C or click on [Browse...] and select it. The Serial Number of the TM-C is on its label.
-
Page 24: Tm-C Web Interface
VIPA Networking Solutions IP Address and Access to the Web Configuration TM-C Web Interface Enter a new LAN IP address and Subnet Mask. Click [Next]. Wait until the address is updated and the device has rebooted. Click [Finish]. 5.4 TM-C Web Interface To access the web pages of your TM-C proceed as follows: Connect the PC to one of the LAN port of the TM-C. - Page 25 ð You will be automatically redirected to the Quick Launch Wizard page: You can follow the Quick Start Guide as an aid to configure your TM-C. Can be downloaded on www.vipa.com under ‘Service-Support è How-to-do è Teleservice’. To reconfigure your TM-C, you can easily rerun the wizard by clicking on the "Set- tings"...
-
Page 26: Troubleshooting
VIPA Networking Solutions Troubleshooting Second Level Reset (factory reset) Troubleshooting 6.1 Normal Boot Process The normal boot process of the TM-C takes approximately 25 seconds to complete. During this process, all LEDs are shortly ON, except "BI1" as long as the RESET button is not pressed. -
Page 27: Reset Impact Matrix
VIPA Networking Solutions Troubleshooting Reset Impact Matrix You have to power the TM-C OFF and ON again to reboot the unit in normal mode. As described before, the TM returns to its default COM parameters and factory IP addresses (like LAN 10.0.0.53) after this level 2 reset is performed.
