Summary of Contents for Vornado energy smart EVDC300
- Page 2 PRECISE SMART WATER-LEVEL MOTOR AUTO-HUMIDITY CONTROL SENSING GUARANTEE Control preciso de Régulation précise et Más eficiencia energética Satisfacción motor garantizada humedad automática automatiquede l’humidité Plus économe en énergie Sensor inteligente de nivel Détection intelligente du Moteur satisfaction garantie del agua niveau d’eau...
-
Page 3: Table Of Contents
MODEL EVDC300 OWNER’S GUIDE GUÍA DEL PROPIETARIO DE MODELO EVDC300, GUIDE D’UTILISATION – MODÈLE EVDC300, EVDC300 모델 사용자 가이드, モデル EVDC300 取扱説明書 CONTENTS Important Safety Instructions ............. 2 Automatic Refill Program ..............11 Getting Started ................... 5 Cleaning .................... 12 Features .................... -
Page 4: Important Safety Instructions
The manufacturer assumes no responsibility for damage or injury IMPORTANT SAFETY INSTRUCTIONS caused by failure to follow these instructions, improper product use or READ ALL INSTRUCTIONS BEFORE USING unauthorized product modification. Any such actions will invalidate the THIS HUMIDIFIER. product warranty. This owner’s guide and any additional inserts are considered part of WARNING –... - Page 5 DANGER - A loose fit between wall outlet (receptacle) and plug may cause overheating and distortion of the plug. Discontinue use of the product in outlet. Contact qualified electrician to replace loose or Risk From Electrical Shock. Contact with wires or components worn outlet.
- Page 6 If interference is suspected, the user is encouraged to contact Vornado Consumer Service at 1-800-234-0604, if within the USA. If outside the USA, please contact the Authorized Service Center.
-
Page 7: Getting Started
Before use, check appliance for visible damage. DO NOT USE if there is evidence of damage. If any damage is found, contact Vornado Consumer Service at 1-800-234-0604, if within the USA. If outside the USA, please contact the Authorized Service Center. -
Page 8: Features
FEATURES AIR OUTLET GRILL Initiates Vornado’s signature Vortex circulation. Removable for easy cleaning. POWER HEAD Powerful brushless DC motor circulates SIMPLETANK™ SYSTEM humidified air This Water Tank is easy to throughout the whole carry, fill, install, clean and room. Easy to access view water level. -
Page 9: Energy Smart
ENERGY SMART ™ MAXIMIZE EFFICIENCY WITH ONE BUTTON Energy Smart™ mode offers precise humidification using less energy with our variable DC motor, which has the capability to automatically adjust up to 10 different speeds with the right amount of power at the right time for the most efficient performance. Energy Smart™... -
Page 10: Controls
CONTROLS ENERGY SMART™ MODE POWER ON/OFF FAN SPEED Delivers the right amount of humidity with the least Turn the humidifier On/Off. Select desired TURBO (HH), amount of power to be as energy efficient as possible. HIGH (HI) or LOW (LO) Fan speed will vary to maintain set humidity level. -
Page 11: Filling Water Tank
FILLING WATER TANK Note: Spills can occur during cleaning, moving or refilling the Water Tank, so be careful to avoid spills when doing these activities. 1. Unplug humidifier and place on a level surface. 2. Remove Water Tank from the base by grasping the top integrated handle and pulling up towards you (A). -
Page 12: How To Use
HOW TO USE 1. Position humidifier to not blow directly on objects or plants. Plug 6. If unit is unplugged, during next use, settings will default to LOW fan power cord into standard grounded wall outlet. speed, 50% humidity. 2. To turn humidifier on touch . The WARNING: Avoid finger contact with the fan blade, which is accessible humidifier will default to LOW fan speed on the underside of the Power Head. -
Page 13: Replacing Wick
Wicks, including amount of use, water hardness and outside environmental factors. You will know the Wick needs to be replaced when it becomes hard and is no longer absorbing the water effectively. Replace the Wick with a genuine Vornado Wick. -
Page 14: Cleaning
CLEANING Proper cleaning of your Evaporative Whole Room Humidifier is essential to the air quality and performance of your humidifier. The frequency in which your humidifier will need to be cleaned will vary depending on use, water hardness and outside environmental factors. It is recommended, assuming average use, to thoroughly clean the unit several times throughout the season, or when algae, mineral deposits or other particles begin to form. - Page 15 CLEANING Note: On occasion the Water Tank may need to be wiped down or cleaned to remove build-up of impurities with a mild detergent and cool water. Do not use gasoline, thinners, solvents or other chemicals for cleaning. The Water Tank is not dishwasher safe. TO CLEAN GRILL grill counterclockwise 1.
- Page 16 CLEANING 1 tsp. 1 gal. Chlorine Water 20 min. Bleach IN THE EVENT YOU WANT TO DISINFECT THE BASE: 1. Mix solution of 1 teaspoon chlorine bleach and 1 gallon water. 3. You may also wipe down the entire surface of humidifier with a Fill Base with solution, wet all surfaces.
-
Page 17: Storage
TIPS STORAGE During the off-season or after extended periods of non-use, you Be aware of several things as your Vornado Evaporative Whole Room ® may choose to store your humidifier. To ensure long life of the Humidifier operates: product, it is recommended to store your humidifier by following these instructions: †... -
Page 18: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE AND SOLUTION Unit fails to power on. Unit is not plugged in. Plug power cord into electrical outlet. Household circuit breaker/ground fault circuit interrupter has tripped or blown fuse. Reset circuit breaker/ground fault circuit interrupter, or replace fuse. For assistance, contact licensed electrician. Ensure power head is securely in place for proper power connection. -
Page 19: Español
Vornado® Evaporative Whole Room Humidifier (“Product”) is free from defects in of electricity, or shipping a Vornado product to a country not intended for use will material or workmanship for a period of five (5) years from the date of purchase. - Page 20 PERFECT vornado.com Esperamos que este producto sea perfecto Si no lo es, ayúdenos a corregirlo 800-234-0604 Nous exigeons de nos produits qu’ils soient parfaits help@vornado.com Si celui-ci ne l’est pas, nous corrigerons la situation...
