Redkite Baby Go Round Jive Instruction Leaflet page 3

To attach the seat unit
Thread the plastic tabs on the bottom
of the seat unit through the
slots running around the seat recess.
Fig 4. From underneath the walker pull
the tabs fully through the slots and
secure in place behind the fixing point.
Make sure all 8 tabs are locked in
place
Fig 4a.
Slot the musical tray into the recess
Fig 5 and secure in place by
pushing the key up and turning 90
degrees.
Fig 5a
Height Selection and folding
Turn the red button 90 degrees and
press it in. Keep it pressed in and raise
or lower the walker to the required
position.
Fig 6.
5
Fig 4
Fig 5
6
Fig 6
Fig 4a
Fig 5a
