Napa 791-5224 Manual

BEFORE USING THIS DEVICE, READ THIS
MANUAL COMPLETELY AND THOROUGHLY,
UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS.
It is the responsibility of the device owner to make sure all personnel
read this manual prior to using the device. It is also the responsibility
of the device owner to keep this manual intact and in a convenient
location for all to see and read. If the manual or product labels are lost
or not legible, contact NAPA for replacements. If the operator is not
fluent in English, the product and safety instructions shall be read to
and discussed with the operator in the operator's native language by
the purchaser/owner or his designee, making sure that the operator
comprehends its contents.
SPECIFICATIONS
Capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Ton
Low Height. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1/2"
High Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-1/2"
Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1/16" x 7-7/8"
Saddle Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1" x 3-1/2"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.9 lbs.
791-5224
ALUMINUM JACK STANDS
WARNING
Read, study, understand and follow all instructions before
operating this device • Inspect the jack stands before each
use. Do not use if damaged, altered, modified, in poor
condition, or unstable due to loose or missing components.
Make corrections before using • User and bystanders must
wear eye protection that meets ANSI Z87.1 and OSHA
standards • Use as a matched pair only • Use only on a hard
level surface capable of supporting the load • Stands are to
be used in matched pairs to support one end of a vehicle
only. Do not simultaneously support both ends or one side
of a vehicle • Center load on saddle. Do not use saddle
lugs to support the load • Do not use jack stands beyond its
rated capacity. Do not shock load • Maximum load capacity
per matched pair shall not exceed the rated capacity of the
individual stand • Apply the emergency brake, put the gear
shift lever in park or in gear if a manual shift transmission, and
chock the tires that will not be lifted off the ground • Check the
stands for solid contact with the ground and vehicle • Ensure
both stands are set at same height and locking pawls are fully
engaging the support column's teeth • Do not crawl under
vehicle when placing/removing stands • Consult the
vehicle manufacturer for the proper frame support locations.
• No alterations shall be made to these stands • Failure to
heed these warnings may result in serious or fatal personal
injury and/or property damage.
WARNING: This product can expose you to
chemicals including nickel, which is known to
the State of California to cause cancer and birth
defects or other reproductive harm.
information go to www.P65Warnings.ca.gov.
1
MODEL # 791-5224
3 TON CAPACITY
(ONE PAIR)
ASME PASE-2014
For more
rev. 03/13/18
