Installation Instructions
Pet Barrier
www.Bestop.com
- We're here to help! Visit our web site and click on
INSTALLATION TIME
2 Hours
TOOLS
10mm,13mm
10mm,13mm
This product is designed primarily to enhance the appearance of the vehicle. Do not rely in any way on the components of this product to
protect against injury or death in the event of an accident. Never operate the vehicle in excess of manuracturer's specifications.
WEAR SEAT BELTS AT ALL TIMES
Read and follow, precisely, all installation instructions provided when installing product. Failure to do so may result in a poor fit and could place occupants
of the vehicle in a potentially dangerous situation.
SKILL LEVEL
2 - Moderately Easy
4mm
T-30, T-40
Vehicle Application
• Jeep Wrangler
2011 - Current
Part Number: 42503
"Ask a
Question". Click here for more
Jeep Accessories by Bestop.
Advertisement
Related Manuals for Bestop 42503
Summary of Contents for Bestop 42503
- Page 1 Vehicle Application Installation Instructions • Jeep Wrangler 2011 - Current Part Number: 42503 Pet Barrier www.Bestop.com - We’re here to help! Visit our web site and click on “Ask a Question”. Click here for more Jeep Accessories by Bestop. INSTALLATION TIME...
- Page 2 M8 Lock Nut (Nyloc Upper Mounting Qty - 4 Nut), Qty - 2 Bracket, Qty - 2 Lower Mounting Bracket, Qty - 2 Seat Rail Cover Passenger Side Shown M8 x 35mm Hex Bolt, Qty - 2 Rev. F 0114 42503 pg. 2...
- Page 3 M8 x 35mm Hex Bolt M8 Washer M8 Bushing Middle T-40 Torx Bracket Right Middle Bracket M6 x 15mm M8 Washer Thumbscrew Right Middle Passenger Side Shown Bracket Base M8 Nut Bracket Passenger Side Shown Rev. F 0114 42503 pg. 3...
- Page 4 Upper Mounting Bracket to the Upper Partition. M6 x 20mm Bracket Thumbscrew Do not tighten fasteners. Repeat on both sides. M6 x 25mm Button Head Screws Upper Mounting Bracket Upper Partition M6 Washers and M6 Lock Nuts Rev. F 0114 42503 pg. 4...
- Page 5 M6 x 35mm Button eight (8) M6 Washers and four Head Screw (4) M6 Lock Nuts to secure the M6 Washers Upper Partition to the Lower Partition. Upper Partition Lower Partition M6 Lock Nut Rev. F 0114 42503 pg. 5...
-
Page 6: Limited Warranty
This warranty gives you specifi c legal rights, and you may also have other rights which vary from state to state. For further information or request for warranty work, please contact: Bestop Inc. Customer Service Toll-Free: (800)845-3567 Main: (303)465-1755 E-mail: csbestop@Bestop.com...
